Setting the Scene The ER Diagrammer shows all Entities and Relationships... … and the Function Hierarchy Diagrammer shows all business functions... … but I want to see both Entities and Functions... How about a matrix?
column row third axis intersection(cell) The Matrix Diagrammer • A two-dimensional Repository object display tool • Is not like ERD, PM, or DFD • Can maintain definitions • Shows CRUD matrixes and many others
Defining Both Matrix Axes • Choose both object types for the horizontal and vertical axes • Most of the primary access elements • Some secondary access elements • Choice of second object type depends on choice of first axis
New Matrix Dialog Initial Appearance Choose Row Type Choose Column Type
Defining What is Displayed • Properties displayed per object type and intersection (cell) • Filters to reduce number of axis elements • Sort order of objects
1 1 Displaying Properties Row - Business Functions Column - Entities Intersection-FunctionEntity Usage Properties View Order Filter Lines LabelShort DefinitionMaster FunctionParent FunctionAtomic?Elementary?FrequencyResponse NeededIntention to AutomateApplication System A is null D =‘Y’ Resulting Pseudo-SQL: SELECT label, response_neededFROM business_functionsWHERE master_function IS NULLAND elementary? =‘Y’ORDER BY short_definition, atomic? desc
Defining Filter Conditions • Limited, SQL-like criteria: • =, >, <, >=, <=, <> • IS NULL, IS NOT NULL • value1 and value2 • ‘A%’, ‘_MEM%’ • No ORs, only implicit ANDs • No Not Like
Attributes Business Functions LINE NO RENTAL DATE C*** C*** CR** *R** *R** *R** CRU* **U* **U* RENTAL RENTAL ITEM REVIEW PUBLICATION entities Displaying a Third Axis PRICE PA Settings automatically shows Entities tab
Uses of a Matrix • Data entry • Completeness checking • Design reporting • Impact analysis • Repository management • Progress reporting
Saving the Matrix • Changes to data are saved automatically in the Repository. • Saving a matrix means saving the matrix settings. • A matrix is automatically requeried when opened. • Broadcast is available for axis elements.
Summary • Matrix Diagrammer: • Display and compact reporting tool • Used for verification and correction of entries • Over 160 different matrixes • Over 40 3D matrixes
