  1. AUTOTEST ELECTRICS ANALYSER 1

  2. DC Volts Current Probe Amps True RMS AC Volts Peak to Peak Volts Pulse Width and Duty Cycle Frequency and RPM Ambient Temperature Ohms with Continuity Beep Diode Voltage Test AutoTest Features Leads Volts 0.00 V Clips Volts 0.00 V Probe Amps 0.00 A Clips Temp. 27°C  • Powerful Managed Test • Simple Simulated Loaded Voltage (SLV) Battery Test • Starter Motor Test • Full Multimeter Function 2

  3. ON MANAGED TEST 3

  4. The Managed Test Leads Volts 0.00 V Clips Volts 0.00 V Probe Amps 0.00 A Clips Temp. 27°C  • Checks that the Battery post to clamp connection is OK • Tests for Battery shorted cells • Tests for a sulphated Battery that will not recover with charging • To protect the vehicle’s electronics, AutoTest checks that a flat Battery will accept charge before advice to jump start is given • Tests the vehicle’s charging system • Tests the vehicle’s Battery condition • Stores test results for printing or download to a computer 4

  5. The Managed Test Leads Volts 0.00 V Clips Volts 0.00 V Probe Amps 0.00 A Clips Temp. 27°C  To enter the Managed Test AutoTest must be in the “Home Screen” as shown here. From the Home Screen press the “ON” button once. 5

  6. Managed Mode. All accessories and lights should be off and doors closed. CARBATTERY ! 6

  7. Managed Mode. All accessories and lights should be off and doors closed. Start of the Managed Test Ensure there are no electrical loads on the battery by closing all the doors and switching off all the vehicle’s lights and accessories 7

  8. Attach test clips to both CLAMPS. Hold amps probe next to GROUND lead. ENTER First, attach the test clips to the clamps (surrounding the battery posts). Next, hold the amps probe in the same orientation it will be when clamped to the battery ground lead but hold it next to the lead so that it can be zeroed before it is attached. 8

  9. Attach clips to both CLAMPS. Hold amps probe next to GROUND lead ENTER CARBATTERY ! 9

  10. Attach clips to both CLAMPS. Hold amps probe next to GROUND lead ENTER CARBATTERY ! 10

  11. Attach clips to both CLAMPS. Hold amps probe next to GROUND lead ENTER CARBATTERY ! 11

  12. Attach clips to both CLAMPS. Hold amps probe next to GROUND lead ENTER CARBATTERY ! 12

  13. Attach amps probe to battery GROUND lead. Attach clips to both POSTS. ENTER Now open the amps probe and clamp it around all the wires attached to the negative battery terminal. Then, move the test clips so that the long jaw of each clip contacts the lead battery posts. The clip’s short jaw can contact the battery post or clamp. 13

  14. Attach amps probe to battery GROUND lead. Attach clips to both POSTS. ENTER CARBATTERY ! 14

  15. Attach amps probe to battery GROUND lead. Attach clips to both POSTS. ENTER CARBATTERY ! 15

  16. Attach amps probe to battery GROUND lead. Attach clips to both POSTS. ENTER CARBATTERY ! 16

  17. Enter battery CCA 400 (SAE) ENTER Use the up and down arrows to select the test battery size (its CCA rating). The measurement standard used for battery size is shown in brackets. Australia and the USA use SAE while Europe uses mostly DIN or Ah. In the demonstration test the test battery size is 350 (SAE). 17

  18. Enter battery CCA 350 (SAE) ENTER CARBATTERY ! 18

  19. ENTER Screening Tests Continue Managed Test Battery Rejected. High Resistance DON’T JUMP START Battery Rejected.Suspected Shorted Cell Clean & Retest Battery Terminals Corroded 19

  20. CONNECT jumper leads GROUND to CHASSIS LAST. Start service vehicle ENTER The demonstration test battery has passed the screening tests but AutoTest has detected that it is too discharged to start the test vehicle so it prompts for jumper leads (booster cables) to be connected and for the service vehicle to be started. 20

  21. Connect Jumper Leads GROUND to CHASSIS LAST. Start service vehicle ENTER CARBATTERY ! 21

  22. Connect Jumper Leads GROUND to CHASSIS LAST. Start service vehicle ENTER Chassis/Engine Earth CARBATTERY ! 22

  23. Testing battery Do not start motor Vch 13.95 Ich 35.2 please wait 0:20 Bad Cell Test Battery RejectedInter-cell fault DO NOT JUMP START Continue Managed Test Sequence AutoTest knows that the test battery is connected to a good charging system (the service vehicle’s) it now tests that the battery is accepting charge and tests that it does not have a bad cell condition. 23

  24. STOP service vehicle Start TEST vehicle Amps 120.2 ENTER The demonstration test battery does not have a bad cell and it’s charge acceptance is OK so AutoTest prompts for the test vehicle to be jump started. The amps reading at the bottom of the screen can be used to get an indication of the starter motor current draw during engine cranking. 24

  25. V 14.22 I 12.1 Check batt recovery. REMOVE jumper leads if OK. ENTER This screen asks the operator to check that the vehicle will not stall once the jumper leads are removed. When the charge voltage is OK and the test battery is accepting a good amount of charge, then the jumper leads should be removed. 25

  26. V 14.22 I 12.1 Check batt recovery REMOVE jumper leads If OK ENTER CARBATTERY ! 26

  27. V 14.22 I 12.1 Check batt recovery REMOVE jumper leads If OK ENTER CARBATTERY ! 27

  28. Testing alternator. Do not stop motor. Vch 13.96 Ich 13.2 Please wait 4:20 CARBATTERY ! 28

  29. Testing alternator. Do not stop motor. Vch 13.96 Ich 13.2 Please wait 4:20 AutoTest now has the test battery connected to the test vehicle’s charging system. This period of testing is called dynamic testing. Firstly, AutoTest checks the alternator to make sure it is charging the test battery properly. 29

  30. Testing battery. Do not stop motor. Vch 14.22 Ich 13.2 Please wait 4:01 Next, AutoTest checks the battery. The amount of time AutoTest takes to test the battery depends on the state of charge of the battery being tested. AutoTest allows more time for a discharged battery to “come good” during charge than it does for a well charged battery. 30

  31. Testing battery Do not stop motor Vch 14.22 Ich 18.2 Please wait 0:10 Was battery OK for Drain Test at start of Managed Test? Continue Managed Test No Yes Test Completed Continue toresults display 31

  32. Vch 14.24 Ich 18.4 Drain Test Stop motor ONLY if OK. ENTER The test battery was too discharged to reveal a current drain at the start of the managed test (when it is usually performed). Because the amps probe has been measuring high amps during cranking and charging, it must be re-zeroed before looking for a small key-off current drain. 32

  33. REMOVE amps probe and place next to battery GROUND lead. ENTER CARBATTERY ! 33

  34. REMOVE amps probe and place next to battery GROUND lead. ENTER CARBATTERY ! 34

  35. REMOVE amps probe and place next to battery GROUND lead. ENTER CARBATTERY ! 35

  36. ATTACH amps probe to battery ground lead Amps 0.00 ENTER CARBATTERY ! 36

  37. ATTACH amps probe to battery ground lead Amps 0.78 ENTER CARBATTERY ! 37

  38. Managed Mode Test Completed Batt Pass/Needs Chrg Alt/Reg Pass Drain Suspect  • Results Screen 1 shows that • the battery is OK but needs charge • the alternator/regulator combination is OK • the key-off current drain is high • and should be checked further 38

  39. Batt Pass/Needs Chrg Alt/Reg Pass Drain Suspect  CARBATTERY ! 39

  40. Battery OCV 7.59V Drain Amps 0.78A Clamp Drop 0.01V  • Results Screen 2 shows more detail • the open circuit voltage OCV (or no load voltage) was 7.59 Volts when the clips were first connected to the battery • the key-off current drain was 0.78 Amps • the drop in loaded volts between • the battery clamp and battery • post was 0.01 Volts 40

  41. Battery OCV 7.59V Drain Amps 0.78A Clamp Drop 0.01V  CARBATTERY ! 41

  42. Charge Volts 13.96V Charge Amps 13.60A Alt ripple 50.5mV  • Results Screen 3 shows results achieved during the course of the Alternator/Regulator test (one of the dynamic tests performed as part of the managed test). It shows • the highest charge voltage was 13.96 Volts • the highest charge current was 13.60 Amps • the ripple voltage produced by the • diodes of the alternator during • charge was 50.5 milli-Volts 42

  43. Charge Volts 13.96V Charge Amps 13.60A Alt ripple 50.5mV  CARBATTERY ! 43

  44. Battery LV 9.63V Accum Ah 1.06A Battery Res 11.6m  • Results Screen 4 shows results achieved during the course of the Battery test (one of the dynamic tests performed as part of the managed test). It shows that the test battery’s • loaded volts (LV) was 9.63 Volts • charge accumulation during the whole managed test was 1.06 Amp hours • internal resistance was 11.6 milli- • Ohms 44

  45. BATTERY SLV STARTER TEST 45

  46. Test indicates the battery’s condition as a percentage Results also shown as the Simulated Loaded Volts or SLV (the result that would be achieved by a loaded voltage test using a ½ CCA current 15 second discharge) The Monitor Screen gives a “live” update of the battery condition during battery charge/discharge The Battery SLV Test Leads Volts 0.00 V Clips Volts 0.00 V Probe Amps 0.00 A Clips Temp. 27°C  • Almost instant two line description of the test result 46

  47. The Battery SLV Test Leads Volts 0.00 V Clips Volts 0.00 V Probe Amps 0.00 A Clips Temp. 27°C  To enter the SLV Test AutoTest must be in the “Home Screen”as shown here. From the Home Screen press the “BATTERY SLV” button once. 47

  48. Battery SLV Test CONNECT Clips CARBATTERY ! 48

  49. Battery SLV Test Enter Battery CCA 400 (SAE) ENTER CARBATTERY ! 49

  50. Battery SLV Test Enter Battery CCA 400 (SAE) ENTER Use the up and down arrows to select the test battery size (its CCA rating). The measurement standard used for battery size is shown in brackets. Australia and the USA use SAE while Europe uses mostly DIN or Ah. In the demonstration test the test battery size is 350 (SAE). 50
