  1. Gwynneth Davidoff, Kendall Pletcher, Mary Schmidt, Amy Whitcombe MXS controljuly 6, 2010

  2. Progress • PIC code for LED: • Right now, we can set LED voltages to loop through; output starts/stops when specified; delays a user-specified amount of time • Time resolution improved from 3 ms to 25 us • Need to improve storage – Keith wants around 250 data points, we have 50 now • Tested 2 PICs with USB connection • PCB outline • GUI progress: • ASCII file running, saving HK to file in format specified by Keith, all HK information = set up • Started constant updating

  3. Next steps • Test GUI with PIC together • Order PCB • Get MCA GUI working  testing
