Presentation Transcript
slide11

3D Depth Sensors

Microphone Array

Motorized Tilt

RGB Camera

slide12

openkinect.org

www.openni.org

kinectforwindows.org

slide14

Xbox Kinect

You’ll need this

That’s not USB

slide16

Demo 0

Hello Tilt

slide17

BGR32 Format

Byte Array:

4 Bytes Per pixel

Stride= Bytes Per Row

= bytes per pixel * width

= 4 * width

width in pixels

height in pixels

slide18

Demo 1

Hello Colorful World

slide19

Depth data

500mm

500mm

500mm

500mm

500mm

500mm

500mm

2500mm

2000mm

2000mm

2030mm

2010mm

slide20

Depth data

Max resolution for raw depth data is 640 x 480

2 bytes per pixel of depth data (short)

  • 000

00001

11101010

11011110

00001

11101010

  • 000
  • 000

00000

pixel

pixel

pixel

depthInMM = pixel >> DepthImageFrame.PlayerIndexBitmaskWidth

slide21

Demo 2

Depth

slide22

Depth + Player Data

SkeletonStream.Enable();

player 1

player 1

player 1

player 1

500mm

500mm

500mm

500mm

player 1

player 1

player 1

500mm

500mm

500mm

2500mm

2000mm

2000mm

2030mm

2010mm

var player = pixel & DepthImageFrame.PlayerIndexBitmask;

11011110

00001

  • 010
slide23

Demo 3

Depth + Player Data

slide25

from skeleton inskeletonFrame.Skeletons

whereskeleton.TrackingState == SkeletonTrackingState.PositionOnly

skeletonFrame.Skeletons

skeletonFrame.Skeletons

whereskeleton.TrackingState == SkeletonTrackingState.Tracked

slide26

hand_right

hand_left

head

wrist_right

wrist_left

shoulder_center

elbow_left

elbow_right

shoulder_left

shoulder_right

Skeleton.Joints[JointType]

spine

hip_right

hip_left

hip

center

Joint.Position (X,Y,Z)

Skeletons are mirrored

X, Y, Z in meters

Origin(0,0,0) = center of camera.

+Z is out

+X is to the right

+Y is up

knee_right

knee_left

ankle_right

ankle_left

foot_left

foot_right

slide27

Demo 3

Skeletal Tracking

slide28

Composites

+

+

Color

slide29

Composites

Color

+

MapSkeletonPointToColor

MapDepthToColorImagePoint

Color

+

MapDepthFrameToColorFrame

MapDepthToSkeletonPoint

+

MapSkeletonPointToDepth

slide30

Demo 4

Green Screen

slide34

Echo Cancellation

  • EchoCancellationMode: None, CancellationOnly, CancellationAndSuppression
  • intEchoCancellationSpeakerIndex: Index of speaker to cancel
slide36

Noise Supression

  • boolNoiseSuppression – true, false
slide38

Automatic Gain Control

  • boolAutomaticGainControl– true, false
slide40

Beam Forming

0.875 radians

50 degrees

-0.875 radians

-50 degrees

.0175 radians

10 degrees

slide41

Demo 5

Speech Recognition

slide42

Audio @!%!#!! Gotchas

Must run in an MTA

AEC SystemModes crash if no speaker output.

Use Microsoft.Speech not System.Speech

DevicePairGuid / Qualitymetrics= crash

Should run in ThreadMode Priority Highest?

Must plug Kinect into Wall

slide43

Demo 6

Beam Forming

slide44

Kinect SDK 1.5!

Seated Skeletal Tracking

Kinect Studio

Face Tracking

Joint Rotation
