  1. CGS TYRES / Mitas a.s. Deula 2010 Technical Sales TrainingLatest status agricultural tyres Wednesday 15th of Sept, 2010

  2. CGS Brand Portfolio full range in all applications full range for tractor and combine application wide range of commodity products focus EU, US and Russia driven by OE‘s basic range of commodity products Full range in all applications sport tyres off the road

  3. AE/PM Team

  4. AE/PM Team Our Ambition • a leading, flexible and globally oriented partner • for the agricultural and industrial • (construction equipment) sectors, • providing top technical solutions to optimize economical benefits for our customers • ensure an attractive and profitable product range

  5. AE/PM Team

  6. OE Business

  7. OE Projects • OE future demands: • more compact products • more load, higher speed • smaller tyre dimensions, lower inflation pressure • supported by TIER IV emission limits • better ride comfort

  8. OE Projects • Advanced technology projects: • „Future problems need future solutions“ • Strategical development partnerships with OE-customers • Claas SE: SHD development • new generation steer tyres • JDWM: „Low Noise Tractor“ • AGCO-Fendt: tyres for 500 HP-tractor incl. TIS • Daimler AG: tyres for future road/rail vehicles • CNH: development 900/60 R 38 SVT for combines

  9. OE Projects • Strategical Development Partnerships with OE-Customers • US: CNH CGS as an accepted Supplier 8 X 710/70 R 42 SVT 550 HP scraper tractor

  10. OE Projects • Strategical Development Partnerships with OE-Customers • US: CNH CGS as an accepted Supplier

  11. Product overview3.1. Continental agricultural tyres – product highlights ContinentalSuperVolumeTyre High Performance Tyre for High Performance Tractors 200 +X HP • maximum productivity • soil protection even under heavy loads • speeds up to 70 kph

  12. Product overview3.1. Continental agricultural tyres – product highlights ContinentalSuperVolumeTyre High Performance Tyre for High Performance Tractors 200 +X HP • Unique hexa-bead technology: • easy mounting • no limitation of HP • compatible to tyre inflation systems

  13. Product overview3.1. Continental agricultural tyres – product highlights ContinentalSuperVolumeTyre Products launched last 12 month: 750/55 R 30 steer axle standard tractors > 300 HP 650/65 R 34 steer axle standard tractors > 300 HP 710/75 R 42 drive wheel for tractors > 300 HP Products to launched next 12 month: 600/70 R 28 steer axle standard tractors 200 HP 710/55 R 30 steer axle standard tractors 250 HP 800/70 R 38 drive wheel for tractors and combines

  14. Product overview3.1. Continental agricultural tyres – product highlights One for All the clever alternative for tractors from 60HP up to 180 HP ContinentalHC 70 • compactness, up to 14% more load compared to A8-rated 70 series • protection, 0,3 bar lower Inflation pressure than A8-rated 70 series • versatility, advanced tread concept for efficiency on field, road and greenland

  15. Product overview3.1. Continental agricultural tyres – product highlights ContinentalHC 70 • 7 sizes in current range • 10 sizes for range completion are under development

  16. Product overview3.1. Continental agricultural tyres – product highlights ContinentalSilent Speed Tyre 65% wide tyre, market standard Unique Comfort noise level in dB(A) speed in km/h

  17. Product overview3.1. Continental agricultural tyres – product highlights ContinentalSilent Speed Tyre • available: • 600/65R 38 • 650/65 R 38 • In preparation: • 650/65 R 42

  18. Product overview3.1. Continental agricultural tyres – product highlights Continental Range Extension for US RowCropTractors • In stage of introduction: • 420/85 R 34 AC85 • 380/80 R 38 AC85 • 480/80 R 42 AC85 • 480/80 R 46 AC85 • 380/90 R 50 AC85 • 480/80 R 50 AC85

  19. Product overview3.2. Mitas agricultural tyres – product highlights • Latest status of 65 series tyres for tractors up to 200 HP • High efficency and enormous versatility Mitas RD-03 • Care for efficiency: • speeds up to 70 kph • low Rolling Resistance • Care for soil and comfort: • 0,2 bar lower inflation pressure than A8-rated 65 series

  20. Product overview3.2. Mitas agricultural tyres – product highlights • New tyre line for US row crop tractors • Versality and reliability Mitas RD-05 • In stage of introduction: • 420/85 R 28 RD-05 • 380/85 R 30 RD-05 • 420/85 R 34 RD-05 • 380/80 R 38 RD-05 • 480/80 R 42 RD-05 • 480/80 R 46 RD-05 • 380/90 R 50 RD-05 • 480/80 R 50 RD-05

  21. Product overview3.2. Mitas agricultural tyres – product highlights • New bias metric tyre line for heavy duty agricultural and forestry application • High traction and robustness Mitas AF-01 • Modern metric bias tyres with service description • speeds up to 50 kph • up to 0,6 bar lower inflation pressure than code designated ply rating marked sizes

  22. Product overview3.2. Mitas agricultural tyres – product highlights • New tyre line heavy duty agriculturaland forestry application • High traction and robustness Mitas AF-01 • In stage of introduction: • 380/85 R 24 AF-01 • 380/85 R 28 AF-01 • 420/85 R 34 AF-01 • 460/85 R 34 AF-01

  23. Product overview3.2. Mitas agricultural tyres – product highlights Market: tyres for trailer application Application: loading wagon slurry trailers shuttle carts Service: grassland/ road field/ road Tyre outer diameter: < 1400 mm > 1400 mm Main requirements: protection of grassland self cleaning self cleaning compatible for TIS rolling resistance rolling resistance low noise generation low noise generation

  24. Product overview3.2. Mitas agricultural tyres – product highlights Product concept Mitas AGRITERRA • AGRITERRA-02 • gentle to grassland • high positive share • Lower Skid Depth • Round Shoulder • AGRITERRA-03 • good selfcleaning • higher negative share • Higher Skid Depth • Distinctive Shoulder

  25. Product overview3.2. Mitas agricultural tyres – product highlights AGRITERRA 02 vs benchmarks • gentle to grassland Flotation Pro CargoXBib AGRITERRA-02

  26. Product overview3.2. Mitas agricultural tyres – product highlights AGRITERRA 03 vs benchmarks • good selfcleaning I-380 Twin Radial AGRITERRA-03

  27. Product overview3.2. Mitas agricultural tyres – product highlights Mitas AGRITERRA The advanced tyre solution for modern trailers AGRITERRA 02 AGRITERRA 03 • slurry tankers and transport technology • economy and robustness • silage trailers • gentle and tough

  28. Product overview3.2. Mitas agricultural tyres – product highlights Mitas AGRITERRA • The advanced tyre solution • Robust and tough • STC-belt: • high puncture resistance • low rolling resistance • hexa bead • good bead seating • TIS compatibility

  29. Product overview3.2. Mitas agricultural tyres – product highlights • The advanced tyre solution for modern silage trailers • Gentle and tough Mitas AGRITERRA-02 • Non agressive tread pattern: • rounded shoulder • high surface of tread blocks

  30. Product overview3.2. Mitas agricultural tyres – product highlights • The advanced tyre solution for modern slurry tankers and transport technology • Economy and robustness Mitas AGRITERRA-03 • Open tread pattern: • good self cleaning • Extra skid depth • high service life

  31. Product overview3.2. Mitas agricultural tyres – product highlights Mitas AGRITERRA The advanced tyre solution for modern trailers AGRITERRA 02 AGRITERRA 03 • In preparation • 650/65 R 30.5 • In preparation • 600/55 R 26.5 • 710/50 R 26.5

  32. Product overview3.3. Cultor agricultural tyres – product highlights CultorActualagriculturalrange 13 sizes 24“ – 38“ 36 sizes 24“ – 42“ 6 sizes 16“ – 20“ 22 sizes 24“ – 42“ 11 sizes 12“ – 22.5“ 7 sizes 15.3“ – 22.5“

  33. Product overview3.3. Cultor agricultural tyres – product highlights Subline for ‚running title‘, if needed Cultor Agriculturalrange in preparation • Radial-85 • Standard Radial MetricDesignated • Tractors Drive Wheel • 15 Sizes 24“-38“

  34. Thank you very much for your attention!
