slide1

A critical assault upon

“A Comparison of Software and Hardware Techniques for x86 Virtualization”

Chris Smowton

virtualisation in a slide
Virtualisation in a slide
  • Emulate running guest OS on real hardware
  • Use actual hardware where you can
  • Respond to cases where you can't with emulation
    • Trap reactively (e.g. catch illegal instruction exception)
    • Or adapt code to call out preemptively
virtualising x86
Virtualising x86
  • Two (major) sources of traps
    • Inherently privileged instructions
      • e.g. “disable interrupts”, “enter kernel mode”
      • Easy to detect
    • Writes to privileged memory
      • e.g. write page table, segment table
      • Could be caused by any ALU op (damn CISC)
classical virtualisation and x86
Classical virtualisation and x86
  • Classical virtualisation: run guest in unprivileged processor mode
    • Including kernel
    • Take and handle exceptions on privileged ops
  • But x86: Guest can tell it's being virtualised
  • And: Some instructions fail silently
two ways out
Two ways out
  • Software binary translation
    • Rewrite those pesky instructions
    • Opportunity to be cleverer than trap-and-emulate
  • Hardware virtualisation
    • i386 v1.1: introduce guest mode
    • Extra pseudo-privileged CPU state
      • Guest exception vectors, interrupt mask...
    • Still trap page table alterations
software bt the vmware way
Software BT (the vmware way)
  • Rewrite guest kernel-mode code on demand
  • Translate inherently privileged ops away
    • Easy ones: emulate without invoking VMM
      • e.g. disable interrupts
    • Hard ones: call into VMM (cheaper than trap)
  • Profile guest memory ops
    • Often faults? Replace with VMM call
    • Or, avoid call altogether!
    • Sort of automatic PV OS generator
guest mmu emulation
Guest MMU emulation
  • Guest will try to write page tables
    • However we detect that action
    • Map guest VAs to pseudo-physical address
  • VMM maps guest PPAs to (real) machine addresses
  • Maintain a “shadow page table” mapping guest VAs to Mas
  • Ensure shadow table always consistent with guest expectations
software bt a neat example
Software BT: a neat example
  • Process creation: build a bunch of page tables
    • Want to avoid fault on every PT write
  • x86: new table entries not valid until TLB flush!
  • Don't call up – instead, save in SHM buffer
  • On TLB flush, VMM processes the buffer
  • Like Xen PV guests, only automatically generated
hardware virt the intel way
Hardware Virt (the Intel way)
  • Replicate privileged processor state in VMCB
  • New processor mode: entered passing VMCB
    • Disable interrupts? Write to VMCB
    • Divide by zero? Check VMCB exc. Vector
    • Enter kernel mode? Same.
  • But, no guest MMU support in hardware
    • Need software MMU emulation as before
relative merits
Relative merits
  • Hardware virt good at anything the VMCB supports
    • Syscalls, interrupt mask...
  • Software BT better at MMU ops
    • Dynamically adapts
    • Could do that for HW guys too...
      • But they don't
results in a nutshell
Results in a nutshell
  • As you might suppose
    • HWVM wins when MMU ops are rare relative to syscalls, exceptions
      • Probably awesome at running getpid
    • SWVM wins the rest of the time
      • Particularly good at running fork-bombs
so criticism
So, criticism?
  • Results probably true
  • Can't reasonably claim obsolete hardware
  • But, a straw man?
  • Restates the same outcome in a dozen guises
  • Ignores the main benefit of classically virtualisable x86:
    • Possible to write a small VMM
    • Which unsurprisingly would be a slower
