integrating security roles into microsoft silverlight applications
DEV356

Integrating Security Roles into Microsoft Silverlight Applications

Dan Wahlin

Wahlin Consulting

agenda
Agenda
  • Silverlight Security Options
  • Accessing User Identity Information
  • Accessing User Roles
  • Creating a SecurityManager class
silverlight security options
Silverlight Security Options
  • Silverlight Authentication:
    • Windows
    • Forms
    • Custom
  • Silverlight Authorization:
    • Active Directory Groups
    • Forms Roles
    • Custom Roles
windows authentication options
Windows Authentication Options
  • Option 1: Secure page hosting Silverlight control
    • Easiest
    • User prompted
    • Silverlight app secured
  • Option 2: Secure backend services
    • Silverlight app is anonymous
    • Calls to service require credentials
    • Client HTTP stack can be used
using the client http stack
Using the Client HTTP Stack
  • //Set once in App.xaml.cs
  • HttpWebRequest.RegisterPrefix("https://", WebRequestCreator.ClientHttp);
  • ....
  • WebClientwc = new WebClient();
  • wc.UseDefaultCredentials = false;
  • wc.Credentials = new NetworkCredential("username", "password", "domain");
agenda6
Agenda
  • Securing Silverlight Applications
  • Accessing User Identity Information
  • Accessing User Roles
  • Creating a SecurityManager class
accessing a user s credentials
Accessing a User's Credentials
  • Silverlight does not support accessing the User object directly
    • User.Identity.Name
  • Options for accessing the user name:
    • initParams (be careful!)
    • Use a service
    • WCF RIA Services
passing the user name with initparams
Passing the User Name with initParams
  • User Name can be passed dynamically into Silverlight using initParams

Be Careful!

using initparams
Using initParams

<param name="initParams" value="UserName=<%=User.Identity.Name%>" />

private void Application_Startup(object sender, StartupEventArgs e) {

ProcessInitParams(e.InitParams);

this.RootVisual = new MainPage();

}

void ProcessInitParams(IDictionary<string, string> initParams) {

if (initParams != null) {

foreach (var item in initParams) {

this.Resources.Add(item.Key, item.Value);

}

}

}

creating a user credentials service
Creating a User Credentials Service
  • Create a User Credentials WCF/ASMX service:
    • Service handles returning authenticated user's information
    • No risk of a spoofed User Name as with initParams
    • Service can return additional information such as roles
    • WCF RIA Services does this out-of-the-box
returning a user name from a service
Returning a User Name from a Service

[OperationContract]

public string GetLoggedInUserName() {

return new SecurityRepository() .GetUserName(OperationContext.Current);

}

public class SecurityRepository {

public string GetUserName(OperationContextopContext) {

return (opContext.ServiceSecurityContext != null &&

opContext.ServiceSecurityContext.WindowsIdentity != null) ? opContext.ServiceSecurityContext.WindowsIdentity.Name : null;

}

}

agenda13
Agenda
  • Silverlight Security Options
  • Accessing User Identity Information
  • Accessing User Roles
  • Creating a SecurityManager class
accessing user roles
Accessing User Roles
  • Options:
    • Pass user roles into application using initParams
    • Create a security service operation that returns roles

Be Careful!

returning roles from a service
Returning Roles from a Service

[OperationContract]

public List<Role> GetRoles()

{

return new SecurityRepository().GetRoles(OperationContext.Current);

}

public class SecurityRepository {

public List<Role> GetRoles(OperationContextopContext)

{

varuserName = GetUserName(opContext);

//Get roles from Active Directory, Database, or elsewhere

}

}

agenda17
Agenda
  • Silverlight Security Options
  • Accessing User Identity Information
  • Accessing User Roles
  • Creating a SecurityManager class
creating a securitymanager class
Creating a SecurityManager Class
  • SecurityManager class can act as client-side gateway to user credentials:
    • Accesses user credentials asynchronously
    • Determine user role(s)
    • Determine access to view
    • MVVM compliant
    • Add to ViewModel base class through aggregation
the securitymanager class
The SecurityManager Class

[Export(typeof(ISecurityManager))]

[PartCreationPolicy(CreationPolicy.Shared)]

public class SecurityManager : ISecurityManager {

public event EventHandlerUserSecurityLoaded;

public boolIsUserSecurityLoadComplete { get; set; }

public ObservableCollection<Role> UserRoles { get; set; }

public string UserName { get; set; }

public boolIsAdmin { get; }

public boolIsInUserRole { get; }

public boolIsValidUser { get; }

private void GetUserSecurityDetails() {}

public boolCheckUserAccessToUri(Uri uri) {}

public boolUserIsInRole(string role) {}

public boolUserIsInAnyRole(params string[] roles) {}

}

using the securitymanager class
Using the SecurityManager Class

public class ViewModelBase: INotifyPropertyChanged { [Import]

public ISecurityManagerSecurityManager { get; set; }

}

public class MainPageViewModel : ViewModelBase {

public MainPageViewModel() {

if (!IsDesignTime) SecurityManager.UserSecurityLoaded += SecurityManagerUserSecurityLoaded;

}

void SecurityManagerUserSecurityLoaded(object sender, EventArgs e) {

IsAdmin = SecurityManager.IsAdmin; //Set INPC property

UserName = SecurityManager.UserName; //Set INPC property

}

}

summary
Summary
  • Silverlight doesn’t provide direct access to user credentials
  • Different techniques can be used to access a user name and roles:
    • Pass into initParams (be careful!)
    • Access data through a security service
    • Use WCF RIA Service's WebContext class
  • The SecurityManager class can simplify the process of working with user credentials
    • Handles async calls to security service
    • Stores user credentials and provides security logic
    • Integrates well with MVVM
