    1. Weathering

    2. Weathering and Erosion Weathering is the chemical or physical breakdown of a rock or mineral due to exposure to the atmosphere. Erosion is the removal or transport of material by 5 possible agents: running water, glaciers, waves, wind, and gravity. www.gg - wind, water, waves, gravity, glaciers Humans and animals may also play a part in erosion.

    3. Types of Weathering There are two major types of weathering: 1. Physical (mechanical) – mechanical breakdown of rock or mineral. Just breaks it into smaller pieces, composition of the material is NOT changed!! 2. Chemical – decomposition of material. The composition IS changed!!

    4. Mechanical Weathering – Video Clip

    5. Physical (Mechanical) Weathering There are several different types of physical weathering: 1. Frost or Ice Wedging – alternating freezing and thawing of moisture in rock openings causing rock disintegration. Water expands as it freezes, this breaks the rock into angular fragments. Occurs A LOT in Western New York – causes most potholes!! Will ONLY occur in areas where the temperature alternates above freezing and below freezing!!!

    7. Physical (Mechanical) Weathering 2. Exfoliation – Erosion of upper rock causes underlying rock to expand resulting in cracking and peeling of rock in slabs. Think of onion skin layers and peeling them off!!

    9. Physical (Mechanical) Weathering 3. Organic Activity – plant roots or animals like burrowing worms can cause rock to breakdown.

    10. Physical (Mechanical) Weathering 4. Wetting and Drying - addition of water to mineral structure causes structure to expand.

    11. Physical (Mechanical) Weathering IMPORTANT!! Physical weathering increases the surface area of rocks/minerals. Taking a rock/mineral and breaking it up into smaller pieces causes it to take up more space (surface area) and will eventually increase the rate of chemical weathering to occur.

    13. Chemical Weathering – Video Clip

    14. Chemical Wethering There are also several different types of chemical weathering: 1. Hydrolosis – chemical reaction between water and other substances. Silicate minerals will often form clay from this process.

    15. Chemical Weathering 2. Carbonic Acid – dissolving of substances by acids in water often leaving insoluble remains.

    16. Chemical Weathering 3. Oxidation – chemical reaction of a substance with oxygen causing a rust material to form.

    17. Weathering and Climate Climate plays a very important role in weathering. The temperature and amount of moisture influences the type of weathering that will occur. Warm and wet climates produce mostly chemical weathering. Never any frost wedging. Cool and slightly wet climates produce mostly physical weathering.

    19. Weathering and Resistance The harder the rock or mineral is, the more resistant it will be to weathering. Any rock with quartz will be quite resistant due to quartz’s hardness. What is quartz’s hardness?? Rocks made mostly of calcite, a very soft mineral, will be easily weathered. What is calcite’s hardness??

    20. Porosity and Permeability Porosity: The percentage of pore space in a material Permeability: The ability of a material to let liquid (water) pass through it. Impermeable: When something will not let liquids pass through it (usually water is the liquid).

    21. Does the grain size or the size of the sediment affect the porosity? NO!!!!! Smaller pieces have smaller gaps between them but there are lots of gaps. Larger pieces have fewer gaps, but they are larger gaps. So…the amount of pore space (porosity) does not change with grain size.

    24. Permeability If something has Low Porosity, then permeability will be SLOW If something has High Porosity, then permeability will be FAST
