  1. Access Control Lists (ACL)

  2. Access-List Overview • A Filter through which all traffic must pass • Used to Permit or Deny Access to Network • Provides Security • Bandwidth Management • Come in two flavors • STANDARD AND EXTENDED

  3. What is an Access-List • A List of Criteria to which all Packets are compared. • Is this Packet from Network 10.5.2.0 • Yes - Forward the Packet • No - Check with Next Statement • Is this a Telnet Protocol Packet from 25.25.0.0 • Yes - Forward the Packet • No - Check Next Statement • Deny All Other Traffic

  4. How an Access-List Works • Packets are compared to Each Statement in an Access-list SEQUENTIALLY - From the Top Down. • The sooner a decision is made the better. • Well written Access-lists take care of the most abundant type of traffic first. • All Access-lists End with an Implicit Deny All statement

  5. Standard Access Lists • Are given a # from 1-99 • Filtering based only on Source Address • Should be applied closest to the Destination

  6. Extended Access-lists • Are given a # from 100-199 • Much more flexible and complex • Can filter based on: • Source address • Destination address • Session Layer Protocol (ICMP, TCP, UDP..) • Port Number (80 http, 23 telnet…) • Should be applied closest to the Source

  7. Two Steps - Create and Apply • Step 1 - Create the Access-list • access-list #permit/denysource IPwildcard • # - 1-99 • permit/deny - switch the packet or drop it • source IP - source IP address to which the packet should be compared. Can also use ANY • wildcard - see next page • Step 2 -Apply the Access-list to an Interface • Must be in interface config mode (config-if)# • IP access-group # in/out (routers point of view)

  8. Wildcards • Allows you to indicate a Range of IP addresses • Two Values are Used: • 0 = Must Match Exactly • 1 = Does Not Matter

  9. Wildcard Examples Network Wildcard • 195.34.5.12 0.0.0.0 • Result: Match all four octets • Only 195.34.5.12 is a match • Could also use host 195.34.5.12 in place of the wildcard. Host indicates an exact match is needed.

  10. Wildcard Examples • Network Wildcard • 172.16.10.0 0.0.0.255 • Result: Match the first three octets exactly but ignore the last octet. • 172.16.10.0 thru 172.16.10.255 is a match since the last octet does not matter.

  11. Implementing Access-lists • Remember the Implicit Deny All at the end of each access-list. • Two Approaches: • 1. List the traffic you know you want to permit • Deny all other traffic • 2. List the traffic you want to deny • Permit all other traffic (permit any)

  12. Implementing Access-lists • You cannot selectively add or remove statements from an Access-list • Typically modifications are made in a text editor and then pasted to the router as a new access-list. The new access list is then applied and the old one removed • Document your Access-list • After each line indicate exactly what that line is supposed to do.

  13. Implementing Access-lists • Verifying Your Access-list • Show Access-lists • Show IP Interfaces • Revisit your access-list after a few days • Routers keep track of the number of packets that match each statement in an access-list • Use this information to reorder your access-list and thus improve it efficiency • Never remove an access-list that is applied to a port - this can crash a router.

  14. Summary: Access-Lists • Are Created and then Applied to an interface • Are Implemented Sequentially- Top Down • End with an implicit Deny ALL statement • #1-99 Standard and # 100-199 Extended • Standard - source address only • Extended - source, destination, protocol, port
