    1. Introduction to ClickOnce Name: Panayiotis Panayiotou Title: Business Solutions Lead – Dot.Cy Developments Ltd

    2. 2 Agenda What is “ClickOnce”? ClickOnce Basics Demo: ClickOnce Publishing Smart Client Windows Applications Fine-tuning ClickOnce Demo: Configuring ClickOnce Deployment Requirements and updating Demo: Updating ClickOnce Deployed Application Prerequisites and Manifests Demo: Prerequisites Security Demo: Security SandBox ClickOnce API Demo: ClickOnce API Hints & Tips

    3. 3

    4. 4 ClickOnce Vision What is “ClickOnce”? Bring the ease of web application deployment to client applications

    5. 5 Deployment with ClickOnce What is “ClickOnce”? Smart Client Deploy meets Web Deploy Run an application by clicking on a URL Update an application by updating a server Robust Downloader & Installer File & HTTP server support Flexible updates – optional, required, etc.. Start Menu & Add/Remove Programs integration Extensibility via an API Deep Visual Studio Integration Rich Security Model CLR CAS sandboxing Permission elevation prompting w/ Authenticode

    6. 6 The Best of the Client and Web What is “ClickOnce”? With no-touch deployment, Windows Forms applications — desktop applications built using the Windows Forms classes of the .NET Framework — can be downloaded, installed, and run directly on the users' machines without any alteration of the registry or shared system components. With no-touch deployment, Windows Forms applications — desktop applications built using the Windows Forms classes of the .NET Framework — can be downloaded, installed, and run directly on the users' machines without any alteration of the registry or shared system components.

    7. Hope Everyone is still awaked!!!!!!!! Demo: ClickOnce Publishing Smart Client Windows Applications

    8. 8 Fine-tuning ClickOnce Development Experience Visual Studio 2005 IDE support Integrated with core project types Setup is not a post-development task Project Designer Publish pane Security pane Singing pane Publish Wizard Copies application to Web server, FTP or network file share

    9. 9 Fine-tuning ClickOnce Deployment Options ‘Launched’ application (from Web or UNC) Application launches, but doesn’t “install” No start menu, no Add/Remove Programs There will be support to cleanup ClickOnce Cache Always updates on launch

    10. 10 .NET Framework Deployment Managed Networks Desktops locked down Push technologies SMS, Intellimirror, Imaging Unmanaged PCs User is the admin Component Bootstrapper FX installed as part of app setup

    11. 11 Component Bootstrapper Lightweight setup.exe Detects prerequisites Downloads/installs as needed Web or disk installations Manages reboots Supports any msi or exe installer Out of the box .NET FX, MDAC 9, MSDE, J#, & MSI 2.0, SQLEXPRESS Fully extensible for other components

    12. 12 Bootstrapper in action

    13. Demo: Configuring ClickOnce Deployment

    14. 14 ClickOnce Requirements Operating System Support “ClickOnce” ships in the .NET Framework redist & supports all of the same operating systems & languages as the core .NET Framework. Specifically Windows 98 & up, except for NT4. Special server requirements for hosting a "ClickOnce" application No, you can use a regular file share, IIS or any web server. If you are using a web server You need to configure the MIME type (application/deployment) for the .application extension. You need to configure your server to unblock any restricted file extensions used by your app, such as .exe, .dll, .config., manifest, etc. If you want to use HTTP compression, you will need IIS6 and HTTP 1.1. Client Computers to have .NET FW 2.0

    15. 15 ClickOnce Basics Update options for installed apps On application startup If found, ask user to update app After application startup If found, ask user to update on next run Required updates Specified using minimum required version Programmatic updating Prerequisites

    16. 16 ClickOnce Basics Update Architecture

    17. Demo: Updating ClickOnce Deployed Application

    18. 18 Manifests Declarative Installation Application manifest (n) Authored by the developer Describes the application Example: what assemblies constitute the application Deployment manifest (1) Authored by the administrator Describes the application deployment Example: what version clients should use

    19. 19 Manifests Deployment & Application Manifests

    20. 20 Manifests Deployment Manifest

    21. 21 Manifests Deployment Manifest

    22. 22 Manifests Deployment Manifest

    23. 23 Manifests Deployment Manifest

    24. 24 Manifests Application Manifest

    25. 25 Manifests Application Manifest

    26. 26 Manifests Application Manifest

    27. 27 Manifests Application Manifest

    28. 28 Manifests Application Manifest

    29. 29 ClickOnce Basics Bootstrapper Installs app prerequisites .NET FX, SQLExpress, DirectX,.. Requires admin rights Extensible architecture Manages reboots Installs ClickOnce app after prerequisites Use ClickOnce for auto-updates No auto-updating of prerequisite components

    30. Demo: Prerequisites

    31. 31 Security Introduction ClickOnce applications run in a sandbox by default Permissions are based on origin Internet, Intranet or Full Trust Similar to IE and Javascript Sandbox size increases “Longhorn” > .NET V2.0 > .NET V1.1 Apps often need higher trust Call unmanaged code Connect to DB, WS, …

    32. 32 Security Determining required permissions Security pane of Project Designer Configure permissions manually Permissions Calculator Calculates least required permissions Use declarative security for dynamic actions Ex. [WebBrowserPermission( SecurityAction.Demand, Unrestricted = true, Level = WebBrowserPermissionLevel.Default)] Debug in sandbox Intellisense in sandbox

    33. 33 Security Microsoft Authenticode Authenticode signatures required for ClickOnce Based on industry standards Allows devs to include company information through the use of digital signatures In contrast to.snk files! Certificate origins Verisign, … Internal certification authority (CA) MakeCert Programs MakeCert: creates X.509 certificate SignCode, CertMgr, … MSDN link

    34. 34 Security User prompting App requests required permissions User prompted, if app permission needs > sandbox permissions Users make trust decisions all the time Installing software from CD Submitting a credit card number to web page Useful for targeting “PCs at home” Internet or unmanaged Intranet User is the admin Admin can disable prompting via policy

    35. 35 Security Scenarios to get elevated trust ISVs Obtain a cert from VeriSign User runs app ? trust prompt indicates the company Large managed companies (no trust prompt) Can use own PKI infrastructure and issue certs for internal enterprise applications Add cert to trusted root & publisher list ? Use Active Directory & Group Policy Small companies & hobbyists (no trust prompt) Use makeCert (.NET SDK) or VS2005 Add cert to trusted root & publisher list on clients At setup time of .NET FW, SMS, etc. Tell enduser to use CertMgr ? As part of the bootstrapper makecert -sk XYZ -n "CN=XYZ Company" testXYZ.cer makecert -sk XYZ -n "CN=XYZ Company" testXYZ.cer

    36. 36 Security Secure Updates ClickOnce manifests are signed (XMLDSig) Manifest hashed Hash signed & signature created Signature added to manifest ? Changing the manifest invalidates the signature ? Guarantees a unique application identity Publisher key needed to deploy updates ClickOnce apps are isolated ? their components can’t be reused! Prevents auto-deployment of viruses Does not require signed assemblies Hash in signed manifest is sufficient

    37. Demo: Security

    38. 38 API Basics Introduction System.Deployment Namespace Class ApplicationDeployment Simple & Secure to use API Ex. CheckForUpdate(), UpdateLocation & Update() Sync & Async versions of all methods Only works when deployed with ClickOnce Use IsNetworkDeployed to detect

    39. 39 API Basics Programming Scenarios Application updating Implement “Update now” menu option Match client with back-end programs Customize when-to-update logic Limit updates to beta users only Throttle updates based on server load

    40. Demo: ClickOnce API

    41. 41 Some Afterthoughts Keep smart client applications as much as possible self-dependable to keep security restrictions to the minimum Compatibility with previous versions of .NET framework Can us a wrapper application Deploying with page login No direct support from ClickOnce API. But you can use the ASP.NET authentication and authorization mechanisms.

    42. 42
