  1. Filtration Principle and Application 过滤原理及应用 默克密理博 王斌

  2. Outline 讲座主要内容 • Filtration Technology and Principles • 过滤知识及原理 • Filtration usage and maintains • 过滤器的使用及维护 • Typical Sterile filtration process • 典型除菌过滤流程

  3. 5 0.22 µm 4 1 2 3 Introduction to Filtration 过滤基本知识

  4. Size Exclusion大小排除 • Particles are too large to pass through the "pore“ • 基于大小来分离 • Examples are termed entrapment, sieving, surface capture • 例如拦截,筛分,表面捕获 • Adsorption吸附 • Particles stick to the filter by chemical / electrical attraction • 颗粒由于化学/电荷作用粘附在滤器上 How do Filters Work? 过滤机理

  5. Main content主要内容 • Important differences in the types of filters used in Bioprocesses. • 生物制药中使用的不同类型过滤器及其特性 • Why we use membrane filters for critical application • 关键应用中为什么使用膜过滤器 • How to recognize filtration problems and perform basic troubleshooting • 怎样理解过滤中的问题和解决简单故障

  6. Filter media type 过滤介质种类 • 深层滤膜 Depth filter • 表面滤膜 Surface filter • 绝对膜 Membrane filter

  7. Typical filter device 常见过滤装置

  8. Install filter 安装滤芯 Autoclave 高温高压/SIP Flushing/wetting 冲洗/润湿 Sterile filtration 除菌过滤 Integrity test 完整性测试 Flushing/wetting冲洗/润湿 Air blow down 空气吹干 DP < 5 psi Integrity test 完整性测试 Typical sterile filtration process除菌过滤基本流程

  9. Sterile Filtration 除菌过滤

  10. Filter Cleaning 滤芯的清洗 • 1．Forward cleaning 正向清洗： • Cleaning agent or water clean from upstream to downstream, pressure could be higher than process.清洗剂或清洗水从膜的上游到下游的清洗方法，可以用稍大于过滤产品的压力来进行。 • 2．Reverse cleaning 反向清洗： • Cleaning agent or water clean from downstream to upstream, pressure should be less than specification.清洗剂或清洗水从膜的下游到上游的清洗方法； • 压力要严格按照产品说明书给定的参数来执行； • 3．Cleaning agent selection 清洗剂的选择 • We should consider 选择清洗剂时，必须考虑下列因素 • 1、Fouling type堵塞的类型 • 2、Membrane type, Chemical compatibility 膜的类型，化学兼容性（如PVDF不能用NaOH清洗，但是蛋白吸附极低，可以用40~50度250~300ppm 活性氯的NaCIO清洗） • 3、Application requirement应用的要求

  11. There are two major retention mechanisms in liquids • 在流体过滤中有两类过滤机理 • Adsorption, Size Exclusion吸附,大小排除 • Three types of filters are commonly used in biopharmaceutical filtration • 三类过滤器普遍使用在生物制药 • Depth, Surface, Membrane深层,表面,膜过滤 • Filter materials are supplied as either过滤介质以下列形式提供 • Disc, Stacked Disc, Pleated Cartridge圆盘,层叠式,柱式 • Filters block by either过滤堵塞可以是 • Gradual, Total or Cake逐渐堵塞,完全堵塞 • Filtration problems can be solved过滤问题可以被解决 • Monitoring and optimizing are key techniques监测和优化是关键技术 Filtration Summary总结
