  1. ELVA-1Millimeter Wave Division Company Profile September 2005 www.elva-1.com

  2. ELVA-1 Millimeter Wave Division • 1993: Millimeter Wave Division founded in St.Petersburg, Russia • Registered locally as Dok.ltd and doing business under ELVA-1 trademark • Company mission: • Export-oriented company with emphasis on design of scientific & research mm-wave equipment • Area of Expertise: millimeter wave components and subsystems

  3. ELVA-1 Millimeter Wave Division 2005: Global brand in mm-wave market • 26 GHz – 2 THz frequencies • Measurement & test equipment for EPR-spectroscopy, plasma physics, astrophysics • Wide range of active and passive mm-wave components, incl. for OEM • 42/60/71-86/94 GHz telecom solutions • Short-range industry radar subsystems

  4. ELVA-1 Millimeter Wave Division ELVA-1 Representatives Worldwide • India: Merlinhawk Associates PVT Ltd • Reps in USA, Canada • Reps in Europe (Germany, UK, France, Spain, Italy…)see more info at www.elva-1.com

  5. ELVA-1Our Team ELVA-1 Team at 2005 • Very proficient and experienced teamof 45 people • 95% of staff have university diplomas (Master Degrees) • 5% of staff are Doctors of Science

  6. Customers are Our Main Asset ELVA-1 equipment works in all Tokamaks of the world • JET Tokamak (UK) – the biggest tokamak in the world • DIII-D Tokamak, General Atomics, USA • Tore-Supra Tokamak, France • TCV Tokamak, Switzerland • RTP Tokamak, The Netherlands • JT-60 Tokamak, Japan • HL-1M Tokamak, China • STORM-M Tokamak, Canada • H-1 Heliac Tokamak, Australia • FTU Tokamak, Italy • TCABR Tokamak, Brazil

  7. Customers are Our Main Asset (continued) Top Scientific, Research and Business customers of the World: • USA & Canada: NASA, NIST, TRW Corp., Cornell University, Jet Propulsion Lab,University of Saskatchewan… • Europe: CERN, Forschungszentrum and University of Karlsruhe, SRON Space Research, Rutherford Appleton Laboratory (UK), University of Kiel, Siemens, University of St. Andrews (UK), Berlin Free University,Technical University of Denmark, FOM Institute, Daltron Limited(UK), Institut fuer Plasmaphysik…

  8. Customers are Our Main Asset(continued) Our Respective Indian customers:(Projects fulfilled with local reps – Merlinhawk Associates PVT) • SAC, ISRO, Ahmedabad • Institute for plasma research, Ahmedabad • Bharat Electronics, Bangalore • Solidstate Physics Laboratory, Delhi • National Phisical Laboratory, Delhi • DERL, Hyderabad

  9. ELVA-1Design and Manufacturing Facilities Mm-wave systems and components for freq. > 40GHz • Through partner factories we’re controlling the manufacturing of key transceiver components: • Cassegrain Antennas 26.5 – 170 GHz • IMPATT Diodes • Diodes for Mixers and Detectors • In-House design, manufacturing, assembling • Active Frequency Multipliers • Cavity Stabilized Oscillators • Mixers • Wave guides, etc.

  10. ELVA-1Product RangeTelecom Products • First Telecom Product released in 1998 • 10Mbit PPC-10/37000 Wireless Lan Bridge • 2005 Product Range • 100/155/1000 Mbps Ethernet Point-to-point digital radios • LMDS 100Mbit Point-to-multipoint Ethernet • MVDS 4.2Gbps Point-to-multipoint Digital TV + IP + VoIP multiservice networks • Antennas for 26.5 – 170 GHz • Cassegrain antennas for telecom applications • Horn antennas for radars

  11. ELVA-1Product RangeTest and Measurement Products Measurement and instrumentation equipment is the base of all R&D activity driven by any company in mm-wave industry • BWO Sweepers for mm-wave and submm-wave bands • Voltage Controlled Oscillators • Millimeter wave band powermeters • Scalar network analyzers 50 – 170 GHz • Digitally controlled oscillators • IMPATT Injection-Locked Amplifiers • MMW Power Modulated Sources • Sweeping and multichannel radiometers • Real-Time Frequency Analyzers

  12. ELVA-1Product RangeShort-range Industrial Radars • FMCW 94/10 Millimeter Wave Distance Sensor • FMCW Radar Front-End (10mW and 200mW versions) • MMW Level Measurement System • Pulse Noise Front-End 80-100 GHz • Single-element mm-wave camera

  13. ELVA-1Product RangePassive and active mm-wave components • Balanced mixers and Image Rejection mixers • Directional Couplers • Circulators and isolators • IMPATT Active Frequency Multipliers 26-150 GHz • Wideband Frequency Multipliers • High Power Pulsed Noise Sources • Solid State Noise Sources • Zero-Biased Detectors, 26.5 to 170 GHz • Cavity-stabilized IMPATT Diode Oscillators • IMPATT Diodes and Test Fixtures • Solid State Voltage Controlled Attenuators • Waveguide components

  14. ELVA-1Design and Manufacturing Facilities • In-house Design Facility: • Measurement, Calibration, Test equipment for up to 220GHz • Manufacturing: • CNC Machines to produce high precision mm-wave components

  15. ELVA-1Aim toSuccess in XXI • Many new products in R&D • More off-the shelf products of all kinds • Telecom Products as leading direction of company market development • Representative companies worldwide • Young, enthusiastic and experienced team • Internet-centric Marketing

  16. ELVA-1 Millimeter Wave Division To be continued… www.elva-1.com

  17. ELVA-1 Poster ADs

  18. ELVA-1 Poster ADs

  19. ELVA-1 Poster ADs
