Advanced services and multicast deployment

Advanced Services and Multicast Deployment

Pierre Vander VorstSolutions ArchitectWWSP Carrier Ethernet


Agenda
Agenda

  • Advanced Services

  • Lifecycle Methodology

    • Prepare

    • Plan

    • Design

    • Implement

    • Operate

    • Optimize

  • Conclusion



Cisco advanced services
Cisco Advanced Services

  • Using the Cisco Lifecycle Services approach, Cisco provide a broad portfolio of services that address all aspects of deploying, operating, and optimizing your network to help increase business value and return on investment

  • Cisco Advanced Services is a Worldwide organization, which delivers services on a Technology basis

  • Services can be

    • Reactive – Technical Support

    • Proactive – Network Operations Subscription

    • Projects - Transactional



A lifecycle approach to service and support

Coordinated Planning and Strategy

Make Sound Financial Decisions

OperationalExcellence

Adapt to Changing Business Requirements

AssessReadiness

Can Your Network Support the Proposed System?

Optimize

MaintainNetworkHealth

Manage, Resolve, Repair, Replace

DesigntheSolution

Products, Service, Support Aligned to Requirements

Plan

Design

Implement

Operate

Prepare

ImplementtheSolution

Integrate Without Disruption or Causing Vulnerability

A Lifecycle Approach to Service and Support

Cisco

Partner

Customer


Advanced services and multicast deployment

The Lifecycle Services approach defines the minimum set of activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

Optimize

Design

Plan

Implement

Operate

Prepare

Carrier Ethernet Service Lifecycle ProgramServices offering for Multicast Deployment

Business Modeling

Competitive Assessments

Regulatory/Financial Environments

Content Acquisition

Network/Operational Assessment

  • Network Audit and Roadmap

  • High Level Network Design

  • System/sub-system specifications doc

  • System Security policies

  • Lab criteria

  • System test plans

Operational Assessments

Network health check

Service Level Agreement

Network Change Support

Optimization Consulting

Education/Training

Organizational Design

Service Provisioning Scripts

Call Handling Scripts

Subscriber Satisfaction Measurement System

Service Assurance reference doc

Monitoring tools reference doc

Inventory/config. Management system

Staging/Inventory Management

Functional Design

Wiring Design

Component Engineering

Low Level Design Document

Network Maps

Test plans

Site Survey

Material Logistics

Vendor Management

Site Labor and Management

Commission and Test


Advanced services and multicast deployment

Plan activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

Prepare

Metro Ethernet Services Lifecycle ProgramPrepare & Plan deliverables

  • Prepare

    • Requirements

    • Business Plan

  • Plan

    • Network Audit

    • High level design

    • Lab criteria

    • System test plans


  • Advanced services and multicast deployment

    Prepare activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramPrepare

    • Requirements for the Multicast Application – IPTV as an example

      • 200-300 SD TV, 2-3.5 Mbps each

      • 10-20 HD TV, 6-20 Mbps each

      • Few sources, usually centralized

      • Redundancy between sources is always required

      • Load-balancing between sources is not always required

      • Number of subscribers

    • Example of requirements


    Advanced services and multicast deployment

    Plan activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramPlan

    • High Level Design


    Advanced services and multicast deployment

    Plan activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramPlan

    • Network Audit for Multicast delivery

      • Provide an assessment and review the readiness of the existing IP network infrastructure for delivering Multicast Service

      • Advise customers in preparing the network to meet Multicast requirements without impacting existing services

      • Analyze the network in terms of capacity, quality of services, security, high availability, bandwidth available

      • Example findings

        • Upgrade network link capacity to accommodate projected traffic

        • Introduce DiffServ-based QoS to differentiate between traffic types

        • Ensure consistent deployment of high availability mechanism

        • Define subscriber density guidelines

        • Add redundancy to eliminate significant single points of failure


    Advanced services and multicast deployment

    Implement activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Design

    Carrier Ethernet Services Lifecycle ProgramDesign & Implement deliverables

    • Design:

      • Low Level design

      • Network maps

      • Test plan

    • Implement:

      • Commission

      • Test


    Advanced services and multicast deployment

    Design activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramDesign – Multiple Options

    • Architecture supports multiple models for delivering Multicast

    • Native Multicast in the global routing table

      • Native Multicast in a VRF/VPN

      • Point-to-Point Pseudowire (MPLS/L2VPN)

      • Multipoint Pseudowire (VPLS)

      • Routed Pseudowire

      • Multicast VLAN Registration (MVR) for Layer2 access

      • Multicast VPN (mVPN) based on mGRE

  • The choice depends on criteria like customer requirements, definition of the Multicast Application, type of Video delivery, Security, Convergence Time


  • Advanced services and multicast deployment

    Design activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramDesign - Multicast Source Discovery Protocol

    Option 1 - MSDP with unique Rendez-Vous Point (Anycast RP)

    • Redundancy is achieved with good convergence (unicast routing is the convergence time)

    • Load-Sharing between the two RPs is a plus

    • Load-Sharing depends on topology, not on group range

    • Can work in sparse-mode only (no need for sparse-dense)

    • Can be combined with RP hierarchies

    • Very robust, but the RP address needs to be configured on every router

    • Security is part of the protocol (SA Filtering and conditional Register)

    • Very good option when Source redundancy needs to be achieved on a geographical based (redundancy between cities for national TV channels and not regional)


    Advanced services and multicast deployment

    Design activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Carrier Ethernet Services Lifecycle ProgramDesign – Source Specific Multicast

    Option 2 - SSM

    • Very convenient for One-to-Many applications

    • If sources are static, SSM Mapping can be used

    • No need of RP engineering, no Shared Tree

    • Easy to maintain and configure, especially with static mapping

    • No packet loss due to Shared Tree to Shortest Path Tree Failover

    • Redundancy between sources can be achieved with Anycast IP

    • Very good option when Source redundancy does not need to be achieved on a geographical based (redundancy between sources in the same cities)


    Advanced services and multicast deployment

    Implement activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Metro Ethernet Services Lifecycle ProgramImplement

    • Advanced Services can be responsible for the deployment, the implementation, and the testing of the network

    • Phasing approach

      • Staging

      • Implementation

      • Test Plan

      • Migration of the existing services


    Advanced services and multicast deployment

    Optimize activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Operate

    Carrier Ethernet Services Lifecycle ProgramOperate & Optimize deliverables

    • Operate

      • Education and training

    • Optimize

      • Network Health Check


    Advanced services and multicast deployment

    Prepare activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    Plan

    Design

    Operates

    Operates

    Carrier Ethernet Services Lifecycle ProgramEngineering Documents

    • During the Lifecycle, Cisco Advanced Services delivers the engineering documents:

      • High Level Design

      • Network Audit

      • Low Level Design

      • Network Implementation Plan

      • Network Staging Plan

      • Network Ready For Use

      • Network Migration Plan

      • Transfer of Information


    Advanced services and multicast deployment

    Carrier Ethernet Services activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.Typical Customers

    • Reference Architecture

      • MPLS

      • BGP Free core

      • Layer 3 up to the Aggregation

      • Layer 2 with MST at the Access

      • One VLAN per service per Access Node

    • Services

      • L2VPN

      • E-LINE, E-LAN, VPLS

      • MPLS L3VPN

      • Residential Voice

      • Residential Video

    • Type of Deployment

      • Greenfield

      • Migration of an existing network into IP NGN

      • Country transformation

    • Platforms

      • Core:

        • CRS-1 4 or 8 slots

      • Distribution and Aggregation:

        • Cisco7609 with ES20 uplink and downlink

        • ME6524

        • Catalyst4500

      • Access:

        • Cisco3750

        • ME3400

        • ME6524


    Conclusion

    Conclusion activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.


    Conclusion1
    Conclusion activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.

    • Cisco Advanced Services is committed to work with the partners and the customers to deploy Multicast services on the network

    • Cisco Advanced Services has adopted the Lifecycle of the network as methodology

    • Deliverables are associated to every phase

    • Cisco Advanced Services has proven to be able to successfully deploy large and complex infrastructure


    Questions answers

    Questions & Answers activities needed, by technology and by network complexity, to help you successfully deploy and operate Cisco Metro Ethernet solutions and optimize performance throughout the network lifecycle.
