appfabric caching how it works and when you should use it
MID302

AppFabric Caching: How It Works and When You Should Use It

Jon Flanders

Senior Consultant

MCW Technologies

agenda
Agenda
  • Why Caching?
  • What is AppFabric Cache?
  • On-Premise and in Azure
  • Demo, demo, demo
problems with typical architecture
Problems with typical architecture
  • Storing session in memory leads to scalability problems
    • Sticky sessions solve this
    • Most cloud providers don’t enable
  • Data tier is difficult to scale out
    • Portioning is one way
    • No product gives you this automatically
how do you scale this architecture
How do you scale this architecture?
  • Caching data from the data tier has been one typical pattern
  • Reduces load on database
  • Reduces network round-trips
  • Caching in memory of web tier can lead to cache coherency problems
    • CEO gets one good financial report from Web Node 1 – refreshes and gets bad financial report from Web Node 2
    • One of these is stale
definitions
Definitions
  • Caching
    • Storing a copy of data closer to application logic, away from its source
  • Distributed Caching
    • A set of nodes in a farm that coordinate to create a unified view of a cache to a caching client
  • Expiration
    • When an object is removed from the cache because of staleness
  • Eviction
    • When an object is removed from the cache due to low memory conditions
what is appfabric cache
What is AppFabric Cache?
  • A distributed cache for “data”
    • An in-memory cache (no paging to disk or persistence layer)
  • The “Data” can be
    • Any (serializable) CLR Object
    • XML
    • Binary data
  • Optimized for the cache-aside pattern (in this version)
    • Programming against the cache uses explicit API
    • Changing the cache doesn’t update the original data store
windows server appfabric cache
Windows *Server* AppFabric Cache
  • Cache runs on N nodes
    • Nodes that share configuration are part of a single Cache Cluster
    • Runs as a Windows Service (one service per server node)
    • Typically not the same servers as the client (web) tier
    • More memory is better
    • In-memory copy cache is optional setting (“Local Cache”)
  • All the cache nodes in a cluster are part of a fabric
    • Share configuration
    • Communicate
    • Cooperate
windows azure appfabric cache
Windows *Azure* AppFabric Cache
  • Essential if you are building Azure Web or Worker roles
  • APIs are identical
  • You don’t have to manage cache cluster
    • Can increase and decrease capacity using configuration rather than physical hosts
    • 128MB to 4GB per named cache – you don’t lose data when you increase cache size
    • Normal eviction policies apply if you decrease cache size
appfabric cache advantages
AppFabric Cache advantages
  • Native .NET API
  • Scalability
  • Performance
    • Typically linear as more nodes are added
    • LocalCache increases raw performance
  • High Availability
    • Distributed nature safeguards against cache client and server failures
current deltas between server and azure
Current deltas between server and Azure
  • Some server features not available ATM
    • No Notifications, HA, Tags/Regions
    • Expiration
      • No way to change expiration on a cache –but can be changed on a per-object basis
    • Eviction
      • No way to change eviction settings
  • Connections
    • Server: one connection ==multiple named caches
    • Azure: one connection == named default cache
    • Azure – create multiple namespace reservations
when to use it
When to use it:
  • Reference data
  • Activity data
  • Resource data
asp net session state provider
ASP.NET Session State Provider
  • Included OOB with the Cache
  • Simple configuration change
    • Enables session state to be cached across a cluster
session state provider
Session state provider
  • <sessionStatemode="Custom"customProvider="SessionStoreProvider">
  • <providers>
  • <addname="SessionStoreProvider"type="Microsoft.ApplicationServer.Caching.DataCacheSessionStoreProvider, Microsoft.ApplicationServer.Caching.Client, Version=1.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35"cacheName="BlueYonderSession"/>
  • </providers>
  • </sessionState>
summary
Summary
  • Windows Server AppFabric Cache is a distributed application cache
  • Caching is important to application scalability
  • Explicit caching API available to .NET 3.5 SP1 and .NET 4.0
  • ASP.NET Session provider an implicit way to take advantage of the Cache’s capabilities
