  1. Policy Driven Heterogeneous Resource Co-Allocation with Gangmatching Rajesh Raman, Miron Livny, Marvin Solomon University of Wisconsin Presented by: Kashmira Phalak

  2. Key Ideas • Dynamic, heterogeneous and distributively owned resource environments pose the challenge of resource representation, allocation and management • Conventional resource management methods fail to address these issues • Matchmaking matches each customer with a single resource: Inadequate • Gangmatching satisfies applications which require a collection of heterogeneous resources to be matched and allocated to perform a task • Gangmatching particularly focuses on the license management co-allocation problem

  3. What is Matchmaking? • Matchmaking is a methodology for Distributed Resource Management • Actions involved in Matchmaking: Matchmaker (Match Algorithm(2)) Advertisement(1) Advertisement(1) Match Notification(3) Match Notification(3) Entity (Requester) Entity (Provider) Claiming(4)

  4. Motivation for Gangmatching • The License Management Problem • Limited number of licenses and validity on only a few workstations

  5. The Gangmatching Model • Multilateral Gangmatching extends the bilateral matchmaking scheme • Matchmaking Framework: • ClassAd representation • Matchmaking Algorithm • Matchmaking (Notification) protocols • Claiming protocols

  6. The Gangmatching Model • ClassAd Representation Gangmatch Request:

  7. The Gangmatching Model Workstation Ad: License Ad:

  8. The Gangmatching Model • Matchmaking Algorithm • Matchmaking (Notification) Protocols • Involves sending copies of the matched gang to every agent • whose advertisement is involved in the gang.

  9. The Gangmatching Model • Claiming Protocols: • Proceed in a 2 phase manner: 1. VERIFY: • Root agent begins the phase by asking subordinates to verify if they want to join the gang • If reply is OK then COMMIT phase initiated • If reply is ABORT then root agent tells gang members to discard the match and start over • If root’s subordinates have children, then the phase is recursively performed 2. COMMIT • After root gets OK from all children, claims and allocations done

  10. Gangmatching Implementation Fill Direction • Naïve Gangmatching: Backtracking Direction ROOT AD Advertisement Filled Port Unfilled Port Marshalled sub-gang Already Filled Not yet Filled Under Consideration

  11. Indexed Matchmaking Algorithm Outline 1: O ← offer classads 2: R ← request classads 3: Orect ← classads in O converted to rectangles 4: Oindexed ← indexed intervals of rectangles in Orect 5: Rsorted ← R sorted by priority 6: for each C in Rsorted do 7: R ← convert C into a rectangle (Window query to probe the index) 8: M ← all rectangles in Oindexed intersecting R 9: B ← pick best match from M 10: output(B,R) 11: remove B from Oindexed 12: end for

  12. Intuitive Scheme for Rectangle Conversion Offers Requests [ x=10; Constraint=other.y>=7 ] [ y=8; Constraint=other.x>=8 ] {(x, y) | x = 10, y >= 7} {(x, y) | y = 10, x >= 8},

  13. Gangmatching Implementation • LR: Indexed In-Order Gangmatching • Overcomes inefficiency of Naïve algorithm due to exclusive reliance on constraint expression evaluation mechanism • Use of index probes before filling docks reduces the number of candidates to be considered to fill the port • Indexes attributes using conventional search trees and constraint expressions using interval trees • Algorithm always picks the machine first and then finds the compatible license • Inherits the naive algorithm’s weakness when operating in workloads composed of scarce or absent resources.

  14. The Gangmatching Model • Dynamic Gangmatching • Solution: Dynamic Right-left operation • Algorithm picks the license first and then finds a machine compatible with it • Constraints are shunted from license classad to the cpu port of job classad • Uses index mechanism to identify compatible candidates and to dynamically determine the port fill order • Algorithm immediately aborts if desired resources are unavailable.

  15. Gangmatching Performance • Workloads are characterized by: N = Number of job and workstation classads L = License density, either 50% or 100% of N S = Selectivity index of license classads • Elapsed time performance of algorithms measured on Intel Pentium Pro Linux workstation with 256MB RAM • Extensive testing now done on Condor

  16. Naïve Algorithm Performance • Extremely inefficient when licenses are scarce • Not sensitive to license selectivity indexes • Expression evaluation and backtracking dominate cost of algorithm • Worst case: O(n3)

  17. LR: Indexed In-Order Gangmatching Performance

  18. Dynamic Algorithm Performance • Performance doesn’t significantly differ between the 50% and 100% regime • Scarcer resources are incorporated first, reducing the number of required index probes.

  19. Left-Right Vs. Dynamic Algorithm Performance • Dynamic Algorithm issues more queries under 100% license workload but shows marked improvement over Indexed In-order Algorithm under 50% license workload

  20. Conclusions & Future Work • Conclusions: • Gangmatching successfully addresses the problem of policy driven heterogeneous resource co-allocation • The data indexing method and heuristic-driven dynamic algorithm can provide efficient implementation • Performance evaluation of the three proposed algorithms demonstrates the feasibility of the Gangmatching solution • Future Work: • Incorporate preferences into gangmatching algorithm • Develop better algorithms for wider and deeper gangs • Overcome restriction of knowing number of resources in advance

  21. Analysis • The matchmaking process behaves like a black-box • Should it be made imperative to satisfy all constraints? • Performance evaluations are shown for just for a single platform and adequate information about it’s role is not provided • Reliability and scalability issues need to be evaluated to address the concerns of larger grids • An automatic mechanism should be provided to replace a classad with its residual resources after matching. • Paper seems a little unbalanced since it provides performance evaluations of implementations which are not completely explained

  22. Questions?
