  1. WiGig technologiesIEEE 802.11ad/ay Roman Kovalchukov Laboratory of Electronics and Communications Engineering

  2. 802.11ad History • WiGig alliance promotes the IEEE 802.11ad Announced in May 2009 • WiGig announced the release of its certification ready version 1.1 specs in June 2011 • WiGig & Wi-Fi Alliance merged in March 2013 • Wi-Fi Alliance announced the launch of its WiGig certification program in Oct 2016

  3. 802.11ad Very High Throughput (VHT) main specs • 802.11ad Operates at 60 GHz frequency • Use up to four 2.16 GHz channels. Over 8 GHz of Bandwidth • Each channel supports up to 6.75675 Gbps (using OFDM) • In Lower complexity single channel (SC) up to 2.224 Gbps • Range 1-10 meters • Support up to 32 antennas (for phase beamforming)

  4. 60 GHz Spectrum allocation

  5. 60 GHz Spectrum allocation

  6. 802.11ay Project Goals • Task Group ay is expected to develop an amendment that defines standardized modifications to both the IEEE 802.11 physical layers (PHY) and the IEEE 802,11 medium access control layer (MAC) that enables at least one mode of operation capable of supporting a maximum throughput of at least 20 gigabits per second (measured at the MAC data service access point), while maintaining or improving the power efficiency per station. This amendment also defines operations for license-exempt bands above 45 GHz while ensuring backward compatibility and coexistence with legacy directional multi-gigabit stations (defined by IEEE 802.11ad-2012 amendment) operating in the same band.

  7. 802.11ay Very High Throughput (VHT) main specs • 802.11ay Operates at 60 GHz frequency • Link rate per stream 20-44 Gbps • Backward compatible with 802.11 ad • With channel bounding provides up to 8.64 GHz bandwidth • MIMO support up to four streams (up to 176 Gbps) • 802.11ay supports 256 QAM

  8. 802.11ay Future Deployments • High performance public Wi-Fi networks in 2019 • Pre-standard 802.11ay chipsets started shipping in 2018 • Backhaul and node interconnection focus • Transmitting rates up to 40 Gpbs at ranges 300-500 meters • Such companies as Nokia, Facebook, Qualcomm and Deutsche Telekom are working on these early deployments

  9. 802.11ay Project Current Timeline Status (26.11.19) • Project Authorization Request approved - March 2015 • Initial Task Group Meeting - May 2015 • Draft 1.0 of the amendment - November 2017 • Draft 2.0 of the amendment - August 2018 • Draft 2.1 of the amendment - October 2018 • Draft 3.0 of the amendment - January 2019 • Final 802.11 Working Group approval - March 2020 • Final 802 EC approval - March 2020 http://www.ieee802.org/11/Reports/tgay_update.htm

  10. Usage models of WiGig technology (IEEE) • Usage Model 1: Ultra Short Range (USR) Communications Train Station Kiosk Movie, video/audio clip, magazine, newspaper, etc. Video/audio clip, magazine, newspaper, etc.

  11. Usage models of WiGig technology (IEEE) • Usage Model 2: 8K UHD Wireless Transfer at Smart Home Replacement of wired interface Set-top box (TV controller) Wireless Transfer from fixed device Blu-ray player 8K UHD Service Smart phone/Tablet TV or Display Wireless Transfer from mobile device

  12. Usage models of WiGig technology (IEEE) • Usage Model 4: Data Center 11ay Inter-Rack Connectivity

  13. Usage models of WiGig technology (IEEE) • Usage Model 8: Wireless Backhauling Backhaul @60GHz Backhaul @60GHz Backhaul @60GHz 11ay AP 11ay AP 11ay AP 11ay AP 11ay AP 11ay AP N-LOS Access N-LOS Access N-LOS Access LOS Access BUS STOP BUS STOP BUS STOP Backhaul @60GHz Wireless backhauling with single hop POP Wireless backhauling with Multiple hops

  14. Usage models of WiGig technology (IEEE) Dock • Usage Model 9 & 11: Office docking and USR Wireless Docking Video stream transfer & Data transfer Wireless Power Charging Side View

  15. 802.11ay Task Group Documents (26.11.19) • The followings are baseline version of the task group documents that are approved by the Task Group as of the end of the November 2018 plenary: • Usage model 11-15/0625r7 (Last update: November 2017) • Channel model 11-15/1150r9 (Last update: March 2017) • Functional requirements 11-15/1074r0 (Last update: September 2015) • Evaluation methodology 11-15/0866r4 (Last update: July 2016) • Coexistence assurance document 11-17/1288r2 (Last update: September 2017) • Selection procedure 11-15/1079r2 (Last update: November 2015) • Specificaion framework document (SFD) 11-15/1358r9 (Last update: December 2016) • Compendium of motion related to SFD 11-16/0266r5 (Last update: November 2016) • Compendium of motion related to the draft 11-17/0186r11 (Last update: November 2018) • Comment database for CC24 (D0.3) 11-17/0649r9 (Last update: November 2017) • Comment database for LB231 (D1.0) 11-18/0067r11 (Last update: July 2018) • Comment database for LB234 (D2.0) 11-18/1483r5 (Last update: November 2018) http://www.ieee802.org/11/Reports/tgay_update.htm

  16. [1] 15-14-0304-11-003d-applications-requirement-document-ard.docx [2] 3GPP TR 36.932 V12.1.0 (2013-03): Scenarios and requirements for small cell enhancements for E-UTRA and E-UTRAN [3] 11-14-1185-00-11ay-11ay-usage-scenarios [4] 11-14-1166-01-11ay-11ay-use-cases [5] 11-14-1160-00-11ay-ultra-short-range-usr-communications-usage-models-for-11ay [6] 11-14-1249-01-11ay-backhaul-support-in-ng-60 [7] 11-14-1151-05-11ay-11ay-proposed-par [8] 11-14-1152-06-11ay-11ay-proposed-csd [9] 11-15-0345-00-8K-UHD-Wireless-Transfer-Usage-Model-for-11ay [10] 11-15-0830-00-00ay-docking-usage-model [11] 11-16-0666-00-00ay-usr-wireless-docking-usage-mode [12] https://www.spirent.com [13] 11-15-0625-07-00ay-ieee-802-11-tgay-usage-scenarios [14] http://www.ieee802.org/11/Reports/tgay_update.htm References
