1. Assuntos para 2o exercícioMétodos de Computação Inteligente1o semestre de 2002 Jacques Robin CIn-UFPE

2. Assuntos para o 2o exercício • Tema do 2o exercício: sistemas especialistas • Leitura: capítulos 15 e 16 de Prolog Programming for Artificial Intelligence, 3rd Ed. de Ivan Bratko • Tarefas: • Implementar um shell de sistema especialista com funcionalidades de: • Máquina de inferência • Aquisição interativa de conhecimento • Justificação das perguntas de aquisição • Explicação de raciocínio • Implementar uma base de conhecimento brinquedo na linguagem de representação do conhecimento aceita pelo shell • Testar o shell com essa base de conhecimento • Equipes de 4 alunos

3. Assuntos para o 2o exercício • Sistema especialista baseado em redes bayesianas em Prolog, Flora, JEOPS ou Java • Sistema especialista combinando encadeamento de regras para frente e para trás em Prolog, Flora, JEOPS ou Java • Sistema especialista combinado frames com regras encadeadas para frente em Prolog ou Java • Sistema especialista combinado frames com regras encadeadas para trás em Prolog ou Java • 2 equipes podem escolher o mesmo assunto, do momento que escolhem duas linguagens de programação diferentes

4. Codificação da base de fatos fact(TermoProlog). Codificação da base de regras if P1 conj ... conj Pn then C onde P1 ... Pn e C são termos Prolog conj é and ou or Codificação das consultas forward deriva todos os fatos Exemplo de base de conhecimento if hallWet and kitchenDry then leakInBathroom if hallWet and bathroonDry then problemInKitchen if windowClosed or noRain then noWaterFromOutside if problemInKitchen and noWaterFromOutside then leakInKitchen Exemplos de consulta ?- forward Derive: problemInKitchen Derive: noWaterFromOutside Derive: leakInKitchen No more facts ?- is_true(leak_in_kitchen). yes Implementação Prolog de máquina de inferência encadeando regras

5. Para frente: :- op( 800, fx, if). :- op( 700, xfx, then). :- op( 300, xfy, or). :- op( 200, xfy, and). forward :-new_derived_fact(P), !, write('Derived: '), write(P), nl,assert(fact(P)), forward ; write('No more facts'). new_derived_fact(Concl) :-if Cond then Concl, not fact(Concl), composed_fact(Cond). composed_fact(Cond) :-fact(Cond). composed_fact(Cond1 and Cond2) :- composed_fact(Cond1),composed_fact(Cond2). composed_fact(Cond1 or Cond2) :- composed_fact(Cond1);composed_fact(Cond2). Pata trás: :- op( 800, fx, if). :- op( 700, xfx, then). :- op( 300, xfy, or). :- op( 200, xfy, and). is_true( P) :-fact( P). is_true( P) :-if Condition then P, is_true( Condition). is_true( P1 and P2) :-is_true( P1),is_true( P2). is_true( P1 or P2) :-is_true( P1);is_true( P2). Implementação Prolog de máquina de inferência encadeando regras

6. Implementação Prolog de máquina de inferência encadeando regras para trás

7. Implementação Prolog de máquina de inferência baseada em frames Codificação dos triplos <frame slot value> • fatos frame(Slot,Value). • com um predicado por cada frame do domínio Codificação dos gatilhos • regras da forma: trigger(Frame,Value) :- .... • com um predicado trigger por cada gatilho do domínio Associação dos triplos <frame slot trigger> • fatos frame(Slot, execute(gatilho(Frame,Value), Frame,Value)). • um por par <frame trigger> do domínio Codificação das consultas • calcular valor de um slot de um framevalue(Frame, Slot,Value)

8. Hierarquia de conceitos: bird(a_kind_of, animal). albatross(a_kind_of, bird). kiwi(a_kind_of, bird). Propriedades dos conceitos e default das suas especializações e instâncias: bird(moving_method, fly). bird(active_at, daylight). albatross(colour, black_and_white). albatross(size, 115). kiwi(size, 40). kiwi(colour, brown). Instâncias de conceitos: albert(instance_of, albatross). ross(instance_of, albatross). Sobrescrita de propriedades default: kiwi(moving_method, walk). kiwi(active_at, night). albert(size, 120). ross(size, 40). Gatilho: animal(relative_size, execute(relative_size(Object, Value), Object, Value) ). relative_size(Object,RelativeSize) :- value(Object,size,Objsize), value(Object,instance_of,ObjClass), value(ObjClass,size,ClassSize), RelativeSize is ObjSize/ClassSize * 100. Exemplo de consultas ?- value(ross,moving_method,M). M = fly. ?- value(ross,relative_size,R) R = 34.78. Implementação Prolog de máquina de inferência baseada em frames

9. % Valor declarada no próprio frame: value(Frame,Slot,Value) :- value(Frame,Frame,Slot,Value). % Valor herdada do super conceito imediato: value(Frame,SuperFrame,Slot,Value) :- Query =.. [SuperFrame,Slot,Information], call(Query), process(Information,Frame,Value), !. % Valor herdada de conceitos mais altos na hierarquia: value(Frame,SuperFrame,Slot,Value) :- parent(SuperFrame,ParentSuperFrame), value(Frame,ParentSuperFrame,Slot,Value). % Acessar super-conceito na hierarquia: parent(Frame,ParentFrame) :- (Query =.. [Frame,a_kind_of,ParentFrame] ; Query =.. [Frame,instance_of,ParentFrame]), call(Query). % Information é derivada por um gatilho process(execute(Goal,Frame,Value),Frame,Value) :- !, call(Goal). % Information é um valor declarado process(Value,_,Value). Implementação Prolog de máquina de inferência baseada em frames

10. Codificação da estrutura da rede predicado parent(ParentNode, Node) Codificação das probabilidades da rede predicado p(Node, PriorProbability) predicado p(Node, ListOfParentNodeValues, ConditionalProbability)i.e., p(N0 | N1 ...  Nn) Codificação das consultas a rede predicado probs(Node, ListOfNodeValues ConditionalProbability)i.e., p(N0 | N1 ...  Nn) Exemplo de rede: parent(burglary, sensor). parent(lightning, sensor). parent(sensor, alarm). parent(sensor, call). p(burglary, 0.001). p(lightning, 0.02). p(sensor, [ burglary, lightning], 0.9). p(sensor, [ burglary, not lightning], 0.9). p(sensor, [ not burglary, lightning], 0.1). p(sensor, [ not burglary, not lightning], 0.001). p(alarm, [ sensor], 0.95). p(alarm, [ not sensor], 0.001). p(call, [ sensor], 0.9). p(call, [ not sensor], 0.0). Exemplo de consulta: ?- prob(burglary, [call, not lightning], P). P = 0.473934 Implementação Prolog de máquina de inferência baseada redes bayesianas

11. prob([X | Xs], Cond, P) :- !, prob(X, Cond, Px), prob(Xs, [X | Cond], PRest),P is Px * PRest. prob([], _, 1) :- !. prob(X, Cond, 1) :-member(X, Cond), !. prob(X, Cond, 0) :-member(not X, Cond), !. prob(not X, Cond, P) :- !, prob(X, Cond, P0),P is 1 - P0. prob(X, Cond0, P) :-delete(Y, Cond0, Cond), predecessor(X, Y), !, prob(X, Cond, Px), prob(Y, [X | Cond], PyGivenX), prob(Y, Cond, Py), P is Px * PyGivenX / Py. prob(X, Cond, P) :-p(X, P), !. % Coloca prob(X, Cond, P) :- !, findall((CONDi,Pi), p(X,CONDi,Pi), CPlist), sum_probs(CPlist, Cond, P). % Calcula p(X|Cond) como somatórios nos % predecessores Si de X na rede de % p(X|Si)*p(Si|Cond) sum_probs([], _, 0). sum_probs([(COND1,P1)|CondsProbs], COND, P) :-prob(COND1, COND, PC1), sum_probs(CondsProbs, COND, PRest), P is P1 * PC1 + PRest. % Busca por predecessores subindo na rede predecessor(X, not Y) :- !, predecessor(X, Y). predecessor(X, Y) :-parent(X, Y). predecessor(X, Z) :-parent(X, Y), predecessor(Y, Z). % Predicados utilitários member(X, [X | _]). member(X, [_ | L]) :-member(X, L). delete(X, [X | L], L). delete(X, [Y | L], [Y | L2]) :-delete(X, L, L2). Implementação Prolog de máquina de inferência baseada redes bayesianas

12. Implementação Prolog de shell de sistema especialista encadeando regras para trás Codificação das regras para o shell: • RuleName :: if Condition then Conclusion, • onde: • Condition é um termo Prolog • Conclusion são termos Prolog conectados por and, or ou not Codificação dos fatos para o shell: • fact :: ShellFact • onde: ShellFact é um fato Prolog ou uma regras Prolog Sintaxe natural: • Operadores Prolog podem ser usados para definir propriedades podem ser definidos e aparecer nas regras e fatos do shell para tornar a aparência da base de conhecimento “mais natural” Aquisição interativa dos fatos via o shell: • askable(Term) indica que o termo Prolog Term é um dos fatos do shell cujo valor (os valores das suas variáveis não instanciadas) pode ser pedido para o usuário durante o raciocínio

13. Implementação Prolog de shell de sistema especialista encadeando regras para trás % Operadores de ‘sintaxe natural’ :- op( 100, xfx, [ has, gives, 'does not', eats, lays, isa]). :- op( 100, xf, [ swims, flies]). % Base de regras rule1 :: ifAnimal has hairorAnimal gives milkthenAnimal isa mammal. rule2 :: ifAnimal has feathersor (Animal flies and Animal lays eggs) thenAnimal isa bird. rule3 :: ifAnimal isa mammal and(Animal eats meator (Animal has 'pointed teeth' and Animal has claws and Animal has 'forward pointing eyes' ) thenAnimal isa carnivore. rule4 :: ifAnimal isa carnivore andAnimal has 'tawny color'andAnimal has 'dark spots' thenAnimal isa cheetah. rule5 :: ifAnimal isa carnivore andAnimal has 'tawny color'andAnimal has 'black stripes' thenAnimal isa tiger. rule6 :: ifAnimal isa bird andAnimal 'does not' fly andAnimal swimsthenAnimal isa penguin. rule7 :: ifAnimal isa bird andAnimal isa 'good flyer'thenAnimal isa albatross. % Base de fatos fact :: X isa animal :-member( X, [cheetah, tiger, penguin, albatross]). askable( _ gives _, 'Animal' gives 'What').askable( _ flies, 'Animal' flies). askable( _ lays eggs, 'Animal' lays eggs).askable( _ eats _, 'Animal' eats 'What'). askable( _ has _, 'Animal' has 'Something').askable( _ 'does not' _, 'Animal' 'does not' fly). askable( _ swims, 'Animal' swims).askable( _ isa 'good flyer', 'Animal' isa 'good flyer'). member(X,[X | _]). member( X, [_ | Rest]) :- member( X, Rest).

14. Implementação Prolog de shell de sistema especialista encadeando regras para trás % Base de regras broken_rule ::ifon(Device) anddevice( Device) and(not working(Device)) andconnected( Device, Fuse) andproved( intact( Fuse)) thenproved( broken( Device)). fuse_ok_rule ::ifconnected( Device, Fuse) andworking( Device)thenproved( intact( Fuse)). fused_rule ::ifconnected( Device1, Fuse) andon( Device1) and(not working( Device1)) andsamefuse( Device2, Device1) andon( Device2) and(not working( Device2)) thenproved( failed( Fuse)). same_fuse_rule ::ifconnected( Device1, Fuse) andconnected( Device2, Fuse) anddifferent( Device1, Device2) thensamefuse( Device1, Device2). device_on_rule ::ifworking( Device)thenon( Device). % Base de fatos fact :: different( X, Y) :- not (X = Y). fact :: device( heater).fact :: device( light1).fact :: device( light2).fact :: device( light3). fact :: device( light4). fact :: connected( light1, fuse1).fact :: connected( light2, fuse1).fact :: connected( heater, fuse1). fact :: connected( light3, fuse2).fact :: connected( light4, fuse2). askable( on(D), on('Device')).askable( working(D), working('Device')).

15. Question, please: peter isa tiger. Is it true: peter has hair? yes. Is it true: peter eats meat? no. Is it true: peter has pointed teeth? yes. Is it true: peter has claws? why. To investigate, by rule3, peter is a carnivore To investigate, by rule 5, peter is a tiger This was your question. Is it true: peter has claws? yes. Is it true: peter has forward pointing eyes? yes. Is it true: peter has tawny colour? yes. Is it true: peter has black stripes? yes. (peter is a tiger) is true Would you like to see how? yes. peter is a tiger was derived by rule5 from peter isa carnivore was derived by rule3 from peter is mamamal was derived by rule1 from peter has hair was told and peter has pointed teeth was told and peter has claws was told and peter has forward pointing eyes was told and peter has tawny color was told and peter has black stripes was told Question, please: Implementação Prolog de shell de sistema especialista encadeando regras para trás

16. Predicados principais: expert: dispara o sistemas especialista explore(Goal,Trace,Answer): dispara encadeamento de regras para trás para tentar provar objetivo Goal guarda em Trace a lista dos objetivos intermediários que foram provados, junto a regra utilizada para prova cada um guarda em Answer a árvore da prova de Goal useranswer(Goal,Trace,Answer): caso Goal for askable, pergunta Goal para o usuário caso a resposta a essa pergunta for yes or no, instância Answer com essa resposta caso a resposta a essa pergunta for why, apresenta Trace como respota usa getreply(Reply) para recuperar de maneira robusta a resposta do usuário present(Answer): apresenta Answer para o usuário como resposta a perguntas de tipo how? Implementação Prolog de shell de sistema especialista encadeando regras para trás

17. % Operadores do shell :- op( 900, xfx, ::). :- op( 800, xfx, was). :- op( 870, fx, if). :- op( 880, xfx, then). :- op( 550, xfy, or). :- op( 540, xfy, and). :- op( 300, fx, 'derived by'). :- op( 600, xfx, from). :- op( 600, xfx, by). :- op( 900, fy, not). % Predicado driver do shell expert :-getquestion(Question), (answeryes(Question);answerno( Question)). getquestion(Question) :-nl, write( 'Question, please '),nl,read( Question). answeryes(Question) :- markstatus( negative), explore( Question, [], Answer), positive( Answer), markstatus( positive),present( Answer), nl, write('More solutions? '), getreply( Reply), Reply = no. answerno( Question) :- retract(no_positive_answer_yet),!, explore( Question, [], Answer),negative( Answer), present( Answer), nl, write('More negative solutions? '), getreply( Reply),Reply = no. markstatus( negative) :- assert(no_positive_answer_yet). markstatus( positive) :- retract(no_positive_answer_yet),!; true. Implementação Prolog de shell de sistema especialista encadeando regras para trás

18. explore(Goal,Trace, _) :-copy_term( Goal, Copy),member( Copy by Rule, Trace), instance_of( Copy, Goal), !, fail. explore(Goal,Trace,Goal is true was 'found as a fact'):-fact :: Goal. explore(Goal,Trace,Goal is TruthValuewas 'derived by'Rule from Answer) :- Rule :: if Condition then Goal,explore( Condition, [Goal by Rule | Trace], Answer), truth( Answer, TruthValue). explore( Goal1 and Goal2, Trace, Answer) :- !,explore( Goal1, Trace, Answer1), continue( Answer1, Goal1 and Goal2, Trace, Answer). explore( Goal1 or Goal2, Trace, Answer) :-exploreyes( Goal1, Trace, Answer) ; exploreyes( Goal2, Trace, Answer). explore( Goal1 or Goal2, Trace, Answer1 and Answer2) :- !,not exploreyes( Goal1, Trace, _), not exploreyes( Goal2, Trace, _), explore( Goal1, Trace, Answer1), explore( Goal2, Trace, Answer2). explore( not Goal, Trace, Answer) :- !, explore( Goal, Trace, Answer1),invert( Answer1, Answer). explore( Goal, Trace, Goal is Answer was told) :-useranswer( Goal, Trace, Answer). Implementação Prolog de shell de sistema especialista encadeando regras para trás

19. exploreyes( Goal, Trace, Answer) :-explore( Goal, Trace, Answer),positive( Answer). continue( Answer1, Goal1 and Goal2, Trace, Answer) :- positive( Answer1),explore( Goal2, Trace, Answer2), (positive( Answer2), Answer = Answer1 and Answer2;negative( Answer2), Answer = Answer2 ). continue( Answer1, Goal1 and Goal2, _, Answer1) :-negative( Answer1). truth( Question is TruthValue was Found, TruthValue) :- !. truth( Answer1 and Answer2, TruthValue) :-truth( Answer1, true),truth( Answer2, true), !, TruthValue = true;TruthValue = false. positive( Answer) :-truth( Answer, true). negative( Answer) :- truth( Answer, false). invert( Quest is true was Found, (not Quest) is false was Found). invert( Quest is false was Found, (not Quest) is true was Found). instantiated( Term) :-numbervars(Term, 0, 0). Implementação Prolog de shell de sistema especialista encadeando regras para trás

20. useranswer( Goal, Trace, Answer) :-askable( Goal, _), freshcopy( Goal, Copy), useranswer( Goal, Copy, Trace, Answer, 1). useranswer( Goal, _, _, _, N) :-N > 1, instantiated( Goal), !,fail. useranswer( Goal, Copy, _, Answer, _) :-wastold( Copy, Answer, _),instance_of( Copy, Goal), !. useranswer( Goal, _, _, true, N) :-wastold( Goal, true, M),M >= N. useranswer( Goal, Copy, _, Answer, N) :-end_answers( Copy),instance_of( Copy, Goal), !, not wastold( Goal, _, _), Answer = false. useranswer( Goal, _, Trace, Answer, N) :-askuser( Goal, Trace, Answer, N). askuser( Goal, Trace, Answer, N) :-askable( Goal, ExternFormat), format( Goal, ExternFormat, Question, [], Variables), ask( Goal, Question, Variables, Trace, Answer, N). ask( Goal, Question, Variables, Trace, Answer, N) :-nl, ( Variables = [], !,write( 'Is it true: ');write( 'Any (more) solution to: ')), write( Question), write('? '), getreply( Reply), !, process( Reply, Goal, Question, Variables, Trace, Answer, N). Implementação Prolog de shell de sistema especialista encadeando regras para trás

21. process( no, Goal, _, _, _, false, N) :-freshcopy( Goal, Copy),wastold( Copy, true, _), !, assertz( end_answers( Goal)), fail;nextindex( Next), assertz( wastold( Goal, false, Next)). format( Var, Name, Name, Vars, [Var/Name|Vars]) :-var( Var), !. format( Atom, Name, Atom, Vars, Vars) :- atomic( Atom), !,atomic( Name). format( Goal, Form, Question, Vars0, Vars) :-Goal =.. [Functor|Args1],Form =.. [Functor|Forms], formatall( Args1, Forms, Args2, Vars0, Vars),Question =.. [Functor|Args2], !. format( Goal, _, Question, Vars0, Vars) :-format( Goal, Goal, Question, Vars0, Vars). formatall( [], [], [], Vars, Vars). formatall( [X|XL], [F|FL], [Q|QL], Vars0, Vars) :-formatall( XL, FL, QL, Vars0, Vars1), format( X, F, Q, Vars1, Vars). askvars( []). askvars( [Variable/Name|Variables]) :-nl, write( Name), write( ' = '), read( Variable),askvars( Variables). showtrace([]) :-nl, write('This was your question'), nl. showtrace( [Goal by Rule | Trace]) :-nl, write( 'To investigate, by '),write( Rule), write( ', '), write( Goal),showtrace( Trace). Implementação Prolog de shell de sistema especialista encadeando regras para trás

22. instance_of( Term, Term1) :-copy_term( Term1, Term2), numbervars( Term2, 0, _), !,Term = Term2. freshcopy( Term, FreshTerm) :- asserta( copy( Term)),retract( copy( FreshTerm)), !. nextindex( Next) :- retract( lastindex( Last)), !,Next is Last + 1,assert( lastindex( Next)). :- assert( lastindex( 0)),assert( wastold( dummy, false, 0)),assert( end_answers( dummy)). Implementação Prolog de shell de sistema especialista encadeando regras para trás

23. present( Answer) :-nl, showconclusion( Answer),nl, write( 'Would you like to see how?'), nl, getreply( Reply),( Reply = yes, !, show( Answer);true ). showconclusion( Answer1 and Answer2) :- !,showconclusion( Answer1), write( ' and '), showconclusion( Answer2). showconclusion( Conclusion was Found) :-write( Conclusion). show( Solution) :-nl, show( Solution, 0), !. show( Answer1 and Answer2, H) :- !, show( Answer1, H),tab( H), write(and), nl,show( Answer2, H). show( Answer was Found, H) :-tab( H), writeans( Answer), nl, tab( H),write( ' was '),show1( Found, H). show1( Derived from Answer, H) :- !,write( Derived), write(' from'), nl, H1 is H + 4,show( Answer, H1). show1( Found, _) :-write( Found), nl. writeans( Goal is true) :- !,write( Goal). writeans( Answer) :- write( Answer). getreply(Meaning) :-read( Reply),means( Reply, Meaning), !; nl, write('Answer unknown, try again please!'), nl, getreply( Meaning). Implementação Prolog de shell de sistema especialista encadeando regras para trás

24. means( why, why) :- !. means( w, why) :- !. means( yes, yes) :- !. means( y, yes) :- !. means( no, no) :- !. means( n, no) :- !. member( X, [X|_]). member( X, [_|L]) :-member( X, L). numbervars( Term, N, Nplus1) :-var( Term), !, Term = var/N,Nplus1 is N + 1. numbervars( Term, N, M) :-Term =.. [Functor | Args],numberargs( Args, N, M). numberargs( [], N, N) :- !. numberargs( [X | L], N, M) :-numbervars( X, N, N1),numberargs( L, N1, M). Implementação Prolog de shell de sistema especialista encadeando regras para trás
