ee 4345 semiconductor electronics design project spring 2002 lecture 05

EE 4345 - Semiconductor Electronics Design Project Spring 2002 - Lecture 05

Professor Ronald L. Carter

ronc@uta.edu

http://www.uta.edu/ronc/

rfp for tp1 1 tp 1 10
Each of the groups in EE 4345 designated by group leaders will present a proposal for doing a Technology Presentation in TP1.1 - TP1.10 as in assignments

Group Leaders

Fares Alnajjar

Jepsy Colon

Robert Colville

Eyad Fanous

Carlos Garcia

Derek Johnson

Nam Nguyen

Peter Presby

Viet Tran

Preeti Yadav

RFP for TP1.1 - TP 1.10
dates for technology project reports
Dates for Technology Project Reports
  • 12 Feb - TP1.1 Text Chapter 2 - 2.1 to 2.4
  • 12 Feb - TP1.2 Text Chapter 2 - 2.5 through 2.7
  • 14 Feb - TP1.3 Text Chapter 3 - Ch 3 - 3.1
  • 14 Feb - TP1.4 Text Chapter 3 - 3.2
  • 19 Feb - TP1.5 Text Chapter 3 - 3.3
  • 19 Feb - TP1.6 Text Chapter 4 - Ch 4 - 4.1 - 4.3.1
  • 21 Feb - TP1.7 Chapter 4-4.3.2(except CMOS and BiCMOS) through 4.4.2
  • 21 Feb - TP1.8 Chapter 5 - Ch 5 - 5.1 through 5.4
  • 26 Feb - TP1.9 Chapter 5 - 5.5 through 5.6
  • 26 Feb - TP1.10 Chapter 6 - Ch 6 (all)
minimum presentation requirements
Minimum presentation requirements
  • 25 to 35 minutes.
  • using visuals such as black on white line drawing transparencies which are easily readable from all parts of the classroom, and can be downloaded so that all students can make their own copy.
  • electronic copy as *.doc or *.ppt file of visuals mailed to ronc@uta.edu by noon the day before presentation.
to respond to this rfp
TO RESPOND TO THIS RFP
  • By 5 pm 31 January, each Group Leader will return the following from their group:
    • A list of all TEN TP numbers, TP1.1 through TP1.10, in rank order of
    • the preference of the group for presentation. Give the TP number MOST preferred FIRST.
to respond to this rfp1
TO RESPOND TO THIS RFP
  • The Group's plan for making the presentation awarded. Include:
    • a description of the media to be used (transparencies, etc.),
    • extra sources for information presented (other books, etc.),
    • plan for development and presentation of the presentation, and
    • other plans which you believe should warrant awarding your highest preferences.
to respond to this rfp2
TO RESPOND TO THIS RFP
      • how each group member will participate in the preparation and presentation of the Technology Presentation - state the specific responsibilities of each member.
  • The TP assignments for TP1.1 through TP1.10 will be announced by 5 PM on 1 February.
getting started
Getting started

To set up your unix environment follow these steps:

  • Make directory called cadence.
  • Open console and type

ftp gamma

at login prompt : cxs4776

password: cxs2011

get .cshrc.oo

get .cshrc.ic

get .simrc

get .cdsinit

bye

slide9
Adding the technology files.

Open the console and at prompt type:

telnet gamma

cxs4776

password: cxs2011

cp –r cadence/ temp

exit

cp –r /tmp/cadence

Take care of the spaces in the commands.

slide10
Now you are all set for Cadence and Hspice
  • Every time you need to start working on Cadence do the following:

source .cshrc.ic

icfb&

These are some useful Cadence and Hspice tutorials online:

http://www.engr.sjsu.edu/~dparent/ee166/CDS_1.htm

http://vlsi.wpi.edu/cds/

http://www.ee.washington.edu/class/cadta/hspice/

http://www.ece.orst.edu/~moon/ece323/hspice/

schematic capture making the circuit
Schematic Capture: Making the circuit
  • Open the Library Manager (click tools on cadence window)
  • Create a new library (say Trial)

File > New >Library > Name >Attach existing file > Analog lib

  • Create a cell view (say inverter)

Click on library “Trial” > New >Cell view>Name> Tool: Schematic Composer

  • A black window should be on your screen now. Familiarize yourself with the handy click buttons on the left.
  • To add the parts of circuit

Instance > Browse > Analog lib > Select component >select view as symbol.

slide12
Add n-channel MOSFET (NMOS4) and a p-channel MOSFET (PMOS4). Set the properties , specifying width, length, and model.
  • Add pins : IN OUT VDD GND
  • Connect with wires
  • Check and save
schematic capture making the symbol
Schematic Capture: Making the symbol

Each circuit (schematic) created should have a symbol. The symbol is normally required when the same component is repeatedly used. This is most likely to happen when the bottom up design flow approach is used. To create a symbol:

  • Click on library “Trial” > New >Cell view>Name (same as schematic)> Tool: Schematic Symbol
  • Draw > Shape
  • Add pins with same names as those in the schematic
  • Check and Save
simulation
Simulation

To simulate the behavior of a component or a system a test bench is required. The best of going about that is creating a test library.

  • Create another library (say Trial test)
  • Create a new cell view (say Invtest)
  • To add the parts of circuit

Instance > Browse > Trial > Select Inverter >select view as symbol.

  • Attach a voltage source (vdc) at the IN and at VDD
  • Add a capacitor ( say cap = 0.01fF)
  • Attach ground (gnd) to the pin GND
  • Connect with wires
  • Check and save
slide15
There are various kinds of analyses possible , DC,AC,transient,etc. We will try DC analysis first.
  • Click on Tools > Analog Environment (this opens another window)
  • Analyses > DC > Specify the start and stop values and the component to be varied (In this case input voltage)
  • Outputs > to be plotted > select on schematic > wire coming out of “OUT” pin and the one going into the “IN” pin.
  • Setup > Simulator > HSPICE
  • Setup > modelpath > type in /home/usrXXXX/cadence/IC/models > add above > select path > apply and run
  • If everything is OK you should get an output in the form of the trasfer curve of Inverter.
