  1. Start Request for NSN Assignment and or Registration of User Has R/N been superseded by another R/N? Yes Technician receives cataloging request for NSN assignment No Technician screens R/N to see if NSN is assigned Is R/N valid per manufacturer? Technician uses all cataloging tools and/or contacts the manufacturer to verify the R/N and obtain technical data Yes Is technical data available? Yes Is NSN assigned? No No No Technician classifies item (INC, FSC, FIIG) Yes Technician analyzes technical data Is submitter recorded as user on NSN? Technician prepares LAU transaction No Technician prepares LNK, LNC or LNR transaction and processed by FLIS Yes Technician returns request to submitter Did output KNA? No Technician analyzes and corrects/resubmits transaction End Yes End
