motorola weavr model driven software development in a large industrial context

Motorola WEAVR: Model-Driven Software Developmentin a Large Industrial Context

by Thomas Cottenier

Software and System Engineering Research Lab, Motorola Labs

Directed by Dr. Tzilla Elrad,

Illinois Institute of Technology

January 2007

motorola weavr outline
Motorola WEAVROutline
  • Introduction
  • What is a Software Model?
  • Model-Driven Software Development
  • Aspect-Oriented Software Development
  • Motorola WEAVR
  • Further Work
  • Conclusions
motorola weavr how to manage software complexity
Motorola WEAVR How to Manage Software Complexity?

Evolution of Software Design: Monolithic → Modular

Abstraction

Focus only on relevant properties – omit what is not relevant

Decomposition

Divide software into separately named and addressable modules

Encapsulation

Group related things together.

InformationHiding

Hide implementation details from the outside

Separation of Concerns

  • Ensure that each module only deals with one concern
  • Low Coupling among the modules
  • High Cohesion within one module
how to manage software complexity

Models

Models@runtime

Aspect-Oriented Programming

Source

Code

1990’s

Object Oriented Programming

Procedural Programming

1980’s

How to Manage Software Complexity?

Aspect-Oriented Software Development

Metamodeling

2000’s

Model-Driven Engineering

motorola weavr introduction
Motorola WEAVR Introduction

Applications = Computations + Composition

Object-Oriented Programming

Applications = Objects + Aggregation, Association,

Inheritance, Polymorphism, ..

Component-Based Software Development

Applications = Component Interfaces + Scripts

Service-Oriented Architecture

Applications = Service Interfaces + Business Processes

Model-Driven Development

Applications = Libraries + Models

motorola weavr introduction1
Motorola WEAVR Introduction

Problems:

- Brittle Composition Mechanisms

Software reuse mechanisms do not scale

Separate Composition from Computation

Domain-Specific Abstractions

- Purely Hierarchical Decomposition

Some concerns cannot be modularized according to an hierarchical decomposition

Aspect-Oriented Software Development

motorola weavr what is a software model
Motorola WEAVR What is a Software Model?

Different types of systems:

  • Transformational systems:

Data-Processing systems, Compilers, Search-Engines, Computation Intensive systems, etc..

  • Reactive systems

ATM, vending machines, phones, cars, missile and avionic systems, telecom infrastructure, human-machine interface of may ordinary software

motorola weavr what is a software model1
Motorola WEAVR What is a Software Model?

Different types of systems:

  • Transformational systems:

Data-Processing systems, Compilers, Search-Engines, Computation Intensive systems, etc..

Procedural, Functional, Object-Oriented, etc programming languages provide excellent support for Transformational systems!

motorola weavr what is a software model2
Motorola WEAVR What is a Software Model?

Different types of systems:

  • Reactive systems

ATM, vending machines, phones, cars, missile and avionic systems, telecom infrastructure, human-machine interface of may ordinary software

Procedural, Functional, Object-Oriented, etc programming languages DO NOT provide the right abstractions

motorola weavr reactive systems

1. void actionPerformed(ActionEvent evt) {

2. switch(this.STATE){

3. case Init:

4. serviceA.methodA();

5. if(evt.getSource() == Enter){

6. serviceB.methodB();

7. if(evt.getActionCommand() == “Previous”){

8. serviceC.methodC();

9. this.STATE = Previous;

10. return;

11. }else

12. if(evt.getActionCommand() == “Next”){

13. serviceD.methodB();

14. this.STATE = Next;

15. return;

16. }

17. }else

18. if (evt.getSource() == Cancel){

19. }

20. break;

21. case Previous:

22. serviceA.methodE();

23. break;

24. case Next:

25. if(evt.getActionCommand() == “Proceed”){

26. serviceA methodC();

27. }

28. break;

29. }

30. methodF();

31. this.STATE = Done;

32. return;

33. }

Motorola WEAVR Reactive Systems

Example: Java Applet

motorola weavr reactive systems1
Motorola WEAVR Reactive Systems

Statechart is a decomposition that better fits the problem domain than the procedural decomposition

motorola weavr reactive systems2

1. void actionPerformed(ActionEvent evt) {

2. switch(this.STATE){

3. case Init:

4. serviceA.methodA();

5. if(evt.getSource() == Enter){

6. serviceB.methodB();

7. if(evt.getActionCommand() == “Previous”){

8. serviceC.methodC();

9. this.STATE = Previous;

10. return;

11. }else

12. if(evt.getActionCommand() == “Next”){

13. serviceD.methodB();

14. this.STATE = Next;

15. return;

16. }

17. }else

18. if (evt.getSource() == Cancel){

19. }

20. break;

21. case Previous:

22. serviceA.methodE();

23. break;

24. case Next:

25. if(evt.getActionCommand() == “Proceed”){

26. serviceA methodC();

27. }

28. break;

29. }

30. methodF();

31. this.STATE = Done;

32. return;

33. }

Motorola WEAVR Reactive Systems
motorola weavr reactive systems3
Motorola WEAVR Reactive Systems

Modules that:

  • are repeatedly prompted by the outside world and continuously respond to external inputs
  • behavior is highly dependent on module history

Abstractions:

  • State
  • Transition
  • Decision Actions

Today, most systems are hybrid systems (reactive and transformational)!

motorola weavr what is a software model3
Motorola WEAVR What is a Software Model?

UML: Collection of Languages that provide complementary decomposition abstractions

  • Object-Oriented and procedural decomposition: Class Diagrams, Sequence Diagrams
  • Reactive decomposition:

State Machine diagrams

  • Workflow decomposition:

Activity Diagram

  • Runtime structure decomposition:

Composite-Part Diagram

+ Execution:

Action Language

motorola weavr what is a software model4
Motorola WEAVR What is a Software Model?

Object-Oriented

Workflow

State Machine

Run time Structure

+ Execution: Action Language

Procedural

motorola weavr model driven software development
Motorola WEAVRModel-Driven Software Development

Different Types of Modeling Practices:

  • Sketches (e.g. Visio)
  • Blue-prints/Elaboration (e.g IBM Rational)
  • Executable Models (e.g IBM Rational)
  • Translatable Models (e.g. Telelogic, iUML)
motorola weavr mdd
Motorola WEAVRMDD

Blue-prints/Elaboration

(e.g IBM Rational)

motorola weavr mdd1
Motorola WEAVRMDD

Model Translation

motorola weavr model driven software development1

Domain Standard

Notations

UK

USA

RMTR

air_in

taxi_in

taxi_out

air_out

GENERICCODE GENERATOR

DESIGN

SIMULATION

UNIT TEST

Motorola WEAVRModel-Driven Software Development

PRODUCT

REQUIREMENTS

VALIDATION

MIDDLEWARE, OS,

PLATFORM

PRODUCT CODE

VERIFICATION

motorola weavr model driven software development4
Motorola WEAVRModel-Driven Software Development

Example: Resource Access Server

VALIDATION

motorola weavr model driven software development6
Motorola WEAVRModel-Driven Software Development

Example: Resource Access Server

Realization

Mappings

4.b.

4.a.

slide28

Motorola WEAVRAspect-Oriented Software Development

  • Socket creation in Tomcat
    • - fits nicely into one package (3 classes)

Good Modularity

slide29

Motorola WEAVRAspect-Oriented Software Development

  • Class Loading in Tomcat
    • - mostly in one package (9 classes)

Good Modularity

slide30

Motorola WEAVRAspect-Oriented Software Development

Logging in Tomcat

- scattered across the packages and classes

- error handling, security, business rules, …

Poor Modularity

motorola weavr aspect oriented software development
Motorola WEAVRAspect-Oriented Software Development

Goal of AOSD

Enable the modular (not scattered) implementation of crosscutting concerns.

Aspect

Explicit abstraction for representing crosscutting concerns

Aspect-Oriented Programming

Language that provides mechanisms to capture aspects

Aspect Weaver

Composition mechanism that coordinates aspects with the rest of the code

aosd terminology crosscutting concerns
AOSD – TerminologyCrosscutting Concerns

Scattering

In a given implementation, the code for a concern is spread out. Single concern affects multiple modules.

Tangling

Multiple concerns are

interleaved in a single module

Crosscutting Concern

The inherent structure of the concern can not be modularized in the decomposition mechanism of the language (Objects or procedures), because it follows different composition rules.

  • class Point {
  • void setX(int x) {
  • Tracer.traceEntry(“Entry Point.set”);

DisplayTracker.updatePoint(this);

  • this.x = x;
  • Tracer.traceExit(“Exit Point.set”);

}

  • }
aosd crosscutting concerns
AOSDCrosscutting Concerns
  • Synchronization
  • Real-time constraints
  • Error-checking
  • Object interaction constraints
  • Memory management
  • Persistency
  • Security
  • Caching
  • Logging
  • Monitoring
  • Testing
  • Domain specific optimization
  • ...
slide36

WEAVR

Model weaving

Engine

Resource Initialization Aspect

Initialization Exception Handling Aspect

motorola weavr examples fault tolerance2
Motorola WEAVRExamples: Fault-Tolerance

Example: Resource Access Server

Realization

Mappings

4.b.

4.a.

motorola weavr examples fault tolerance4
Motorola WEAVRExamples: Fault-Tolerance

10.a.

Recoverability

restore

backup

motorola weavr further work
Motorola WEAVRFurther Work

AspectX

classX

x

classY

AspectY

WEAVR partially addresses the most important issue with AOSD

  • Dependency Inversion

Does dependency inversion impedes system modularity, evolvability?

  • Aspect/Core semantic interactions

Guaranties on the quality attributes of woven software?

  • Interferences between aspects

AOSD destroys the locality of the run-time control flow.

We need full global knowledge in order to reason about the correctness of the system!

  • Syntactic Joinpoint Designators

Does my join point specification match my intention of the joint point?

AOP introduces new ways the correctness of a program can break down

Current joint point languages are too low level

motorola weavr further work1
Motorola WEAVRFurther Work

How to guarantee the correctness of woven Models?

Validation, Simulation, Model Checking, testing of woven models?

motorola weavr conclusions
Motorola WEAVRConclusions
  • Modeling allows a system to be decomposed according to complementary decomposition abstractions. Use the abstraction that fits problem domain the best
  • Model-Driven Software Development – fully automatic code generation from executable models
  • Aspect-Oriented Software Development – provide abstractions for crosscutting concerns
  • Motorola WEAVR: Aspect-Oriented Software Development through model transformation

Our Contribution

  • Aspect-Oriented Language for State Machines – New Joinpoint model
  • Inference of Implementation Joinpoints from Pointcuts expressed in terms of the Specification – Increased Modularity
  • Concepts fully implemented in WEAVR tool
  • Tool deployed in an industrial context – Expected Results by end 2007: Reduction of 40% of model size in WiMAX infrastructure project
motorola weavr references
Motorola WEAVRReferences

Website: http://www.iit.edu/~concur/weavr/

Contact: thomas.cottenier@motorola.com

  • Cottenier, T., van den Berg, A., Elrad, T.: Joinpoint Inference from Behavioral Specification to Implementation, submitted to ECOOP’07, available at www.iit.edu/~concur/weavr/papers/, 2006
  • Cottenier, T. Aspect-Oriented Modeling and Simulation. Tutorial to be presented at the International Conference on Aspect-Oriented Software Development, Vancouver, Canada, 2007http://www.iit.edu/~concur/weavr/papers/AOMS_tutorial_proposal.pdf
  • Cottenier, T., van den Berg, A., Elrad, T. The Motorola WEAVR: Model Weaving in a Large Industrial Context. To appear in Proceedings of the International Conference on Aspect-Oriented Software Development, Industry Track, Vancouver, Canada, 2006http://www.iit.edu/~concur/weavr/papers/AOSD_MotorolaWEAVR.pdf
  • Cottenier, T., van den Berg, A., Elrad, T. Motorola WEAVR: An Add-In for Aspect-Oriented Modeling in TAU. Telelogic User Group Conference, Denver, Colorado, USA, 2006http://www.iit.edu/~concur/weavr/papers/motorola_weavr.pdf
  • Cottenier, T., van den Berg, A., Elrad, T. Model Weaving: Bridging the Divide between Translationists and Elaborationists. Workshop on Aspect-Oriented Modeling at the 9th International Conference on Model Driven Engineering Languages and Systems, Milan, Italy, 2006http://www.aspect-modeling.org/acceptedpapers_oct06/thomas.pdf
  • Zhang, J., Cottenier, T., van den Berg, A., Gray, J., Aspect Interference and Composition in the Motorola Aspect-Oriented Modeling Weaver. Workshop on Aspect-Oriented Modeling at the 9th International Conference on Model Driven Engineering Languages and Systems, Milan, Italy, 2006http://www.cis.uab.edu/gray/Pubs/aom-models-2006.pdf
  • Cottenier, T., van den Berg, A., Elrad, T. Modeling Aspect-Oriented Compositions. Proceedings of the Satellite Events at the 8th International Conference on Model Driven Engineering Languages and Systems, Montego Bay, Jamaica, LNCS 3844, pp. 100-109, Springer-Verlag, 2005http://www.iit.edu/~concur/weavr/papers/maoc_lncs.pdf
