Presentation Transcript
slide1

::ICS 804::

Theory of Computation

- Ibrahim Otieno -

iotieno@uonbi.ac.ke

+254-0722-429297

SCI/ICT Building Rm. G15

course outline
Course Outline
  • Mathematical Preliminaries
  • Turing Machines
  • Recursion Theory
  • Markov Algorithms
  • Register Machines
  • Regular Languages and finite-state automata
  • Aspects of Computability
last time turing machines
Last Time: Turing Machines
  • What is Computation?
  • Informal Description of Turing Machines
  • Formal Description of Turing Machines
  • Turing Machines as Language acceptors and Language recognizers
  • Turing Machines as Computers of number-theoretic functions
  • Modular Turing Machines
  • Complexity Theory
course outline1
Course Outline
  • Mathematical Preliminaries
  • Turing Machines
    • Additional Varieties of Turing Machines
  • Recursion Theory
  • Markov Algorithms
  • Register Machines
  • Regular Languages and finite-state automata
  • Aspects of Computability
additional varieties of turing machines
Additional Varieties of Turing Machines
  • Turing Machines with One-Way-Infinite tape
  • Turing Machines that accept by terminal state
  • Multitape Turing Machines
  • Encoding of Turing Machines
  • Universal Turing Machines
  • Nondeterministic Turing Machines
  • Turing-Computability
  • Turing Machines and Artificial Intelligence
  • Turing Machines and Cognitive Science
tapes
Tapes
  • So far: Turing machines with two-way infinite tape
  • Turing (1936): one-way infinite tape
  • No difference in computational power
  • A function Turing computable in a 2-way infinite tape setup is also Turing computable with a 1-way infinite tape
turing machines with one way infinite tape1
Turing Machines with One-Way-Infinite Tape
  • Machine tape infinite only to the right
  • Leftmost tape square containing left endmarker  (use , in Deus Ex Machina)
  • What happens on reaching left most square?
  • One-way function computation
  • One-way language acceptance (recognition)
equivalence result
Equivalence Result
  • Central to theory of computability
  • Let f be a k-ary number-theoretic function:
  • Then there exists a Turing Machine with two-way-infinite tape that two-way computes f if and only if there exists a Turing machine with one-way-infinite tape that one-way computes f
acceptance recap
Acceptance (Recap)
  • Word acceptance:

Deterministic Turing Machine M accepts nonempty word w if, when started scanning the leftmost symbol of w on an input tape that contains w and is otherwise blank, M ultimately halts scanning a 1 on an otherwise blank tape.

  • “Acceptance by 1”
terminal state
Terminal State
  • A single terminal state qt( “one or more”)
  • Sex-tuple Q, S, G, qinit, qt , d
    • qt Q
    • d is undefined for pairs of the form < qt , d >
    • Turing Machine M can still halt in any other state
    • Not necessarily distinct from qinit
    • Exercise: Draw a TM that accepts L = { (abc)n | n >=1} by terminal state
language acceptance by terminal state
Language Acceptance by Terminal State
  • M accepts w if halts in qt
  • M accepts language L by terminal state provided that M accepts, by terminal state, all and only the words of L
    • Tape content upon halting in state qt is not defined
    • No requirement that M has read word w completely
equivalence result1
Equivalence Result
  • Theorem: Let L be a language over alphabet S. Then there exists a Turing machine that accepts L “by 1” if and only if there exists a Turing machine that accepts L by terminal state.
  • Equivalence result: forward and reverse proof involve maintaining new end markers  and 
multitape turing machines1
Multitape Turing Machines
  • Has K+2 tapes where K >= 0
  • (Possibly read-only) input tape at top
  • (Possibly write-only) output tape at bottom
  • 0 or more worktapes in between
  • Referred to as offline TM
no worktapes
No worktapes

Initially

input tape: H11111111

output tape: HB

Ultimately halts in the configuration

input tape: H11111111 (unchanged)

output tape: H1111

worktapes
Worktapes

Initially

input tape: HababB

worktape1: HBBBBB

worktape2: HBBBBB

output tape: HBBBBB

Ultimately halts in the configuration

input tape: HababB (unchanged)

worktape1: …

worktape2: …

output tape: H1BBB

clarification
Clarification
  • Let M be a multitape Turing machine. Suppose that tape t is one of M’s k + 2tapes. In general, determination of which action is to be taken by the read/write head on tape t will depend on the symbols currently being scanned on tapes other than t and not merely on the symbol currently being scanned on tape t itself.
language acceptance
Language Acceptance

Suppose that (k+2)-tape Turing Machine M is started scanning the leftmost symbol of nonempty input word w on its input tape, which is otherwise blank initially.

Suppose all the other tapes are blank as well. Then if M halts with its first read-head scanning the leftmost symbol of w on its input tape, which is otherwise blank, and scanning a single 1 on its output tape, which is otherwise blank, then we shall say that M accepts word w

example
Example

{w *|na(w) = nb(w)}

example1
Example
  • Instructions for each tape. Often: only 1 tape is reading/writing. Other tapes: “a:a” type instructions
example2
Example
  • Copies occurrences of a unto worktape1 and occurrences of b unto worktape2. Then M ascertains whether the number of a’s on worktape1 is the same as the number of b’s on worktape2
example3
Example

Deus Ex Machina:

  • Machine: SAMNUM4T.TM
  • Try tapes 6A4BMULT.TT and 9A9BMULT.TT
example4
Example

Calculate Time complexity

Single-tape: O(n2)

Multi-tape: O(n)

parallel computation
Parallel Computation?

Let M be a multitape Turing Machine. Suppose that tape t is one of M’s k+2 tapes. In general, determination of which action is to be taken by the read/write head on tape t will depend on the symbols currently being scanned on tapes other than t and not merely on the symbol currently being scanned

  • No individual processors: no parallel computation
  • Single processor controlling multiple tape heads
exercise
Exercise
  • Develop a TM that accepts L = { (an | n is prime}
time space trade off
Time/Space trade-off

timeM(n)

spaceM(n)

  • Adding tapes increases spaceM but generally decreases timeM
equivalence results
Equivalence Results
  • Theorem A language L is accepted by some multitape Turing machine if and only if L is accepted by some single-tape Turing machine.
  • Theorem A language L is recognized by some multitape Turing machine if and only if L is recognized by some single-tape Turing machine.
another equivalence result
Another Equivalence Result
  • Theorem Similarly, a function f is computed by some multitape Turing machine if and only if it is computed by some single-tape Turing machine.
  •  always trivial
  • Proof idea for : Tape alphabet of single-tape simulator M will be large; one symbol  will represent entire “section” through tapes of multitape M´
time and space
Time and Space
  • Corollary Suppose that language L is accepted by k-tape Turing machine M. Then L is accepted by a single-tape Turing machine M1 such that timeM1(n) is O([timeM(n)]2)
  • Corollary Suppose that language L is accepted by k-tape Turing machine M. Then L is accepted by a single-tape Turing machine M´ such that spaceM´(n) is O(spaceM(n)).
off line turing machines
Off-line Turing Machines
  • Multitape machines: improved time analysis
  • Singletape machines: space analysis involves counting the number of tape squares visited over the course of a computation

 usually visit all squares of the input

 no single-tape machine will compute in less than O(n) space

encoding of turing machines1
Encoding of Turing Machines
  • Any Turing machine can be represented by a natural number code
  • ASCII-style encoding
  • Euler-Gödel encoding
ascii

a:B

q0

q1

B:R

B:1

q2

s’:s

q

q’

s:R

s:s’’

q’’

ASCII
  • Describes language {an|n0}
  • Slight changes to make it more general

<q,s’,s,q’>

<q’,s,R,q>

<q,s,s’’,q’’>

ascii1

s’:s

q

q’

s:R

s:s’’

q’’

ASCII

<q,s’,s,q’>

<q’,s,R,q>

<q,s,s’’,q’’>

  • q: is always initial state
  • Any Turing machine: finite set S of quadruples
  • We want to represent S by a single symbol string
ascii2
ASCII
  • q: is always initial state
  • Any Turing machine: finite set S of quadruples
  • We want to represent S by a single symbol string

3*2 different ways:

q,s’,s,q’;q’,s,R,q;q,s,s’’,q’’

q,s’,s,q’;q,s,s’’,q’’;q’,s,R,q

q’,s,R,q;q,s’,s,q’;q,s,s’’,q’’

q’,s,R,q;q,s,s’’,q’’;q,s’,s,q’

q,s,s’’,q’’;q’,s,R,q;q,s’,s,q’

q,s,s’’,q’’;q,s’,s,q’;q’,s,R,q

ascii3
ASCII

q,s’,s,q’;q’,s,R,q;q,s,s’’,q’’

q,s’,s,q’;q,s,s’’,q’’;q’,s,R,q

q’,s,R,q;q,s’,s,q’;q,s,s’’,q’’

q’,s,R,q;q,s,s’’,q’’;q,s’,s,q’

q,s,s’’,q’’;q’,s,R,q;q,s’,s,q’

q,s,s’’,q’’;q,s’,s,q’;q’,s,R,q

Each of these is a string over Turing Machine description alphabet , containing the seven symbols q ‘ s L R , ;

Represent each of these options as a binary digit string: associate symbols of alphabet with binary-digit strings of e.g. length 3

ascii4
ASCII

q,s’,s,q’;q’,s,R,q;q,s,s’’,q’’

001 000 010 110 000 010 000 001 110 101 001 110 000 010 000 011 000 001 101 001 000 010 000 010 000 010 110 110 000 001 110 110

= symbol code of machine M

Encode M as a natural number: ASCII code of M

= natural number denoted by the 90 digit string interpreted as a binary numeral

ascii5
ASCII
  • Turing machines will not have unique ASCII codes
  • No natural number that encodes a Turing machine will be the ASCII code of more than one Turing machine
  • Most natural numbers are not ASCII codes
  • If n is a code, then it is the code of a unique machine (retrievability property).
euler g del
Euler-Gödel
  • Based on prime decomposition

e.g. 18720 = 25.32.51.131

  • Associate each member of alphabet  with a natural number

:   {1,2,3,4,5,6,7}

euler g del1
Euler-Gödel
  • List prime numbers for each symbol and put it to the power of the function call of that symbol

22.31.53.77.111.133.171.192.237.296.312.377.411.434.471.534.591.612.676.712.731.793.831.893.977.1017.1031.1072.1097.1137.

q,s’,s,q’;q’,s,R,q;q,s,s’’,q’’

euler g del2
Euler-Gödel
  • Turing machines do not have unique Gödel numbers
  • No natural number that is the Gödel number of a Turing Machine will be the Gödel number of more than one Turing Machine
  • Given a natural number, there is a simple algorithm for determining if it is the Gödel number of a Turing Machine and which one it is
decoding
Decoding
  • 577565488500 is the alleged Gödel number of a Turing Machine
  • Prime decomposition
    • 577565488500 = 22 . 144391372125
    • 577565488500 = 22 . 31 . 48130457375
    • 577565488500 = 22 . 31 . 53 . 71 . 114 . 131 . 172
decoding1
Decoding
  • 577565488500 = 22 . 31 . 53 . 71 . 114 . 131 . 172
    • q,B,R,q

B:R

q

universal turing machines1
Universal Turing machines
  • So far: machines in a peculiar sense
  • Single program, single set of instructions
  • Change 1 instruction  change the machine
  • Can our TM be programmed to simulate behavior of any TM whatsoever?
universal turing machines2
Universal Turing machines
  • Usual sense of a machine: machine (hardware) that can run several programs (software)
  • Digital Computer: Universal Computing device that - suitably programmed (and ignoring resource limits) - can compute any function that is in principle computable
definition
Definition

Turing Machine M* is universal if, for any Turing Machine M with input alphabet , when M* is started scanning the leftmost 1 in an unbroken string of n0+1 1s (n0 being the encoding of machine M) followed by a single blank followed by word w over , M* transforms w exactly as machine M would transform it

utms exist
UTMs Exist
  • Turing (1936) proved this
  • Decode/encoding of Turing Machine and copy it to one or more worktapes
  • Arguments are copied to worktape(s)
  • Then the program is executed
  • Proving that UTM exists different from actually constructing it!
utms exist1
UTMs Exist
  • ENIAC (1943): programmed manually by setting flip-flops and plugging wires into circuit boards

 Store these instructions in the manner of input data

  • Stored-program computers (EDVAC/1946)
  • Also ACE (Turing, London)
  • General-purpose, executive programs: operating systems
    • Accept other programs as input and execute it
  • hardware plasticity: ability of one general-purpose machine architecture to mimic other, diverse machine architectures by means of dedicated software (cf. emulators)
slide54

EDVAC (Electronic Discrete Variable Automatic Computer)

  • more internal memory than any other computing device to date
  • used binary rather than decimal numbers
  • 10 years after Turing!!!
history of computing on the internet
History of Computing on the Internet
  • Charles Babbage Institute http://www.cbi.umn.edu/photo/cbi/gallery.htm
  • EDVAC site at http://www.ifi.unizh.ch/se/people/hoyle/Lecture/edvac.html
  • Most highly recommended is the Smithsonian Institute site (Landmarks in Digital Computing) at http://www.nasm.edu/NASMDOCS/DSH/LDC/ldc_contents.html
nondeterministic turing machine1
Nondeterministic Turing Machine

L = {(ab)n | n  1}

nondeterministic turing machine2
Nondeterministic Turing Machine

L = {(ab)n | n  1}

L’ = {an | n  1}

nondeterministic turing machine3
Nondeterministic Turing Machine

L = {(ab)n | n  1}

L’ = {an | n  1}

Alternative execution paths

Non-deterministic language accepting Turing machine

Should accept L  L’

language acceptance1
Language Acceptance
  • Accepts w if some computation of M results in an accepting 1
  • In general there will be “nonaccepting” computations even in the case of an accepted w
  • M accepts L if and only if M accepts all and only the words of L
transition functions
Transition Functions
  • In the case of a nondeterministic M, we have that M is not single-valued, e.g., M(q0, a) = (B, q1) and M(q0, a) = (B, q6).
  • We speak of a transition mapping, instead of transition function
  • Deterministic machines of those among the nondeterministic machines with single-valued transitions mappings.
  • Determinism = a special case of non-determinism.
turing computability
Turing-Computability
  • Theorem Let f be a number-theoretic function. Then f is computed by some nondeterministic Mnd if and only if f is computed by some deterministic Md.
time complexity recap
Time complexity (recap)
  • Complexity class P: class of all languages accepted in polynomial time by some Turing Machine
  • L = {w*|na(w) = nb(w) } is a member of complexity class P

A language L over alphabet  is said to be polynomial-time Turing-acceptable if there exist both a deterministic TM M and a polynomial p(n) such that for any w *, we have w  L if and only if M accepts w in O(p(|w|)) steps.

a new complexity class
A New Complexity Class
  • NP = class of polynomial-time non-deterministically Turing-acceptable languages
  • P  NP trivially
  • Every language in NP is Turing-acceptable
slide67
P  NP?
  • Is something that is easy to check, also easy to compute?
  • Open problem worth $1M

http://www.claymath.org/millennium/P_vs_NP/

Suppose that you are organizing housing accommodations for a group of four hundred university students. Space is limited and only one hundred of the students will receive places in the dormitory. To complicate matters, the Dean has provided you with a list of pairs of incompatible students, and requested that no pair from this list appear in your final choice. This is an example of what computer scientists call an NP-problem, since it is easy to check if a given choice of one hundred students proposed by a coworker is satisfactory (i.e., no pair taken from your coworker's list also appears on the list from the Dean's office), however the task of generating such a list from scratch seems to be so hard as to be completely impractical. Indeed, the total number of ways of choosing one hundred students from the four hundred applicants is greater than the number of atoms in the known universe! Thus no future civilization could ever hope to build a supercomputer capable of solving the problem by brute force; that is, by checking every possible combination of 100 students. However, this apparent difficulty may only reflect the lack of ingenuity of your programmer. In fact, one of the outstanding problems in computer science is determining whether questions exist whose answer can be quickly checked, but which require an impossibly long time to solve by any direct procedure. Problems like the one listed above certainly seem to be of this kind, but so far no one has managed to prove that any of them really are so hard as they appear, i.e., that there really is no feasible way to generate an answer with the help of a computer. Stephen Cook and Leonid Levin formulated the P (i.e., easy to find) versus NP (i.e., easy to check) problem independently in 1971.

slide68
P  NP?
  • Probable answer: yes
  • NP-complete problems: problems that are most likely not to be in P
  • NP-hard problems: NP problems that can be reduced in polynomial time
  • Traveling salesman: NP-complete problem. If this problem turns out to be in P, P=NP
  • So far: no one has been able to find a polynomial time solution to an NP-hard problem
  • Inherent problem of computation? Or human intelligence problem?
machine intelligence
Machine Intelligence
  • Descartes Test: intelligence = a machine’s ability to use language:
    • More than language recognition?
    • Communication with humans?
    • Weizenbaum’s ELIZA?
turing test
Turing Test
  • Computing Machinery and Intelligence (1950)
  • 3 participants: 2 men (manA and manB) and 1 woman play imitation game:
    • Room 1: manA as the interrogator
    • Room 2: manB + woman
    • Communication through networked computers
    • Goal: interrogator needs to identify male or female in room2 through questioning (questions to player X and player Y (predefined by manB and woman))
    • If the interrogator correctly identifies them, interrogator and woman win
      • Woman has to help interrogator by answering like a woman
      • manB has to confuse the interrogator by answering like a woman
turing test1
Turing Test
  • Interrogator has to ask intelligent questions:
    • Name a shoe manufacturer
    • Name a football team
    • What is your shoe size
  • If the 3 participants are of the same intelligence, the interrogator will end up merely guessing
    • Woman+Interrogator wins half the games
    • manB wins half the games
turing test2
Turing Test
  • What if the role of manB is played by a computer?
  • Interrogator needs to guess who is the computer and who is the woman
  • Woman will help the interrogator and computer needs to confuse him
  • If the number of games won by the computer is at least as great as that of manB, we pronounce the computer intelligent
  • Computer’s knowledge of the world is just as important as its knowledge of human knowledge limitations
  • But: anthropocentric (cf. extraterrestrial intelligence)
block s critique
Block’s critique
  • Given 60 minutes of Imitation Game, 88 characters, … the class of imitation game conversations is finite
  • A machine Aunt Bubbles has access to all of these conversation and simply searches for the most appropriate next answer
  • Is this machine intelligence?
  • “Intelligence of a jukebox”
  • Deep Blue?
cognition
Cognition
  • Sensory perception, natural language processing, reasoning, judgment, memory, …
  • Computation = one sort of human cognitive activity
  • Cognitive scientists: seek plausible models of cognitive activity
  • Theory of computability can make a contribution to cognitive science
cognition and turing machines
Cognition and Turing Machines
  • Strong claim: Universal Turing Machines model human cognition?
    • Is human cognition goal-oriented?
    • Is everything we think about computation?
  • Weak claim: every genuinely cognitive aspect of the human mind can be modeled with a Turing Machine, given the correct tape representation. The rest is noise
cognition and turing machines1
Cognition and Turing Machines
  • Competence models of cognition: formal analysis of overall input/output relations
  • Performance models of cognition: includes modeling of noise

Turing Machine modeling: only competence!

exercise 4
Exercise 4
  • Use Deus ex Machina to design a 3-tape turing machine that accepts the language {w * | w = wR}
exercise 5
Exercise 5
  • Use the ASCII translation table to find the ASCII code of the Turing Machine below

s’:R

q

exercise 6
Exercise 6
  • Find the Turing Machine encoded by natural number 1,312,648,837,500

Using the Euler-Gödel scheme and the following translation table:

exercise 7 difficult
Exercise 7 (difficult)
  • Use Deus Ex Machina to design a non-deterministic Turing Machine that accepts language {ww|w*} with  = {a,b}

hint: design a machine that nondeterministically selects a candidate midpoint within its input word and then proceeds to compare its front half with its back half, one character at the time

exercise 8
Exercise 8
  • Given the following deterministic Turing Machine that should accept all and only the words over alphabet  = {a,b}, but fails
  • Try word bbaabb
exercise 81
Exercise 8
  • Design a deterministic or nondeterministic Turing Machine which does accept the language L ={waaw’|w,w’  *}
