Presentation Transcript
overview
overview
  • Sockets are a protocol independent method of creating a connection between processes.
java socket api
JAVA Socket API
  • java.net.Socket
    • Socket(InetAddressaddr, int port);
      • create a Socket connection to address addr on port port
    • InputStreamgetInputStream();
      • returns an instance of InputStream for getting info from the implicit Socket object
    • OutputStreamgetOutputStream();
      • returns an instance of OutputStream for sending info to implicit Socket object.
    • close();
      • close connection to implicit socket object, cleaning up resources.
java socket api1
JAVA Socket API
  • java.net.ServerSocket
    • ServerSocket(intport);
      • enables program to listen for connections on port port
    • Socket accept();
      • blocks until connection is requested via Socket request from some other process. When connection is established, an instance of Socket is returned for establishing communication streams.
  • java.net.InetAddress
    • static InetAddressgetByName(String name)
      • given a hostname name, return the InetAddress object representing that name (basically encapsulates name and IP associated with name);
    • static InetAddress[] getAllByName(String name)
      • same as above but for case where many ip’s mapped to single name (try www.microsoft.com, e.g.).
    • static InetAddressgetLocalHost()
      • get InetAddress object associated with local host.
    • static InetAddressgetByAddress(byte[] addr)
      • get InetAddress object associated with address addr
simple server
Simple server

try {

serverSocket= new ServerSocket(port);

clientSocket= serverSocket.accept();

out = new DataOutputStream(

clientSocket.getOutputStream());

String str = “HELLO”;

out.write(str.getBytes(), 0, str.getBytes(.length);

out.flush();

} catch (IOException ex) {

}

simple client
Simple Client

try {

clientSocket= new Socket(port);

in = new DataInputStream(clientSocket.getInputStream());

inByte = new byte[1024];

in.read(inByte);

server = new String(inByte, 0, inByte.length);

System.out.println(server.trim());

} catch (IOException ex) {

}

java web socket sever
JAVA WEB SOCKET SEVER
  • It is based on sokets.
  • Java Websocket Solution
      • http://java-websocket.org/
    • http://jwebsocket.org/
java web socket api
JAVA WEB SOCKET API
  • Import WebSocket Library
    • http://java-websocket.org/

import org.java_websocket.server.WebSocketServer;

import org.java_websocket.WebSocket;

public class ChatServer extends WebSocketServer implements ActionListener

{

private WebSocket player;

public ChatServer(int port) { super(port); }

public void onClientOpen(WebSocket conn) {

try {

this.player= conn;

this.player.send("Hello Player"); // sendToAll

} catch (Exception ex) { ex.printStackTrace();}

}

public void onClientClose(WebSocket conn)

public void onClientMessage(WebSocket conn, String message)

public void onError(Throwable ex)

}

web socket
WEB socket
  • Creating a WebSocket
    • url= "ws://localhost:8887";
    • w = new WebSocket(url);
  • Add Event Listeners
    • w.onopen = function() { log("open");w.send("thank you for accepting this websocket request");}
    • w.onmessage = function(e) { log(e.data);}
    • w.onclose = function(e) { log("closed");}
  • Sending Message
    • document.getElementById("sendButton").onclick = function() {w.send(document.getElementById("inputMessage").value);}
websocket server
WebSocket Server
  • A Simple Java WebSocket Server
    • https://github.com/TooTallNate/Java-WebSocket
  • Compile WebSocket Server Example
    • ant
  • Run WebSocket Server
    • java -cp build/examples:dist/java_websocket.jar ChatServer
a websocket chatroom
A websocketchatroom
  • function connectServer() {
  • varurl= "ws://localhost:8887";
  • socket = new WebSocket(url);
  • socket.onopen = function() {
  • updateSocketStatus("Connected to WebSocket server");
  • }
  • socket.onmessage = function(e) {
  • updateSocketStatus("Update message: " + e.data);
  • }
  • }
  • function sendMessage() {
  • var message = document.getElementById("sendMessage").value;
  • socket.send(message);
  • }
  • document.getElementById("connectButton").addEventListener("click", connectServer);
  • document.getElementById("sendMsgButton").addEventListener("click", sendMessage);
slide14

1.連線對戰遊戲配對控制

  • 2.身份辨識
  • 3.亂數子的產生
  • 4.同步
