grids utility computing and a perspective on the future of it infrastructure

Grids, utility computingand a perspective onthe future of IT infrastructure

Washington Area CTO Forum

March 31, 2006

Nirav Kapadia

nhkapadia@gmail.com

outline
Outline
  • Characterizing computing grids
    • Grids as intended versus what we see today
    • Common types of grids today
  • Putting computing grids to work
    • Types of problems addressed by today’s grids
    • Operational considerations in deploying a grid
  • A perspective on the future of IT infrastructure
    • Cost pressures and technology commoditization
    • Grid and utility computing: the technology enablers
grids came about from a need for large scale collaborative computing
Grids came about from a need for large scale, collaborative computing
  • Scale is measured in terms of users, nodes, organizations, geography, and heterogeneity
    • A grid in the strict sense of the word involves a large number of heterogeneous, shared resources
  • Collaboration is measured in terms of resource sharing and interoperability
    • A key characteristic is the ability to manage across organizational boundaries
systems for large scale collaborative computing must meet key criteria

Broad definition of

computing grid

Strict definition of computing grid

Systems for large scale, collaborative computing must meet key criteria

Group A

Scalable with users and resources

Support for heterogeneity

Group B

Support for interoperability

Scalable with geographical distances

Group C

Fully distributed (federated) architecture

Ability to compartmentalize along

organizational boundaries

many commercial grid solutions only meet the broad definition of a grid
Many commercial grid solutions only meet the broad definition of a grid
  • Cluster management systems
    • Typically harness clusters of dedicated servers
    • Examples include Platform LSF, Sun Grid Engine
  • CPU-scavenging “master-slave” applications
    • Typically take advantage of idle desktop cycles
    • Examples include SETI@Home, distributed.net
many commercial grid solutions only meet the broad definition of a grid6
Many commercial grid solutions only meet the broad definition of a grid
  • Application-specific, custom-built grids
    • Typically built around a key business function
    • Examples include Acxiom, Oracle offerings
today solutions that meet the strict definition of a grid have to be built
Today, solutions that meet the strict definition of a grid have to be “built”
  • Grid solutions based on the Globus toolkit
    • Several vendors have Globus based offerings
    • Univa Corp is commercializing Globus
  • Other grid solutions in academia and research
    • Most are custom-built and target a specific problem
    • Typically not appropriate for commercial use (today)
key takeaways
Key takeaways
  • A grid is a distributed computing system that enables large scale, collaborative computing
    • Scalable across a large number of diverse and geographically dispersed resources
  • Many commercial “grid solutions” of today do not meet the strict definition of a grid
    • Limited ability to manage policies and resources across administrative boundaries
outline9
Outline
  • Characterizing computing grids
    • Grids as intended versus what we see today
    • Common types of grids today
  • Putting computing grids to work
    • Types of problems addressed by today’s grids
    • Operational considerations in deploying a grid
  • A perspective on the future of IT infrastructure
    • Cost pressures and technology commoditization
    • Grid and utility computing: the technology enablers
even today s grids can benefit users with large scale computing needs
Even today’s grids can benefit users with large scale computing needs
  • High throughput computing (HTC)
    • Many independent (non-communicating) tasks
    • Large problems that break up into manageable, independent tasks
  • High performance computing (HPC)
    • Large problem that is not decomposable into manageable, independent tasks
high throughput computing is common in business environments
High throughput computing is common in business environments
  • Large, legacy applications are best served by cluster management systems
    • Compute-intensive apps are preferable but a mix of compute- and data-intensive apps are manageable
  • Customizable apps that work on small slices of data work well with CPU-scavenging grids
    • Apps must be compute-intensive and preferably run within a sandbox
high performance computing is seen more in targeted environments
High performance computing isseen more in targeted environments
  • Applications involving multiple, communicating tasks are typically require custom designed grid environments
    • Examples include Oracle grid offering and some test beds built with Globus
    • Other examples include distributed computing platforms such as PVM and MPI
so you re ready to deploy a grid computing environment
So… you’re ready to deploy a grid computing environment…
  • As with any other technology, there are several operational considerations…
    • Resources on the grid – dedicated or shared?
    • Access management – who needs access to what?
    • Data management – how does data get to the grid?
    • Security model employed by the grid
resources on the grid should they be dedicated or shared
Cluster Mgmt Systems

Cluster management systems work best with dedicated resources

Condor – from the U of Wisconsin – is a notable exception, but not commercially available

CPU-scavenging grids

As the name implies, resources are shared – and typically involve desktops

A custom screen saver is the most common vehicle for running the grid application

Resources on the grid –should they be dedicated or shared?
access management who needs gets access to what
Cluster Mgmt Systems

Option #1: jobs run in a guest account

Shared access across jobs

Option #2: accounts for everyone on all machines

Homogeneous uid pool highly recommended

Logins typically disabled

CPU-scavenging grids

Option #1: jobs run with user’s privileges

If downloaded by user

Option #2: jobs run in guest account

If set up by administrator

No direct remote user access to desktop

Access management –who needs (gets) access to what?
data management how does data get to the apps
Cluster Mgmt Systems

Transfer user specified files via ftp, scp, etc

File staging for large data

On demand file transfer (system call traps)

Shared file systems

CPU-scavenging grids

Data embedded within application or retrieved via HTTP/Java call-backs

Limited data, typically no files

Data management –how does data get to the apps?
security model user accountability is key today

Access management (capability control)

Opportunities for subversion

distributed.net,

SETI@Home, etc

Globus

Java, PCCs

Condor

LSF, PBS, SGE

Unix

Ideal Grid

Security model –user accountability is key today

Custom

Applications

Source Code

Modifications

Object Code

Modifications

Basic system and kernel safeguards

Unchanged

Binaries

Application

Executable

Application

Generation

Application

Users

Run Time

Environment

key takeaways18
Key takeaways
  • Today’s commercially available grid solutions primarily target high throughput computing
    • Cluster management systems and CPU-scavenging grids are the most common
  • Carefully consider the policy implications of grids in terms of access and data management
    • More of a concern for grids that span sub-nets or fire walls
outline19
Outline
  • Characterizing computing grids
    • Grids as intended versus what we see today
    • Common types of grids today
  • Putting computing grids to work
    • Types of problems addressed by today’s grids
    • Operational considerations in deploying a grid
  • A perspective on the future of IT infrastructure
    • Cost pressures and technology commoditization
    • Grid and utility computing: the technology enablers
even as grids take hold the it landscape is changing rapidly
Even as grids take hold, theIT landscape is changing rapidly…
  • Technology is rapidly being commoditized
  • Businesses are more willing and able to shop for IT services
  • In-house IT infrastructure is increasingly seen as complex and rigid

© Harvard Business Review

it infrastructure is already a commodity from a business view
IT infrastructure is already a commodity from a business view
  • Outsourcing is pervasive; and standards-based, open systems are increasingly common
    • Cost pressures will continue driving businesses to streamline IT infrastructure
  • More often than not, customized in-house IT systems stand out for their cost and complexity
    • Common off-the-shelf solutions provide more value in the absence of direct competitive advantage
in time economics will drive it infrastructure out of the enterprise
In time, economics will drive IT infrastructure out of the enterprise
  • The technology enablers for this paradigm exist today, but are still nascent
    • (True) grids offer a way to manage computing resources across organizational boundaries
    • Utility computing solutions bring together grids, data center automation, and virtualization
the technology implications of these changes are enormous
The technology implications of these changes are enormous
  • Computing infrastructure needs to become transparent to end users
    • Users only interact with applications and data
  • Policy management needs to be decoupled from system management
    • Cannot assume users can be held accountable
  • Components of computing systems need to be less tightly coupled
    • CPU, OS, data, apps may all be in different, remote locations
a utility computing test bed at purdue showcases this paradigm
A utility computing test bed at Purdue showcases this paradigm
  • Operating since 1995; now a joint development effort between Purdue and U of Florida
    • By 2001, allowed 3,000+ users from 30 countries to run ~100 applications in a utility environment
    • Extensively validated: ~400,000 runs (by 2001); highly peaked usage profile
    • Powers online simulations in the nanoHUB.org portal for the nanotechnology community
nanohub org remote access to simulators and compute power

Physical Machine

Virtual Machine

Real users and real usage

>10,687 users

Condor-G

Globus

TeraGrid

Cluster

nanoHUB.org – remote access to simulators and compute power

nanoHUB infrastructure

Internet

nanoHUB.org

Web site

Remote desktop (VNC)

NMI Cluster

Slide courtesy of Gerhard Klimeck, Network for Computational Nanotechnology

inside nanohub org

Custom computing

environment assembled

in real time

Web

Portal

Application

Repositories

OS

Repositories

Data Vaults

CPU Farms

Inside nanoHUB.org

Local Services

Utility Services

PUNCH Virtual Machine

in conclusion
In conclusion…
  • Today’s commercially available grids provide a valuable but narrow service
    • More efficient computing in a closed environment; limited support for cross-organizational sharing
  • In time, grid and utility computing technologies will move IT infrastructure out of the enterprise
    • Virtualization and data center automation products are visible precursors
slide28
Questions? Comments?

Email: nhkapadia@gmail.com
