Presentation Transcript


  1. Primary Productivity in the Marine Environment Fig. 13.5

  2. Primary productivity • Energy is converted into organic matter to be used by cells • Photosynthesis using solar radiation • 99.9% of marine life relies directly or indirectly on photosynthesis for food • Chemosynthesis using chemical reactions • Happens in hydrothermal vents at bottom of ocean with no light

  3. Remember, energy cannot be created or destroyed – it only changes form

  4. Let’s talk about energy • Biological organisms need biochemical processes to happen in an orderly fashion in order to maintain life • Needs constant input of energy to maintain that order • Our cells need energy in form of ATP • ATP formed during cellular respiration • Need input of carbon (i.e. glucose) and oxygen for cellular respiration • That carbon source and oxygen comes from photosynthesis (primary productivity)

  5. Photosynthetic productivity • Chemical reaction that stores solar energy in organic molecules • Photosynthetic organisms fix carbon and energy from atmosphere • Also incorporate other elements and molecules necessary for life (nitrogen, phosphorus, etc) • What do we need these for? For making proteins, lipids, DNA, etc. • Use some of that for their own energy source for life • Excess moves it’s way up the food chain

  6. Now we are going to revisit photosynthesis and cellular respiration • Remember, we are following electrons and protons • OIL RIG – Oxidize it loses, reduced it gains

  7. Photosynthesis – process of fixing carbon from the atmosphere into organic material that now has energy from the sun trapped in the bonds of the molecule • What is the chemical formula for photosynthesis? • Review this Prezi: http://prezi.com/2byn9gmriian/photosynthesis/?utm_campaign=share&utm_medium=copy

  8. Cellular Respiration • Review this Prezi: http://prezi.com/8_qehzkw-vuk/cellular-respiration/?utm_campaign=share&utm_medium=copy

  9. Is glucose the only molecule that can be broken down and oxidized during cellular respiration to gain energy?

  10. Measuring primary productivity • Capture plankton • Plankton nets • Ocean color • Chlorophyll colors seawater • SeaWiFs on satellite

  11. Factors affecting primary productivity • Nutrients • Nitrate, phosphorous, iron, silica • Needed for bacteria and phytoplankton to make more DNA, proteins, etc to make more of themselves • Most from river runoff • Productivity high along continental margins because of nutrient runoff • Solar radiation • Uppermost surface seawater and shallow seafloor are most productive, need light! • Euphotic zone surface to about 100 m (330 ft)

  12. Upwelling and nutrient supply • Cooler, deeper seawater nutrient-rich • Areas of coastal upwelling sites of high productivity Fig. 13.6a http://cordellbank.noaa.gov/images/environment/upwelling_470.jpg

  13. Light transmission • Visible light of the electromagnetic spectrum • Blue wavelengths penetrate deepest • Longer wavelengths (red, orange) absorbed first

  14. Light transmission in ocean • Color of ocean ranges from deep blue to yellow-green • Factors • Water depth • Turbidity from runoff • Photosynthetic pigment (chlorophyll) • “dirty” water in coastal areas, lagoons, etc. are areas of high productivity, lots of plankton (preventing that “blue” color) http://upload.wikimedia.org/wikipedia/commons/a/a5/LightningVolt_Deep_Blue_Sea.jpg

  15. Types of photosynthetic marine organisms • Angiosperms • Seed-bearing flowering plants, example is mangroves • Macroscopic (large) algae • Larger seaweeds, like kelp • Microscopic (small) algae • phytoplankton • Photosynthetic bacteria

  16. Macroscopic algae – “Seaweeds” • Brown algae http://www.starfish.ch/photos/plants-Pflanzen/Sargassum.jpg

  17. Macroscopic algae – “Seaweeds” • Green algae Caulerpa brachypus, an invasive species in the Indian River Lagoon Codium http://www.sms.si.edu/IRLspec/images/cbrachypus2.jpg http://192.107.66.195/Buoy/System_Description_Codium_Fragile.jpg

  18. Macroscopic algae – “Seaweeds” • Red algae • Most abundant and most widespread of “seaweeds” • Varied colors http://www.agen.ufl.edu/~chyn/age2062/lect/lect_15/22_14B.GIF http://www.dnrec.state.de.us/MacroAlgae/information/Indentifying.shtml

  19. Microscopic algae http://biologi.uio.no/akv/forskning/mbot/images • Produce food for 99% of marine animals • Most are planktonic - phytoplankton • Golden algae • Diatoms(tests of silica) • Most abundant single-celled algae – 5600+ spp. • Silicate skeletons – pillbox or rod-shaped ooze • Some w/ sticky threads, spines  slows sinking www.bren.ucsb.edu/ facilities/MEIAF

  20. Microscopic algae • Coccolithophores(plates of ate) • Flagellated • calcium carbon plates  possibly sunshades • Coccolithid ooze  fossilized in white cliffs of Dover http://www.esa.int/images

  21. Microscopic algae • Dinoflagellates • Mostly autotrophic; some heterotrophic or both • Flagella in grooves for locomotion • Many bioluminescent • Often toxic when toxin is concentrated due to bloom • Red tides (algal blooms)  fish kills (increase nutrients, runoff) http://oceanworld.tamu.edu/students/fisheries/images/red_tide_bloom_1.jpg http://www.hku.hk/ecology/porcupine/por24gif/Karenia-digitata.jpg

  22. Microscopic algae • Dinoflagellates • Pfiesteriafound in temperate coastal waters • Ciguatera - illness caused from eating fish coated with Gambierdiscustoxicus • Paralytic, diarhetic, amnesic shellfish poisoning Pfiesteria http://www.odu.edu/sci/biology/pfiesteria

  23. Photosynthetic bacteria • Cyanobacteria – many different species • Extremely small • May be responsible for half of total photosynthetic biomass in oceans Anabaena Gleocapsa http://www.micrographia.com/specbiol/bacteri/bacter/bact0200/anabae03.jpg http://silicasecchidisk.conncoll.edu/Pics/Other%20Algae/Blue_Green%20jpegs/Gloeocapsa_Key45.jpg

  24. Regional primary productivity • Varies from very low to very high depending on • Distribution of nutrients • Seasonal changes in solar radiation • About 90% of surface biomass decomposed in surface ocean • About 10% sinks to deeper ocean • Only 1% organic matter not decomposed in deep ocean  reaches bottom • Biological pump (CO2 and nutrients to sea floor sediments)

  25. Temperate ocean productivity • Seasonal variation with temperature/light/nutrients • Winter: • High winter winds  mixing of sediments/plankton • Low light & few phytoplankton  nutrients increase • Spring: • Phytoplankton blooms with more light, nutrients • Bloom continues until… • Nutrients run out • Herbivores eat enough phytoplankton • Summer: often low production due to lack of nutrients • Fall: Often second bloom, as winds bring up nutrients

  26. Polar ocean productivity • Winter darkness • Summer sunlight (sometimes 24 hours/day) • Phytoplankton (diatoms) bloom • Zooplankton (mainly small crustaceans) productivity follows • HIGH PRODUCTIVITY!! • Example Arctic Ocean

  27. Tropical ocean productivity • Permanent thermocline is barrier to vertical mixing • Low rate of primary productivity (lack of nutrients) above thermocline • That’s why tropical waters tend to be clear and blue

  28. Tropical ocean productivity • Productivity in tropical ocean is lower than that of polar oceans • That’s why tropical oceans look clear • Tropical oceans are deserts with some high areas of sporadic productivity (oasis). Examples of these areas are: • Equatorial upwelling • Coastal upwelling (river runoff, etc.) • Coral reefs

  29. Energy flow in marine ecosystems • Consumers eat other organisms • Herbivores (primary consumers) • Carnivores • Omnivores • Bacteriovores • Decomposers breaking down dead organisms or waste products

  30. Nutrient flow in marine ecosystems • Nutrients cycled from one chemical form to another • Biogeochemical cycling • Example, nutrients fixed by producers • Passed onto consumers • Some nutrients released to seawater through decomposers • Nutrients can be recycled through upwelling

  31. Feeding strategies • Suspension feeding or filter feeding • Take in seawater and filter out usable organic matter • Deposit feeding • Take in detritus and sediment and extract usable organic matter • Carnivorous feeding • Organisms capture and eat other animals

  32. Trophic levels • Feeding stage is trophic level • Chemical energy is transferred from producers to consumers • On average, about 10% of energy is transferred to next trophic level • Much of the energy is lost as heat

  33. Food chain Food web • Branching network of many consumers • Consumers more likely to survive with alternative food sources • Primary producer • Herbivore • One or more carnivores

  34. Foodwebs are more complex & more realistic • Consumers often operate at two or more levels http://users.aber.ac.uk/pmm1

  35. Marine fisheries • Commercial fishing • Most tonnage from continental shelves and coastal fisheries, compared to open ocean fisheries • Over 20% of catch from areas of upwelling that make up 0.1% of ocean surface area Fig. 13.23

  36. Overfishing • Taking more fish than is sustainable over long periods • Remaining fish younger, smaller • About 30% of fish stocks depleted or overfished • About 47% fished at biological limit

  37. Aquaculture becoming a more significant component of world fisheries

  38. Incidental catch or bycatch • Bycatch - Non-commercial species (or juveniles of commercial species) taken incidentally by commercial fishers • Bycatch may be 25% or 800% of commercial fish • Birds, turtles, dolphins, sharks http://www.motherjones.com/news/featurex/2006/03/bycatch_265x181.jpg

  39. Incidental catch or bycatch • Technology to help reduce bycatch • Dolphin-safe tuna • TEDs – turtle exclusion devices • Driftnets or gill nets banned in 1989 • Gill nets banned in Florida by constitutional amendment in 1994 http://www.st.nmfs.noaa.gov/st4/images/TurtTEDBlu_small.jpg

  40. http://www.cefas.co.uk/media/70062/fig10b.gif Fisheries management Plaice • Regulate fishing • Closings – Cod fisheries of New England • Seasons • Size limits • Minimum size limits –protects juveniles, less effective • Min/max size (slot) limits – preserves juvs and larger adults (contribute most reproductive effort) http://www.cefas.co.uk/media/70037/fig7b.gif

  41. Fisheries management • Conflicting interests • Conservation vs. economic – “tragedy of the commons” • Self-sustaining marine ecosystems • Human employment • International waters • Enforcement difficult “Tragedy of the commons” – All participants must agree to conserve the commons, but any one can force the destruction of the commons http://farm1.static.flickr.com/178/380993834_09864a282c.jpg

  42. Fisheries management • Consumer choices in seafood • Consume and purchase seafood from healthy, thriving fisheries • Examples, farmed seafood, Alaska salmon • Avoid overfished or depleted seafood • Examples, bluefin tuna, shark, shrimp, swordfish • Visit: ORCA's Blue Diet page http://marineresearch.ca/hawaii/wp-content/uploads/tuna-auction-largeview.jpg

  43. Figure 13.28
