Presentation Transcript
the ghs the globally harmonized system for hazard classification and labelling of chemicals

The GHSThe Globally Harmonized System for Hazard Classification and Labelling of Chemicals

Basic Course

slide2

Outline

1. Concept of the GHS2. Hazard Classification 2.1 Physical Hazard Classification 2.2 Health and Environmental Hazard Classification 3. Labels and SDS 4. Situation of Chemical Management in Thailand

what is harmonised
What is harmonised?
  • Labels
  • Safety Data Sheets
slide5

Target Groups & Sectors

  • workplace including pesticides and pharmaceuticals
    • labels and safety data sheets
  • consumers
    • labels
  • transport
    • labels, placards, transport documents
  • emergency responders
labels
Labels
  • The Essential Elements
    • Symbols, Pictograms and colour
    • Signal words
    • Hazard statements
    • Precautionary information
    • Product identifiers/declaration of ingredients
    • Precedence of hazard
slide7

Symbols in the GHS

  • Standard symbol set used in the UN RTDG model regulations
  • Fish and tree symbol for environmental hazard
  • Exclamation mark for “low level” health hazard
  • Human with crack in a body for chronic health hazard
ghs symbols
GHS Symbols

Flame

(Flammable/

Self-reactive/ etc.)

Flame over circle

(Oxidizing/

Organic peroxide)

Exploding bomb

(Explosives/

Self-reactive/ etc.)

Corrosion

Gas cylinder

(Compressed gases)

Skull & crossbones

(Acute toxicity)

Exclamation Mark

(Acute: lower level)

Human

(Chronic: higher lev)

Environment

(Aquatic toxicity)

slide10

Pictogram Shape & Colour

  • Recommendation from ILO Group is that all pictograms should be in shape of a square set at a point (diamond)
  • For transport, pictograms will use the background and symbol colour specified in the UNRTDG Model regulations
  • For supply, pictograms will have a black symbol on a white background with a red frame
ghs pictogram
GHS Pictogram

Flammable substance

Self-reactive substance

Pyrophoric and self-

heating substance

Explosives

Self-reactive subst.

Organic peroxide

Oxidizing substance

Organic peroxides

Compressed gas

Sensitization (Respiratory)

Mutagenicity

Carcinogenicity

Reproductive toxicity

Target organ toxicity

Skin corr.

Eye corr.

Corrosive to metal

Acute toxicity

Acute toxicity

Skin irrit.

Eye irrit.

Sensitization (Dermal)

Environmental

toxicity

slide12

Some points on GHS Pictograms

  • UNRTDG will cover the transport area as they have been.
  • Competent authority may choose to give suppliers and employers discretion to use a black border for domestic use.
  • Competent authority may allow the use of UNRTDG pictograms in other use settings
slide13

Signal Word

  • “Danger” or “Warning”
  • Used to emphasis hazard and to discriminate between hazard categories (level of hazard)
  • e.g. Acute toxicity category 1 will require “Danger”, category 4 will require“Warning”
slide14

Hazard Statements

  • A single harmonised hazard statement for each hazard category within each hazard class
  • e.g. Flammable liquid
    • - Category 1
    • “Extremely flammable liquid and vapour ”
    • - Category 2
    • “Highly flammable liquid and vapour”
    • - Category 3
    • “Flammable liquid and vapour”
    • - Category 4
    • “Combustible liquid”
hazard statements cont
Hazard Statements (cont.)

e.g. Oral Acute Toxicity

  • category 1

“Fatal if swallowed “

  • Category 2

“Fatal if swallowed ”

  • Category 3

“Toxic if swallowed”

  • Category 4

“Harmful if swallowed”

  • Category 5

“Maybe harmful if swallowed”

slide16

Precautionary Statements

  • GHS label should include appropriate precautionary information
  • The intent is to harmonise precautionary statements in the future
slide17

Examples of Precautionary Pictograms

From European Union (COUNCIL DIRECTIVE

92/58/EEC of 24 June 1992)

slide18

Product Identifier

  • Name or number used for a hazardous product on a label or in the SDS.
  • Unique means by which the substance or mixture can be identified within the particular use setting
  • UN proper shipping name also to be used on the package when substance or mixture covered by the UN RTDG
precedence of hazard
Precedence of hazard

>

>

Skin/Eye irritation

Skin/Eye irritation

>

>

DANGER

WARNING

slide20

Declaration of Ingredients

  • Substances
    • chemical identity (name as determined by IUPAC, ISO, CAS or technical name)
  • Mixtures
    • chemical identities of all ingredients contributing to acute toxicity, skin or eye corrosion, germ cell mutagenicity, carcinogenicity, reproductive toxicity, skin or respiratory sensitisation or TOST
  • Competent authority rules for CBI take priority
slide21

Confidential Business Information

  • Competent authorities should establish appropriate mechanisms for CBI protection. CBI will not be harmonized under the GHS.
  • The provisions for CBI protection should not compromise the health and safety of users.
  • CBI claims should be limited to the names of chemicals and their concentrations in mixtures.
  • Mechanisms should be established for disclosure in emergency and non-emergency situations.
slide22

Other (Non-GHS) Information

  • Supplemental information
  • Competent authority may choose to specify where information should appear on the label or allow supplier discretion
  • Must not impede identification of GHS information
allocation of label elements
Allocation of Label Elements

Category 1

Category 2

Category 3

Category4

Category 5

Danger

Fatal if swallowed

Danger

Fatal if swallowed

Danger

Toxic if swallowed

Warning

Harmful if

Swallowed

No

Symbol

Warning

May be harmful if swallowed

Example : Acute Toxicity (Oral)

allocation of label elements cont
Allocation of Label Elements (cont.)

Category 1A

Category 1B

Category 1C

Category 2

Category 3

Danger

Causes severe skin burns and eye damage

Danger

Causes severe skin burns and eye damage

Danger

Causes severe skin burns and eye damage

Warning

Causes skin irritation

No

Symbol

Warning

Causes mild skin irritation

Example : Skin Corrosion/Irritation

slide25

Building Block Approach (1)

Example : Acute Toxicity (Oral)

slide26

Building Block Approach (2)

Example : Explosives

slide27

Epichlohydrin

1-Chloro-2,3-epoxypropane

CAS No. 106-89-8

UN No. 2023

Product identifier

EPICHLOROHYDRIN

Example of label component

Pictogram

DANGER

Signal word

Hazard statements:

・Toxic if swallowed

・Toxic in contact with skin

・Fatal if inhaled

・May cause an allergic skin reaction.

・May cause genetic defects.

・May cause cancer

・Cause severe skin burns and eye damage

・Cause serious eye irritation

・Toxic to aquatic life

Hazard statements

Precautionary statements:

・Keep out of reach of children.

・Keep container tightly closed.

・Do not handle until all safety precautions have been read and

understood.

・Wear eye/face protection.

・Wear protective gloves/clothing.

・Wear respiratory protection, as specified by the manufacturer.

・Do not breathe dust/fume/gas/mist/vapours/spray.

・Use appropriate ventilation.

・Wash thoroughly after handling.

Precautionary statements

United Nations Co., Ltd.

1-1, Peace Ave., Geneva

Switzerland

Tel. 41 22 917 00 00 Fax. 41 22 917 00 00

Supplier identification

safety data sheet
Safety Data Sheet
  • Primarily workplace use
  • 16 heading format agreed
  • Minimum additional information specified, where applicable or available, under the relevant headings
criteria for sds production
Criteria for SDS production

For all substances and mixtures which meet the harmonized criteria for physical, health or environmental hazards under the GHS

cut off values concentration limits for health and environmental hazard class

Hazard class

Cut-off value /Concentration limit

Acute Toxicity

≥ 1.0

Skin Corrosion/Irritation

≥ 1.0

Serious damage to eyes/eye irritation

≥ 1.0

Respiratory/Skin sensitization

≥ 1.0

Mutagenicity: Category1

≥ 0.1

Mutagenicity: Category2

≥ 1.0

Carcinogenicity

≥ 0.1

Reproductive Toxicity

≥ 0.1

Target Organ Systemic Toxicity (Single Exp.)

≥ 1.0

Target Organ Systemic Toxicity (Repeat Exp.)

≥ 1.0

Hazardous to the Aquatic Environment

≥ 1.0

Cut off values/Concentration limits for health and environmental hazard class
sds 16 headings
SDS 16 Headings
  • Identification.
  • Hazard(s) identification.
  • Composition/information on ingredients.
  • First-aid measures.
  • Fire-fighting measures.
  • Accidental release measures.
  • Handling and storage.
  • Exposure controls/personal protection.
sds 16 headings cont
SDS 16 Headings (cont.)
  • Physical and chemical properties.
  • Stability and reactivity.
  • Toxicological information.
  • Ecological information.
  • Disposal considerations.
  • Transport information.
  • Regulatory information.
  • Other information.
slide39

Physical Data

Boiling Point -The temperature at which a liquid turns to a vapour

slide40

Freezing Point

- Temperature at which the liquid form of a chemical will turn into the solid form

Melting Point

- Temperature at which the solid form of a chemical will turn into the liquid form

Vapour pressure

- The higher the vapour pressure,the more rapidly the material will change from liquid form to o vapour when released to the environment.

slide41

Vapour pressure

The amount of released harmful vapors in based on the chemical’s vapor pressure. The greater the vapor pressure, the greater the yield of hazardous vapors . Acetone will give off more vapors then gasoline. Sulfuric acid has a low vapor pressure and gives off little vapor.

slide42

Vapour density

- Density of a gas compared to the density of air

slide43

Specific gravity - density of a chemical compared to the density of water. If the specific gravity is less than one, the chemical will float on water. If the specific gravity is greater than one, the chemical will sink.

slide47

Water solubility of a chemical the quantity of a chemical that will mix with or dissolve in water. Helps to determine many of its toxic effects on living tissues / Chemicals that are very water soluble, lead to cellular injury.

slide48

Liquid - gas ratios. The volume of gas produced by the vaporization of a given volume of liquid . The volume of gas produced is always greater than the volume of liquid before vaporization.

slide49

Different chemicals have different expansion ratios. Liquified gases and cryogenics have the greatest

The expansion ratio of a chemical helps to determine the extent of hazard that the chemical poses.

slide54

Label - Examples

Transportation and Workplace

Plastic drum

slide55

Label - Examples

Transportation and Workplace

Paper box

slide56

Label - Examples

Workplace

Paper box
