progress report regarding redesign and packaging of adirondack chair

Progress Report Regarding Redesign and Packaging of Adirondack Chair

Team: 58

Project #F07-58ADRNDKCH

Client: Garrett Cook

Center For Comprehensive Services

Team Members:

William Fogerson

Craig Craddock

Jason Hick

John Mathews

&

Mike Mayo

outline
Outline
  • Background on Client
  • Background on Project
  • Computer Simulation
  • Physical Testing
  • Packing
  • Timeline
  • AIL
  • RASI
  • Summary
computer simulation
Computer Simulation
  • Modeling
    • Computer Aided Design
      • 3D part drawings were constructed
      • Parts were then assembled as required
    • Finite Elemental Analysis
      • Stress analysis was performed on the original design and the new designs proposed
      • Maximum principal stress was compared for each design
computer aided design
Computer Aided Design
  • Autodesk Inventor
computer simulation1
Computer Simulation
  • Original Design 100 psi 100lbf Couple
computer simulation cont d
Computer Simulation Cont’d
  • 2x6 Design 100 psi 100lbf Couple
computer simulation cont d1
Computer Simulation Cont’d
  • 1x6 Design with Bracing and Glue
  • 100 psi 100lbf Couple
physical testing
Physical Testing
  • Test Set-up
physical testing cont d
Physical Testing Cont’d
  • Average Force and Range of Force
physical testing cont d1
Physical Testing Cont’d
  • Range as a Percentage of Average Force
packaging
Packaging
  • Procured Boxes, bubble wrap, and tape
  • Provide Client with 2 options
    • Option A
      • Smaller box therefore cheaper shipping cost
      • Much more assembly required
    • Option B
      • Larger box therefore more expensive to ship
      • Less Assembly required
executive summary
Executive Summary
  • Team Members
  • Background on Client
  • Background on Problems
  • Major Problems
  • Major Changes
  • Additional Resources
