    1. SuperJANET5 RNO installation guide Roland Trice SuperJANET 5 Rollout Manager

    2. 8th February 2006 SJ5 Rollout 2 RNEP Requirements paper E-mailed to MANS list Describes installation details Readiness certificate Does not need signing E-mail to Verizon (Eddie Holloway) Electrical test certificate Will need a signature Some copies available today

    3. 8th February 2006 SJ5 Rollout 3 Racks Verizon will not re-use existing racks Insufficient battery capacity Risk of service disruption Installation and decommissioning

    4. 8th February 2006 SJ5 Rollout 4 Standard Rack Build New rack 600mm square 2200mm tall Unless physically impossible Four hour battery stack Unless specifically declined Cable access from beneath the floor Unless there is no false floor New fibre will be installed at both RNEPs

    5. 8th February 2006 SJ5 Rollout 5 Power RNEP to provide 16 amp commando socket* 20 amp type-D MCB at the EDU Ensures breakers in the rack trip before those in the EDU

    6. 8th February 2006 SJ5 Rollout 6 Power Building earth bonding point Rack will be earthed to this point RNEP must provide an electrical test certificate Conformant to 16th edition of IEE regulations Good general level of lighting

    7. 8th February 2006 SJ5 Rollout 7 Standard Rack Build A fully loaded cabinet weighs 211Kg, Cabinet shell and sides 110 Kg Eaton APS 3 rectifier 35 Kg 4 batteries 50 Kg Ciena CN4200 10.5 Kg Optical patch panel 5 Kg

    8. 8th February 2006 SJ5 Rollout 8 CN 4200 environmental specs Ambient Temperature +5o C to +50o C; Relative Humidity 5% to 85% (non-condensing) Cooling available for maximum 375 W Power consumption between 5-11 amps

    9. 8th February 2006 SJ5 Rollout 9 CN 4200 optical presentation All SDH links present as: Single-mode fibre 1330 nm Short Reach FC/PC connectors All GE links present as: Multi-mode fibre 850 nm SC/PC connectors

    10. 8th February 2006 SJ5 Rollout 10 Connections Production IP service 10 Gbit/s or 2.5 Gbit/s SDH Other Production Services GE UKLight equipment to UKLight Core 10 Gbit/s SDH Other research bandwidth GE

    11. 8th February 2006 SJ5 Rollout 11 Other equipment Some RNEPs will continue to house other JANET equipment UKLight Metro Director or 3600 Small services router Servers OOB router Power management system One or two RNEPs may gain new kit Need to rationalise this equipment

    12. 8th February 2006 SJ5 Rollout 12 Other equipment Please tell me about the JANET kit you have Where it is How many racks it is in How much space it occupies within the racks Rack layouts would be really good ? Aim to minimise the space we use NOSC will liaise with individual RNOs

    13. 8th February 2006 SJ5 Rollout 13 Post installation Link acceptance testing Will be performed by the NOSC Will test to loopback at R-PoP Verizon will leave all active circuits looped back Loopback cable useful for future testing or new provision QA by Verizon and RNO after installation Your chance to ensure your facility is left as you want it

    14. 8th February 2006 SJ5 Rollout 14 R-PoP issues Site surveys Verizon will be arranging for Feb/March Verizon will compile site report for RNO & UKERNA Wayleaves THE major hassle in SJ4 Please warm up your estates people now Problems (Great Crested Newts) Tell me as soon as possible

    15. 8th February 2006 SJ5 Rollout 15 The culprit

    16. Questions?
