oracle clinical remote data capture system rdc presentation

Oracle Clinical Remote Data Capture System (RDC) Presentation

Introduction to RDC Application (v4.5.0)

please note
***Please Note***

The information contained in the following presentation is for the general training and review of Investigator Sites and employees of Biogen Idec participating in studies utilizing Oracle Clinical Remote Data Capture.

This presentation should not be reproduced, republished or retransmitted without the prior consent of Biogen Idec.

  • Discussion of RDC
  • Log-in and Navigation of RDC
      • Demonstration
  • Data Capture Procedures
      • Demonstration
  • Browsing Data
  • Discrepancy Management
      • Demonstration
  • Logging Off
  • eCRF Verification
  • eCRF Approval
  • Archival
  • Technical and Clinical Support
  • Q&A
what is rdc
What is RDC?
  • Remote Data Capture (RDC) is a Web-based tool used at Investigator Sites to record, store and manage clinical study data. This process allows for Investigator Site and Sponsors to view clinical data directly in the sponsors Oracle Clinical database at time of entry, address any discrepant data as needed and sign or approve electronic case report forms (eCRFs)
benefits of rdc
Benefits of RDC
  • Improves Overall Data Quality by allowing…
    • the Sponsor to have real time access to the data
    • discrepant data to be immediately identified and resolved in a timely manor
    • CRAs’ to monitor site data remotely and prepare for monitoring visits
  • No paper!
workflow in rdc
Workflow in RDC

Data entered by site staff

System-generated discrepancies

Site staff correct eCRF

Discrepancy closed by system, CRA or DM

Changes rejected

Site staff correct eCRF or comment on entered data

Validation checks

CRA reviews changes or comments

CRA performs SDV

Investigator approves eCRF Casebook

CRA verifies eCRF

*Manual discrepancies may be generated by the CRA or CDA anytime after data

has been source verified. These discrepancies will follow the same flow as above.

responsibilities within rdc
Responsibilities Within RDC
  • Study Coordinator
    • Data Entry and review of eCRFs
    • Review and Respond to Discrepancies
    • Create Investigator comments in data field when needed
    • Notify Investigator when eCRFs are ready for review and approval
  • Investigator
    • Data Entry and review of eCRFs
    • Review and Respond to Discrepancies
    • Approve (sign) eCRF Casebook
responsibilities within rdc8
Responsibilities Within RDC
  • Clinical Research Associate (CRA)
    • Review Data and create Manual Discrepancies when needed
    • Advise Site Coordinator with discrepancy and data entry questions
    • Close discrepancies
    • Perform Source Verification, marking the eCRFs as ‘verified’
  • Data Management
    • Review and perform cross checks of data and create Manual Discrepancies when needed
    • Provide metrics and status to Study Team
    • Advise CRA with discrepancy and data entry questions
    • Lock clean eCRFs
    • Lock Database
login initial information
LoginInitial Information
  • Prior to training you will receive…
    • Username and Password that will provide you with secure

access to the Biogen Idec web portal

    • Web address for Oracle Clinical RDC Training data base
    • Username and Password for OC-RDC
  • Post OC RDC training you will receive…
    • Access to OC-RDC Production data base
    • The same username and password will be used for both test and production data base
login passwords


  • Passwords must be changed after initial login
  • They must be at least 8 characters in length
  • Passwords will expire every 90 days
  • Passwords cannot be re-used

To be compliant with the FDA Guidelines: 21 CRF Part 11 it is imperative that you


login passwords12
  • To update your password
  • At the Log in Screen click on Change Password under the Login button
login launch application
LoginLaunch Application

Once logged into Biogen Idec Website…

  • Click on the following link to launch OC-RDC:

  • Click Log In
login launch application14
LoginLaunch Application

The OC RDC log in screen will appear


  • OC User Name
  • Password
  • Database Name (PCDS)

Click Connect to log in

log in launch application
Log InLaunch Application

A separate OC-RDC window will also appear

This screen must remain open to maintain your connection to OC RDC however you may click on the minimize icon if needed

log in launch study
Log InLaunch Study

If you have access to multiple studies the Change Study box will appear

  • Click the appropriate study
  • Click Ok

Note: If you only have access

to one study hit F9. This will

automatically select the study for you

navigation news updates
NavigationNews Updates
  • News Updates
      • Any news updates will appear in a centered pop-up window
        • News updates can be study related and will also be used to alert you to scheduled maintenance
        • Make use of scroll bars to review any new or existing news messages
        • If no news is available or active then the search window is automatically activated
navigation activities window
Navigation Activities Window

The activity list window will appear

The list allows you to choose the activity you would like to perform, you can browse all of the data, review eCRFs with discrepancies, or review eCRFs with discrepancies for other users.

navigation search window
Navigation Search Window
  • To refine your search you can click on Search an this window will appear

The Search Window provides you with the ability to filter on certain areas of data you would like to work on

navigation search window20
NavigationSearch Window

Using the search window you can :

  • Select and display only the casebook you need to work on
  • Select and display multiple patients by visit or visit date
  • Browse certain types of eCRFs
  • Search for eCRFs that need to be verified and/or signed by the Investigator

Note:If no data has been entered for a site then at least the patient must be selected

navigation search window criteria
NavigationSearch Window Criteria

Search Window Criteria

  • Book: Dependent on type of study:
        • Non cohort studies use only one book which will default
        • For Cohort studies select the appropriate book assigned by patient
  • Site: Study sites will use their default Site, CRAs with more than one site will need to select the appropriate site
  • Patients: Used to define a range of patients by study number
navigation search window criteria22
NavigationSearch Window Criteria
  • Visits/Pages: Used to define a range of visits/pages
  • CRF Status:
    • Used to filter for complete, partially complete or blank eCRF’s
    • Discrepancy status can be used to filter for actionable (red), un-actionable (yellow) or eCRF’s which have no discrepancies
    • CRA’s can filter for Unverified pages to prepare for their next monitoring visit
    • Approved eCRFs can be used to confirm that the Investigator has approved the data on each of the subjects at their site.
navigation search window criteria23
Navigation Search Window Criteria
  • Date Window: Can be used to define the Date range that a page was initially entered:
  • Data: Specific drill down menu which can be used to filter on specific data points entered
navigation oc rdc spreadsheet
NavigationOC-RDC Spreadsheet

Once you select the search criteria the OC-RDC Spreadsheet will appear

navigation oc rdc spreadsheet25
NavigationOC-RDC Spreadsheet

Spreadsheet screen set up:

  • Rows = Patients (Additional patients can be displayed by using the drop down)
  • Columns = Pages
  • Tabs = Visit (Tabs Drop Down should always display by Visit)
navigation menu and tool bar
NavigationMenu and Tool Bar

OC-RDC navigation functions are similar to Microsoft Windows

  • Example

Use the Menu Bar to..

        • File Save
        • Insert Patient

Use the Tool Bar to…

Add a Patient

Add Investigator Comment

Create a Manual Discrepancy

navigation key commands
NavigationKey Commands

Use Key Commands to…

  • Perform all the same tasks you would using your mouse

Example: Press Alt + I to select Insert function from the drop down menu. From this menu, Alt + T will insert a new patient

…..Or use Function Key during eCRF entry/review to…

F6 Insert Patient

F10 Save

CTRL + U Clear Data Field

CTRL + Shift + F11 Add Operator Comment

F1 Get Help

navigation oc rdc icons
NavigationOC-RDC Icons
  • For eCRF icon description

Click on Help RDC Help Topics

navigation selecting a patient
NavigationSelecting a Patient
  • If more than eight patients are selected from the search window then a drop down box is available…
      • Click on the drop down box and the patients are listed in groups of eight in numerical order
      • Click on the necessary group and the patients within that group will be displayed on the main screen
navigation selecting an ecrf
NavigationSelecting an eCRF
  • Once a patient is selected…
    • Click on appropriate tab to select desired visit
  • Note: If desired visit is not displayed at the top, click on the to display additional visits
    • Use the bottom navigation bar to view all eCRFs scheduled per visit
  • Example: Screening Visit may have 15 expected pages but only 11 are displayed
navigation selecting an ecrf31
NavigationSelecting an eCRF
  • To Open a new eCRF….
    • Single Click in empty cell
    • eCRF Icon will appear
navigation task tabs
NavigationTask Tabs

Task Tabs

  • Summary – Overall Visit summary. If a page is clicked on, then the overall summary of that page is given
  • Discrepancies – Displays all the discrepancies for a specific page. It is from this tab that control of discrepancy management takes place
  • Verification – Tab used by CRA to verify eCRF’s
navigation task tabs33
NavigationTask Tabs
  • Approval – Tab used by Investigator to approve eCRF’s
  • Audit Trail – Tab used by all users to monitor changes made to data after initial entry has been saved

NOTE: If no eCRF is selected then only Study Information tab will be available

demonstration log in and navigation
DemonstrationLog In and Navigation
  • Key Point Summary
    • Log In to Biogen Idec Web Portal
    • Click on RDC link and Log in to OC-RDC
    • Select Study
    • Select Search Criteria
    • Select Patient
    • Select Visit
    • Open eCRF
    • Review Tool and Menu Bars
data capture procedures subject identification
Data Capture ProceduresSubject Identification
  • Patient numbers will be pre-entered by Data Management staff into the system when the subjects’ are randomized.
    • Subject ID numbers will be seven digits the first three digits will be the site number, then a (-) followed by the subject ID number.


  • The Study coordinator will select the appropriate patient number
  • This patient number will automatically populate on all eCRF pages for that subject
data capture procedures header information
Data Capture ProceduresHeader Information

Header Information

Do not enter any details (visit date or comment) in this section UNLESS no data will be collected for that eCRF. In that case only the Blank field can be used

data capture procedures marking an ecrf blank
Data Capture ProceduresMarking an eCRF Blank
  • To mark an eCRF Blank…
      • Click in the blank box in the header
      • Click OK on the Forms box

Note: Once Ok is clicked, the next eCRF for this patient will be displayed

data capture procedures marking an ecrf blank39
Data Capture ProceduresMarking an eCRF Blank
  • For eCRF sections that will not have data entered…..
        • Click on correct tab
        • Click the Blank box

This will automatically mark the section blank

data capture procedures marking an ecrf blank40
Data Capture ProceduresMarking an eCRF Blank

Pages that can be marked blank will be study specific and defined by the study team

data capture procedures expanding ecrf screen
Data Capture ProceduresExpanding eCRF Screen
  • To Expand eCRF Screen for better viewing…
      • Double Click on the Patient Information bar
  • Click and drag mouse to outline desired size
  • Press Done
data capture procedures data entry
Data Capture ProceduresData Entry

To display contents of eCRF, click in Visit field and Press Tab key

Begin Data Entry by typing in the responses and using the Tab Key to navigate from one field to another

Tip: Be sure to have the study specific eCRF Completion Guidelines to reference during entry – this will help avoid unnecessary discrepancies

data capture procedures list of values
Data Capture ProceduresList of Values

Some data fields are not enterable and will have a List of values (LOV) to choose from

To select from the LOV

  • Click on the LOV symbol ‘…’ or Press F9
  • Select from the LOV
  • Click Ok

This will place the selection in the data field

Tip: you can always Press F1 if you have any questions or need additional help

data capture procedures dates and times
Data Capture ProceduresDates and Times

Dates can be entered using the following formats:

  • mm/dd/yy
  • mm/dd/yyyy
  • mmddyy
  • mmddyyyy

Times should be entered using a 24-hour clock. After entering in the numerical value, press the Tab Key. OC-RDC will automatically add the ‘:’

  • Note: Certain date fields allow the entry of Partial Dates and other date fields will prompt a discrepancy stating the it is not a complete date. If the complete date is unknown it is best to close the discrepancy immediately.
data capture procedures log pages
Data Capture ProceduresLog Pages

Log Pages are kept at the end of the eCRF book and can be located by using the page drop down menu

Note: Log pages are displayed in numerical order and should be entered as such. If additional pages are needed then an Unplanned eCRF can be added

data capture procedures unplanned ecrf
Data Capture ProceduresUnplanned eCRF

Adding and Unplanned eCRF

From drop down menu select Insert Visit

Use drop down arrow in the right hand portion of window to select the appropriate eCRF

Tip: To easier identify the appropriate eCRF to select, please refer to eCRF Completion Guidelines for page name descriptions

data capture procedures unplanned visit
Data Capture ProceduresUnplanned Visit

Adding an unplanned visit

  • Open the current visit
  • From drop down menu select Insert Visit
  • Click Ok

Note: the Unplanned Visit will be inserted after the visit that is open, i.e. if an unplanned visit occurs post Visit 2 the cursor should be on Visit 2 when you add the visit.

data capture procedures indicator questions
Data Capture ProceduresIndicator Questions

Indicator Questions (Yes/No or Done/Not Done) will more easily direct the flow of data entry

Example: ‘Any data for this section?’ Y/N question:

  • If answered ‘Yes’, curser moves to the next data field on the eCRF
  • If answered ‘No’, entry skips to next question group or page

Note: Question Group is a group of questions with a common indicator, generally a polar question. eCRFs can have multiple questions groups.

data capture procedures repeating question groups
Data Capture ProceduresRepeating Question Groups

Repeating Question Groups

  • Repeating questions groups are usually displayed in a table format
  • An eCRF can have several repeating question groups
  • Once in a repeating question group question, the title bar will indicate how many records exist and which record you have currently selected.
data capture procedures delete row function
Data Capture ProceduresDelete Row Function
  • Data Entry for eCRFs with repeated questions groups will prompt an error message if the Tab Key is pressed in the last data field of a blank repeat
        • Click Ok
        • Select CRF from Menu Bar
        • Select Delete Row
        • Click to close eCRF

Note: This error message can be avoided it is best to click the on the top corner of the eCRF after entry is complete and avoid using the Tab Key

data capture procedures closing or deleting ecrfs
Data Capture ProceduresClosing or Deleting eCRFs
  • Closing an eCRF
      • Click on the “X” in the upper right hand corner of the eCRF


      • Press Tab Key when in last data field
  • Deleting an eCRF
        • Select eCRF
        • Use Drop-down menu “Edit Delete CRF”


        • Press Shift + F6 and select “Delete CRF”
  • Note: DO NOT click on the “X” on the Data Capture spreadsheet as this will result in closing down the RDC session and entered data may be lost
data capture procedures demonstration
Data Capture ProceduresDemonstration

Key Point Summary

  • Header Information
  • Marking eCRF and section of eCRF Blank
  • Expanding eCRF screen
  • Enterable Data Fields
  • Non Enterable Data Fields (LOV)
  • Dates and Times
  • Log Pages
  • Adding Unplanned eCRF
  • Adding Unplanned Visit
  • Indicator Questions and Question Groups
  • Repeating Question Groups and Delete Row Function
  • Closing an eCRF
  • Deleting an eCRF
browsing data54
Browsing Data

You can easily Browse Data by…

  • Using the Search Window function to select specific data


  • Using the Tab Key to go through each data field from eCRF to eCRF


  • Using your Mouse, Point and Click
browsing data demonstration
Browsing DataDemonstration
  • Key Point Summary
    • Search Window Function
    • Tab Key
    • Point and Click
discrepancy management types of discrepancies
Discrepancy ManagementTypes of Discrepancies

Types of Discrepancies:

  • Univariate Discrepanciesoccur immediately upon data entry for certain data fields and generate because data is considered incorrect or left blank
  • Multivariate Discrepanciesgenerate the next day after the Oracle Clinical system runs the new data through a batch validation process.
  • Manual Discrepancies usually created by CRA’s/Data Management during source verification/data review. Manual discrepancies DO NOT close automatically, meaning once the discrepancy is addressed the user will need to send to CRA to be closed

Note: To avoid an abundance of discrepancies, if possible - it is best to address the Univariate discrepancies immediately. If the discrepancy can not be addressed immediately, click Save to address at a later time.

discrepancy management identifying discrepancies59
Discrepancy ManagementIdentifying Discrepancies

Icon Description


  • requires action on your part in order to resolve (RED icon)


  • requires action on someone else’s part to resolve (YELLOW icon)

No Action

  • requires no action, no active (open) discrepancies (WHITE icon)
discrepancy management viewing discrepancies
Discrepancy ManagementViewing Discrepancies
  • To view active discrepancies…
      • Open on desired eCRF
      • Click on Discrepancies under Task Tab
discrepancy management resolving univariate multivariate discrepancies
Discrepancy ManagementResolving Univariate/Multivariate Discrepancies
  • Steps to Closing a Univariate or Multivariate Discrepancy
      • Update data point
      • Provide ‘Reason for Change’
      • Discrepancy will close out
  • OR
      • “Send to CRA” with an internal comment describing why error can not be corrected. CRA will close discrepancy when source verification has been completed.

Manual discrepancies DO NOT close automatically, meaning once the discrepancy is addressed the user will need to select the appropriate action to close.

discrepancy management resolving univariate multivariate discrepancies62
Discrepancy ManagementResolving Univariate/Multivariate Discrepancies

‘Reason for Change’…

  • automatically displays when a change is made to a Complete eCRF
  • is required for all updates to the database once the data has been entered and verified.

From the LOV, you may select only the following options:

      • Data Entry Error: select if error was made during data entry
      • Investigator Correction: select if changes are made to patient source date

Note: Reason for Change will be stored as an Audit to the data base

discrepancy management resolving manual discrepancies
Discrepancy ManagementResolving Manual Discrepancies
  • Steps to Resolving a Manual Discrepancy
      • Update data point
      • Add comment in the Internal Comment section describing the change or reason for no change
      • “Send to CRA”

Example: Does subject have any ongoing or resolved medical or surgical history? has been marked No, however source documentation indicates otherwise. Please update data accordingly.

discrepancy management routing discrepancies
Discrepancy ManagementRouting Discrepancies



Send to Data Manager



Send to CRA with Internal Comment

Discrepancy Closed Automatically or Manually by CRA



data management demonstration
Data ManagementDemonstration
  • Key Point Summary
    • Review Icons
    • View Discrepancies
    • Address Discrepancies
    • Routing Discrepancies
    • Creating an Manual Discrepancy
logging off67
Logging Off

To end your session:

  • Close any open eCRFs
  • Select File => Exit menu command from the main screen

Note: DO NOT click on the “X” on the Data Capture spreadsheet as this will result in closing down the RDC session and entered data may be lost

verification process69
Verification Process
  • Verification Process
    • Once the site has completed entry and all relevant discrepancies have been resolved for an eCRF, the page is ready for verification
      • CRA verifies the information recorded on the eCRF matches the information in the source documents
      • CRA marks the eCRF as verified
investigator approval71
Investigator Approval

Once the verification process is complete for all eCRFs

  • Data has been reviewed for logic and accuracy
  • All discrepancies are resolved

The casebook is ready for Investigator approval

  • The Investigator will select the appropriate Casebook and click on Approval Tab
  • Investigator must enter his/her Oracle Clinical password to grant approval status to the Casebook
21 crf part 11 electronic records signatures
21 CRF Part 11: Electronic Records & Signatures

Provides guidance that states the FDA will consider:

  • Electronic records equivalent to paper records
  • Electronic signatures equivalent to traditional handwritten signatures
archival of data74
Archival of Data

At the end of each study…

  • The RDC study will be decommissioned and on-line data will no longer be available to site staff
  • Each site will receive a CD containing data for their site patients only

CDs and will include:

      • Patient data entered
      • Patient discrepancy information
      • Audit trail information
technical and clinical support76
Technical and Clinical Support
  • Technical Support Help Desk


    • Toll free number is posted on the RDC web page.
    • Hours of technical support are 09:00 – 17:00 EST.
  • Call the help desk for any of the following issues:
    • Firewall issues at site
    • Forgotten passwords
    • Expired accounts
    • New Accounts
    • Notify Help Desk immediately if a user has left the study.

Under NO circumstances should anyone use another persons account for the purpose of data capture.

  • Clinical Support – Contact the lead CRA for the study for all clinical support
oc rdc review
OC-RDC Review
