Presentation Transcript
slide1

1

7

OBD II Tracker

2

0

contents

Contents

Software Introduction

OBD Types

Basic Spec

Advntages

01

02

03

04

Market positioning is different

VT200, VT200B and VT400 (wifi hotspot)

Algorithm make our products better than 95% products

Provide web/Apps customizable services

slide3

01

OBD Types

01 obd types

01. OBD Types

GPS OBD II

(1)Bluetooth OBD II

Real-time but no security

First generation

Monitor the operating status of the engine and the working status of the exhaust aftertreatment system - the fault code

Second generation

OBD-II is different from all previous vehicle-borne diagnostic systems in that it has a strict emission targeting, and its physical performance is to monitor vehicle emissions by monitoring the vehicle's power and emission control system.

1. The shape of the integrated vehicle is 16PIN.

2. Has the numerical analysis data transmission function.

3. Unify the same fault code and significance of each vehicle.

4. With the traffic recorder function.

5. Have to re-display the memory fault code function.

6. With the instrument can be directly removed from the fault code function.

On this basis, built-in acceleration sensor to prevent the car stolen, increase the sensor to monitor driving behavior, etc., to form a security function based on electronic fence.

(2)WIFI OBD

Expensive but not security

(3)Error clear OBD

4S shop dedicated

(4)GPS OBD

Remote security, but delay

slide5

02

Specification

02 specifications

02. Specifications

VT200&VT200B

02 specifications 1

02. Specifications

VT400 4G Version

slide8

03

Advantages

03 advantage 1

03. Advantage-1

  • Historical track playback

GPS accurate positioning,

error is less than ten meter

Support the historical track playback, can see store three months data

Geo-fence

Compatible with 95%

brands cars

Temperature certifications

Platform type electronic fence, not at the expense of the productperformance

Passed high and low temperature test, work normally in -20 ℃ and ultra high temperature 75 ℃ condition

ISO 9141-2

ISO 14230-1

ISO 14230-2

ISO 15765-2

ISO 15765-4

Advantage

CE and ROHS ceritificate

Passed CE and ROHS certification, reach Europe quality standard level

03 advantage 2

03. Advantage-2

  • Support VIN code

Calculate mileage using

OBD's original data

support VIN, IMEI, and MSI

number

Smart upload interval

Low power consumption

Determine the upload time interval according to the curvature of the turn, speed, etc. 5S ~ 30S flexible

Running current: 50~60mA;

Sleep mode current: 8mA

Voltage range :8V~28V

High-performance TVS diode, avoid the voltage surge and jump effectively

Advantage

Save the network flow

Using hexadecimal, each packet to about 80bytes, saves the flow of data transmission

03 advantage 3

03. Advantage-3

  • Smart power IC chips

Big flash memory

When the car battery voltage less than 4V, devices will enter sleep state, not consuming battery power , ensure it have power even car parking long time

16M BIT, can store more than 14,000 pieces data, average on 4-5 hours a day

Fatigue driving alarm

Error code reading and clearing functions

Can avoid accident efficiently, save life and money

Can read about 2000 pieces error codes and clear them

Support RTC wake up

Support the RTC wake up, vibration wake up, SMS wake up, electricity wake up etc

Advantage

Remote upgrade(OTA)

No need to collect devices to upgrade firmware from end customers , can upgrade the firmware with the latest functions for customers easierly.

03 advantage 4

03. Advantage-4

  • Accurate fuel consumption analysis

Urgent acceleration and

sharp turn

Camber compensation

Total mileage, average, high-speed mileage, medium-speedmileage, low-speed mileage, idle mileage fuel consumption, accuracy up to 99%

3 axis sensor detect, accuracy can reach 99.9%

Support plug alarm

using the algorithm of automatic, automatic compensation when turning,ensure smooth track .

devices comes with a 140 ma of lithium battery, support plug in and remove out alarm

Driving behavior detection

Hard acceleration, rapid deceleration, sudden brak, sharp lanes changes,

sharp turns, fatigue driving, etc.,

accurate detect and report

Advantage

Accurate mileage analysis

Total mileage, speeding, high speed, medium speed, low speed mileages, accuracy reach 99%

03 advantage 5

03. Advantage-5

  • Support fleet management

Real-time status dashboard

Including real-time speed, mileage, fuel consumption battery voltage, engine speed,coolant temperature and air-fuel ratio

Under an account you can add an unlimited number car, achieve the function of team management.

Day, week, month report

Travel statistics report

Can select daily, weekly, and monthly mileage, fuel consumption, speed and driving behaviorof their respectpercentage and the number alarm s

Including the beginning and end of travel site, Engine system, report, the speed report,  driving behavior statements, such as a pie chart display, lear and concise

Accurate alarm statistics

Account statements of all the cars are stated and report timely, support alarm over 50 kinds.

Advantage

The healthy check-up car

the power charging system, throttle system,idle system, cooling system, fault system, etc

slide14

04

APP introduction

4 1 app interface

4.1 APPinterface

Account info

alarms

Car list

Device status

Report

Vehicle detect

Trip list

Geo-fence

Dashboard

4 2 report 1

4.2 Report-1

DailyreportWeekly reportMonthly report

4 2 report 2

4.2 Report-2

MileageFuel consumptionSpeeddriving behavioralarms

4 3 trip list 1

4.3 Trip list-1

Trip listTrip detailsHistory playback

4 3 trip list 2

4.3 Trip list-2

MileageFuel consumptionSpeeddriving behavioralarms

4 5 others

4.5 Others

Account infoCar listAlarms listCar's info

annex customize solution

Annex:customize solution

Firmware

Enclosure

Package

Add protocol

Color

logo

sharp

logo

appearance

design

01

02

03

04

Other protocol

Threshold value

slide24

1

7

Thank you!

2

0

To get more information about our dealers, distributors & partners and for placing bulk orders, please contact

www.thinkrace.com
