Verification of a Lock-free Concurrent Priority Queue Using Skip-List Data Structure

1. Verification of a Concurrent Priority Queue Bart Verzijlenberg

2. Agenda • Brief Review • Verification Overview • Verification Results • Errors • Further Work • Conclusion

3. Brief Review • Priority Queue • Lock-free • Relies on atomic Compare and Swap operations

4. Algorithm Review • The algorithm uses the Skip-List data structure • Extends the Skip-List for concurrent use • The Skip-List is sorted on the priority of the nodes • The algorithm is lock-free • No blocking • Prevent dead locks • Always progress by at least one operation • Risk of starvation

5. Algorithm ReviewSkip-List • Multi-layer linked list • H forward pointers for a node of height h • Each pointer i points to the next node with a height of at least i

6. Inserting in a Skip-List Inserting 17 in the list

7. Verification Overview • Java Path Finder • Breadth-First Search • Depth-First Search • Modified JPF script • Increased stack size to 1536Mb • Vary the number of inserts/deletions • At what point does JPF crash?

8. Test Classes • Driver Class • Creates • N insertThreads • M deleteThreads • Insert Thread • Inserts a single number into the queue • Delete Thread • Loops until a single number removed from queue • Use of sleep important

9. Code Modifications • Maximum Level = 3 • Probabilistic level selection replaced with a random level • Probabilistic function calls random multiple times • Too many additional paths for JPF • Removed back-off period

10. A Note • At the end of the code • Print “End of Code” • Marks each time JPF reaches the end of a potential execution path • I consider each “End of Code” to correspond with a different thread interleaving (i.e. a path)

11. Verification Results • (1,2) = 1 Insert Thread, 2 Delete Threads

12. By Comparison • Implemented simple priority queue test • java.util.PriorityQueue • Not safe for concurrency • Synchronized insert statement using a lock on the queue • Able to test inserting 8 numbers quickly • 3713 Paths • Tested in 45 Min • Inserting 10 numbers • Crashed after 60791 Paths

13. What is the Difference? • Using synchronized method • Very few points where a thread can take over • I.e. When one thread is inserting, none of the others can insert at the same time • Lock Free • Threads can be interrupted after every instruction • This results in many more potential interleavings

14. Errors ! • java.lang.OutOfMemoryError: • GC overhead limit exceeded • More than 98% of time spent on GC • Recovering less than 2% of the heap • java.lang.OutOfMemoryError: • Java heap space • [SEVERE] JPF out of memory • [SEVERE] JPF exception, terminating: • class java.lang.NullPointerException: null

15. Further Work • Reduce Max level to 2 • Further reducing number of paths • Enable back-off function • Find linearization points in the code • Add each number into two queues at the same time • Try some of the other search classes

16. Conclusion • Testing at this point has not found errors • When inserting up to 2 numbers • When inserting 3 numbers (before crashing) • More work needed to reduce the chance of errors further • Will not eliminate completely

17. Thank You Questions?
