70 284 mcse guide to microsoft exchange server 2003 administration

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

Chapter Five

Managing Addresses

objectives
Objectives
  • Understand and create the different types of address lists that are used within Exchange Server 2003
  • Understand how recipient policies work
  • Describe how the Recipient Update Service works

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

managing addresses
Managing Addresses
  • Recipient: represents a resource in Active Directory
    • Examples: mailbox, public folder, Internet newsgroup
  • Global Address List (GAL): list of all messaging recipients
  • Custom address list: groups recipients in GAL by attributes
  • Offline address list: provides downloadable copy of address list(s)
  • Recipient Update Service (RUS): builds and maintains address lists

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

address lists
Address Lists
  • Reach of Global Address Lists (GALs):
    • List of recipients in Exchange Server 2003 organization
    • List of users within a foreign system; e.g. Lotus Notes
      • Requires a dedicated connector (Lotus Notes Connector)
  • Three components of internal GAL:
    • Default address lists
    • Custom address lists
    • Offline address lists

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

default address lists
Default Address Lists
  • Set up by default with the installation of Exchange Server
  • Organizes presentation of recipient information
  • Default address lists may be tailored to an organization

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

custom address lists
Custom Address Lists
  • Custom Address Lists: based on Active Directory attributes that can be queried
    • Examples: location, department, teams
  • To create a custom address list
    • Define to whom the policy will be applied
    • Use a Find command to select/filter desired recipients
      • LDAP (Lightweight Directory Access Protocol) query
    • Three choices for restricting membership
      • By specific recipient types
      • By specific server or mailbox store
      • By criteria set in a custom LDAP filter

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

custom address lists continued
Custom Address Lists (continued)
  • Five ways to restrict membership in an address list
    • Users with an Exchange Mailbox
    • Users with external e-mail addresses
    • Groups
    • Contacts
    • Public folders
  • Three ways to limit membership based on storage location
    • Mailboxes on any server
    • Mailboxes on this server
    • Mailboxes in this mailbox store

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

custom address lists continued9
Custom Address Lists (continued)
  • Create a custom query filter for granular control
    • Enables fine-tuning of membership list
    • Multiple filter rules are allowed
  • To create custom query filters
    • Define Active Directory field, condition, and search value
      • Filter rules use a logical AND to form an LDAP query
        • All conditions must be met for the recipient to be a list member
      • Identification process for eligible recipients compares the value in the Find Exchange Recipients dialog box to the value in Active Directory

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 1 creating a new address list
Activity 5-1: Creating a New Address List
  • Time Required: 10 to 20 minutes
  • Objective: Create a new address list for an Exchange Server 2003 organization
  • Description: Create a new address list to identify the users within the city associated with each particular server

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 2 nesting address lists
Activity 5-2: Nesting Address Lists
  • Time Required: 10 to 20 minutes
  • Objective: Nest address lists within an existing address list
  • Description: Create a nested address list under the country address list from previous activity

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 3 assigning permissions to address lists
Activity 5-3: Assigning Permissions to Address Lists
  • Time Required: 30 to 40 minutes
  • Objective: Set the permissions on an address list so that recipients can see their own respective address list and the address lists of other users
  • Description: Assign permissions so that only a select set of individuals can see it

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 4 change the display order of names within the global address list
Activity 5-4: Change the Display Order of Names Within the Global Address List
  • Time Required: 10 to 20 minutes
  • Objective: Change the display format for names within the GAL from “Firstname Lastname” format to “Lastname, Firstname” format
  • Description: Configure Active Directory to change the display format of the display name within the GAL from “Firstname Lastname” to “Lastname, Firstname” format

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 5 configure clients to make use of address list
Activity 5-5: Configure Clients to Make Use of Address List
  • Time Required: 10 to 20 minutes
  • Objective: Configure Outlook to make use of a custom address list
  • Description: Configure Outlook to make use of the custom City Recipient List Address list that was created in previous activity

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

offline address lists
Offline Address Lists
  • Set of address lists in files created and stored on the offline address lists server
  • Default offline address list is:
    • Created when Exchange 2003 server is installed
    • Based on the Default Global Address List
  • Multiple offline address lists may be created
  • Mailbox store is associated with offline address lists
  • Users with mailboxes on store may download list

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 6 configuring an offline address list
Activity 5-6: Configuring an Offline Address List
  • Time Required: 10 to 20 minutes
  • Objective: Configure an offline address list on your server
  • Description: Configure an offline address list that will be composed of the Default Global Address List and previously created custom address lists

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 7 configuring clients to make use of offline address lists
Activity 5-7: Configuring Clients to Make Use Of Offline Address Lists
  • Time Required: 5 to 10 minutes
  • Objective: Configure an Outlook client to make use of an offline address list
  • Description: Configure your Outlook client to make use of offline address lists

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

recipient policies
Recipient Policies
  • Recipient policy: collection of configuration settings applied to Exchange objects
  • Two types of recipient policies are available
    • Mailbox Manager
    • E-mail address
  • Recipient policies are applied with LDAP queries
  • Tasks performed by default recipient policy:
    • Creates SMTP and X.400 addresses for all mail-enabled objects
    • Configures e-mail address for components (cc:Mail)

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

e mail address recipient policies
E-mail Address Recipient Policies
  • E-mail address recipient policies:
    • Control e-mail address generation in organization
    • Used to establish new global default e-mail addresses
  • Multiple e-mail address recipient policies may be created
  • Filters allow for the selective application of policies

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 8 creating an e mail address recipient policy
Activity 5-8: Creating an E-mail Address Recipient Policy
  • Time Required: 10 to 20 minutes
  • Objective: Create an e-mail address recipient policy to configure a primary address to represent your organization
  • Description: Create an e-mail address recipient policy that will be used to stamp your users with the organization name

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 9 creating exceptions to e mail address recipient policies
Activity 5-9: Creating Exceptions to E-mail Address Recipient Policies
  • Time Required: 5 to 10 minutes
  • Objective: Exclude individuals from having e-mail address recipient policies applied to them
  • Description: Modify a test user created on your server to exclude her from having e-mail address recipient policies applied to her

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

mailbox manager recipient policies
Mailbox Manager Recipient Policies
  • Mailbox Manager recipient policies:
    • Tracks mailbox usage
    • Notifies users to cleanup messages
    • May perform cleanup by moving or deleting messages
  • Messages processed according to storage folder
  • Default triggers for Mailbox Manager processing:
    • Items in folder longer than 30 days
    • Items larger than 1 MB

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

mailbox manager recipient policies continued
Mailbox Manager Recipient Policies (continued)
  • Four message processing options are available
    • Generate Report Only
    • Move to Deleted Items Folder
    • Move to System Cleanup Folders
    • Delete Immediately
  • Policies may be applied to all mailbox-enabled objects
  • Activating Mailbox Manager is a two-part process
    • Create and configure Mailbox Manager recipient policy
    • Specify when and how mailbox management occurs
  • Multiple Mailbox Manager policies may be created

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 10 creating a mailbox manager policy
Activity 5-10: Creating a Mailbox Manager Policy
  • Time Required: 10 to 20 minutes
  • Objective: Create a Mailbox Manager policy that will notify users when they should clean up their mailboxes
  • Description: Creating a Mailbox Manager policy helps users to be aware that they need to clean up their mailboxes on occasion

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

recipient update service
Recipient Update Service
  • Recipient Update Service (RUS):
    • Builds and maintains address lists
    • Creates and maintains Exchange Server 2003 attribute values in Active Directory
  • RUS runs as a thread of the System Attendant Service
  • Two default RUS objects are created
    • RUS (Enterprise Configuration)
    • RUS (installation Active Directory domain)
  • An additional RUS is needed if the server has recipients

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

recipient update service continued
Recipient Update Service (continued)
  • RUS responsibilities:
    • Automatic generation of SMTP addresses
    • Automatic generation of proxy addresses
    • Stamping proxyAddresses attribute on recipient objects in Active Directory
  • RUS searches for objects to update in three ways
    • Update only new and modified objects
    • Update all objects by initiating a Rebuild event
    • Update objects corresponding to specific recipient policy

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

updating new and modified objects
Updating New and Modified Objects
  • Default RUS behavior includes updating new and modified objects each time it runs
    • Running frequency is once a minute
  • RUS tracks changes occurring on the domain controller
  • Three events that cause RUS to update recipient objects:
    • New recipients
    • New address lists
    • Changes to existing address list

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

activity 5 11 scheduling e mail address recipient policy updates
Activity 5-11: Scheduling E-mail Address Recipient Policy Updates
  • Time Required: 5 to 10 minutes
  • Objective: Modify the schedule with which the RUS applies recipient policies
  • Description: Configure the RUS to make modifications to e-mail addresses based on recipient policy changes

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

updating all objects
Updating All Objects
  • To update all objects, use the Rebuild option in Exchange System Manager
  • Sequence of events following the selection of Rebuild:
    • Set msExchDoFullReplication attribute to true
    • RUS started by schedule of Update Now command
    • RUS looks at all objects in Active Directory
    • Rebuild process is completed
    • msExchDoFullReplication is set back to false

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

updating objects corresponding to a specific policy
Updating Objects Corresponding to a Specific Policy
  • Filter on policy causes the RUS to take modified action
  • Steps to altering a RUS default behavior:
    • Modify filter on policy
    • RUS queries for users who match the new and old filter
    • msExchPoliciesIncluded attribute reset
    • Administrator uses Apply Now option to apply the policy
  • Three-step RUS decision process:
    • RUS determines the recipient policy to apply to the object
    • RUS determines whether the recipient is new
    • RUS adds selected primary address of type (if needed)

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

updating objects corresponding to a specific policy continued
Updating Objects Corresponding to a Specific Policy (continued)
  • Conditions for the RUS to regenerate a primary address:
    • Recipient policy has been applied
    • gatewayProxy attribute is populated
  • Conditions for adding secondary addresses:
    • When recipient is new
    • Policy has already been applied
  • Be cautious if clearing the check box for a primary address
    • All addresses of that type are removed when the policy is applied

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

summary
Summary
  • GALs are composed of several address lists
  • Default address lists are created when Exchange Server 2003 installed
  • Custom address lists are built on Active Directory attributes available for query
  • To create an address list, define to whom the policy will be applied
  • Select and filter recipients based on an LDAP query

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

summary continued
Summary (continued)
  • Multiple ways to group recipients in an address list
  • GAL should be listed before other types of lists
  • Offline address list is created and stored on an offline address list server
  • Policy is collection of configuration settings applied to Exchange objects
  • Two types of policies are available in Exchange Server 2003

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration

summary continued49
Summary (continued)
  • E-mail address recipient policies control e-mail address generation
  • Mailbox Manager tracks mailbox usage
  • Mailbox Manager recommends or performs cleanup
  • RUS builds and manages address lists
  • RUS creates and maintains Exchange Server 2003 specific attribute values

70-284 MCSE Guide to Microsoft Exchange Server 2003 Administration
