NMAP Scanning Options

1. NMAP Scanning Options

2. NMAP • Nmap is the most popular scanning tool used on the Internet. • Cretead by Fyodar (http://www.insecure.org) , it was featured in the Matrix Reloaded movie.

3. SYN Scanning • Syn scanning, a technique that is widely across the Internet today. • The syn scan, also called the "half open" scan, is the ability to determine a ports state without making a full connection to the host. • Many systems do not log the attempt, and discard it as a communications error. • You must first learn 3-way handshake to understand the Syn scan.

4. TCP Communication Flags • Standard TCP communications are controlled by flags in the TCP packet header. • The flags are as follows: • Synchronize - also called "SYN” • Used to initiate a connection between hosts. • Acknowledgement - also called "ACK” • Used in establishing a connection between hosts • Push - "PSH” • Instructs receiving system to send all buffered data immediately • Urgent - "URG” • States that the data contained in the packet should be processed immediately • Finish - also called "FIN" • Tells remote system that there will be no more transmissions • Reset - also called "RST” • Also used to reset a connection.

5. Three Way Handshake Computer A Computer B 192.168.1.2:2342 ------------syn----------->192.168.1.3:80 192.168.1.2:2342 <---------syn/ack----------192.168.1.3:80 192.168.1.2:2342-------------ack----------->192.168.1.3:80 Connection Established • The Computer A ( 192.168.1.2 ) initiates a connection to the server ( 192.168.1.3 ) via a packet with only the SYN flag set. • The server replies with a packet with both the SYN and the ACK flag set. • For the final step, the client responds back the server with a single ACK packet. • If these three steps are completed without complication, then a TCP connection has been established between the client and server.

6. Stealth Scan Computer A Computer B 192.168.1.2:2342 ------------syn----------->192.168.1.3:80 192.168.1.2:2342 <---------syn/ack----------192.168.1.3:80 192.168.1.2:2342-------------RST----------->192.168.1.3:80 • Client sends a single SYN packet to the server on the appropriate port. • If the port is open then the server responds with a SYN/ACK packet. • If the server responds with an RST packet, then the remote port is in state "closed” • The client sends RST packet to close the initiation before a connection can ever be established. • This scan also known as “half-open” scan.

7. Xmas Scan Computer A Computer B Xmas scan directed at open port: 192.5.5.92:4031 -----------FIN/URG/PSH----------->192.5.5.110:23 192.5.5.92:4031 <----------NO RESPONSE------------192.5.5.110:23 Xmas scan directed at closed port: 192.5.5.92:4031 -----------FIN/URG/PSH----------->192.5.5.110:23 192.5.5.92:4031<-------------RST/ACK--------------192.5.5.110:23 • Note: XMAS scan only works OS system's TCP/IP implementation is developed according to RFC 793 • Xmas Scan will not work against any current version of Microsoft Windows. • Xmas scans directed at any Microsoft system will show all ports on the host as being closed.

8. FIN Scan Computer A Computer B FIN scan directed at open port: 192.5.5.92:4031 -----------FIN------------------->192.5.5.110:23 192.5.5.92:4031 <----------NO RESPONSE------------192.5.5.110:23 FIN scan directed at closed port: 192.5.5.92:4031 -------------FIN------------------192.5.5.110:23 192.5.5.92:4031<-------------RST/ACK--------------192.5.5.110:23 • Note: FIN scan only works OS system's TCP/IP implementation is developed according to RFC 793 • FIN Scan will not work against any current version of Microsoft Windows. • FIN scans directed at any Microsoft system will show all ports on the host as being closed.

9. NULL Scan Computer A Computer B NULL scan directed at open port: 192.5.5.92:4031 -----------NO FLAGS SET---------->192.5.5.110:23 192.5.5.92:4031 <----------NO RESPONSE------------192.5.5.110:23 NULL scan directed at closed port: 192.5.5.92:4031 -------------NO FLAGS SET---------192.5.5.110:23 192.5.5.92:4031<-------------RST/ACK--------------192.5.5.110:23 • Note: NULL scan only works OS system's TCP/IP implementation is developed according to RFC 793 • NULL Scan will not work against any current version of Microsoft Windows. • NULL scans directed at any Microsoft system will show all ports on the host as being closed.

10. IDLE Scan • Almost four years ago, security researcher Antirez posted an innovative new TCP port scanning technique. • Idlescan, as it has become known, allows for completely blind port scanning. • Attackers can actually scan a target without sending a single packet to the target from their own IP address.

11. IDLE Scan: Basics • Most network servers listen on TCP ports, such as web servers on port 80 and mail servers on port 25. • A port is considered "open" if an application is listening on the port, otherwise it is closed. • One way to determine whether a port is open is to send a "SYN" (session establishment) packet to the port. • The target machine will send back a "SYN|ACK" (session request acknowledgment) packet if the port is open, and a "RST" (Reset) packet if the port is closed. • A machine which receives an unsolicited SYN|ACK packet will respond with a RST. An unsolicited RST will be ignored. • Every IP packet on the Internet has a "fragment identification" number. • Many operating systems simply increment this number for every packet they send. • So probing for this number can tell an attacker how many packets have been sent since the last probe.

12. IDLE Scan: Step 1 • Choose a "zombie" and proble for its current IPID number

13. IDLE Scan: Step 2 • Send forged packet "from" Zombie to target.

14. IDLE Scan: Step 3 • Probe Zombie IPID again

15. Fragmentation scanning • Instead of just sending the probe packet, you break it into a couple of small IP fragments. • You are splitting up the TCP header over several packets to make it harder for packet filters and so forth to detect what you are doing. • The -f switch instructs the specified SYN or FIN scan to use tiny fragmented packets.

16. ICMP echo scanning • This isn't really port scanning, since ICMP doesn't have a port abstraction. • But it is sometimes useful to determine what hosts in a network are up by pinging them all. • nmap -P cert.org/24 152.148.0.0/16

17. Scan Options • -sT (TcpConnect) • -sS (SYN scan) • -sF (Fin Scan) • -sX (Xmas Scan) • -sN (Null Scan) • -sP (Ping Scan) • -sU (UDP scans) • -sO (Protocol Scan) • -sI (Idle Scan) • -sA (Ack Scan) • -sW (Window Scan) • -sR (RPC scan) • -sL (List/Dns Scan)

18. Ping Detection • -P0 (don’t ping) • -PT (TCP ping) • -PS (SYN ping) • -PI (ICMP ping) • -PB (= PT + PI) • -PP (ICMP timestamp) • -PM (ICMP netmask)

19. Output Format • -oN(ormal) • -oX(ml) • -oG(repable) • -oA(ll)

20. Timing • -T Paranoid – serial scan & 300 sec wait • -T Sneaky - serialize scans & 15 sec wait • -T Polite - serialize scans & 0.4 sec wait • -T Normal – parallel scan • -T Aggressive- parallel scan & 300 sec timeout & 1.25 sec/probe • -T Insane - parallel scan & 75 sec timeout & 0.3 sec/probe • --host_timeout --max_rtt_timeout (default - 9000) • --min_rtt_timeout --initial_rtt_timeout (default – 6000) • --max_parallelism --scan_delay (between probes)

21. --resume (scan) --append_output • -iL <targets_filename> -p <port ranges> • -F (Fast scan mode) -D <decoy1 [,decoy2][,ME],> • -S <SRC_IP_Address> -e <interface> • -g <portnumber> --data_length <number> • --randomize_hosts -O (OS fingerprinting) -I (dent-scan) • -f (fragmentation) -v (verbose) -h (help) • -n (no reverse lookup) -R (do reverse lookup) • -r (dont randomize port scan) -b <ftp relay host> (FTP bounce)
