automatic data structure repair for self healing systems

Automatic Data Structure Repair for Self-Healing Systems

Brian Demsky

Martin Rinard

Laboratory for Computer Science

Massachusetts Institute of Technology

motivation
Motivation

Broken Data Structure

Errors

  • Missing elements
  • Inappropriate sharing
  • Dangling references
  • Out of bounds array indices
  • Inconsistent values

F = 20

G = 10

F = 20

G = 5

I = 5

J = 2

slide3

Goal

Broken Data Structure

Consistent Data Structure

F = 2

G = 1

F = 20

G = 10

F = 10

G = 5

F = 20

G = 10

F = 20

G = 5

Repair

Algorithm

I = 3

I = 5

J = 2

J = 2

slide4

Goal

Broken Data Structure

Consistency

Properties

From

Developer

Consistent Data Structure

F = 2

G = 1

F = 20

G = 10

F = 10

G = 5

F = 20

G = 10

F = 20

G = 5

Repair

Algorithm

I = 3

I = 5

J = 2

J = 2

what does repair algorithm produce
What Does Repair Algorithm Produce?
  • Data structure that
    • Satisfies consistency properties, and
    • Heuristically close to broken data structure
  • Not necessarily the same data structure as (hypothetical) correct program would produce
  • But enough to keep program operating successfully
precursors
Precursors
  • Data structure repair has historically appeared in systems with extreme reliability goals
    • 5ESS switch – hand coded audit routines
    • IBM MVS operating system – hand coded failure recovery routines
  • Key component of these systems
where is this likely to be useful
Where Is This Likely To Be Useful?
  • Not for systems with slack - can just reboot
    • Cause of error must go away after reboot
    • Must be OK to lose volatile state
    • Must be OK to wait for reboot
  • Persistent data structures

(file systems, application files)

  • Autonomous and/or safety critical systems
    • Monitor/control unstable physical phenomena
    • Largely independent subcomputations
    • Moving time window
architecture
Architecture

Broken

Abstract Model

Repaired

Abstract Model

Internal

Consistency

Properties

External

Consistency

Properties

Model

Definition &

Translation

1011100110001111011

1010101011110011101

1010111000111101110

1010011110001111011

1010110101110011010

1010111011001100010

Broken

Bits

Repaired

Bits

architecture rationale
Architecture Rationale

Why go through the abstract model?

  • Simple, uniform structure
    • Sets of objects
    • Relations between objects
  • Simplifies both
    • Expression of consistency properties
    • Repair algorithm
  • Enables system to support full range of efficient, heavily encoded data structures
file system example
struct Entry {

byte name[Length];

int firstBlock;

}

struct Block {

int nextBlock;

data byte[BlockSize];

}

File System Example

abst

0

intro

2

1

-5

1

-1

Directory Entries

Disk Blocks

struct Disk {

Entry dir[NumEntries];

Block block[NumBlocks];

}

Disk D;

model definition
Model Definition
  • Sets of objects

set blocks of integer : partition used | free;

  • Relations between objects – values of object fields, referencing relationships between objects

relation next : used, used;

blocks

next

used

free

model translation
Model Translation

Bits translated to sets and relations in abstract model using statements of the form:

Quantifiers, Condition  Inclusion Constraint

for i in 0..NumEntries, 0  D.dir[i].firstBlock and D.dir[i].firstBlock < NumBlocks 

D.dir[i].firstBlock in used

for b in used, 0  D.block[b].nextBlock and D.block[b].nextBlock < NumBlocks b,D.block[b].nextBlock in next

for b,n in next, true  n inused

for b in 0..NumBlocks, not (b in used) b in free

model in example
Model in Example

abst

0

intro

2

1

-5

1

-1

Directory Entries

Disk Blocks

blocks

used

0

next

free

1

3

next

2

internal consistency properties
Internal Consistency Properties

Quantifiers, Body

  • Body is first-order property of basic propositions
  • Inequality constraints on values of numeric fields
    • V.R = E, V.R < E, V.R  E, V.R  E, V.R > E
  • Presence of required number of objects
    • size(S) = C, size(S)  C, size(S)  C
  • Topology of region surrounding each object
    • size(V.R) = C, size(V.R)  C, size(V.R)  C
    • size(R.V) = C, size(R.V)  C, size(R.V)  C
  • Inclusion constraints: V in S, V1 in V2.R, V1,V2 in R
  • Example: for b in used, size(next.b)  1
internal consistency violations
Internal Consistency Violations

Evaluate consistency properties, find violations

for b in used, size(next.b)  1 is false for b = 1

blocks

used

0

next

free

1

3

next

2

repairing violations of internal consistency properties
Repairing Violations of Internal Consistency Properties
  • Violation provides binding for quantified variables
  • Convert Body to disjunctive normal form

(p1  …  pn )  …  (q1  …  qm )

p1 …pn , q1 …qm are basic propositions

  • Choose a conjunction to satisfy
  • Repair violated basic propositions in conjunction
repairing violations of basic propositions
Repairing Violations of Basic Propositions
  • Inequality constraints on values of numeric fields
    • V.R = E, V.R < E, V.R  E, V.R  E, V.R > E
    • Compute value of expression, assign field
  • Presence of required number of objects
    • size(S) = C, size(S)  C, size(S)  C
    • Remove or insert objects from/to set
  • Topology of region surrounding each object
    • size(V.R) = C, size(V.R)  C, size(V.R)  C
    • size(R.V) = C, size(R.V)  C, size(R.V)  C
    • Remove or insert pairs from/to relation
  • Inclusion constraints: V in S, V1 in V2.R, V1,V2 in R
    • Remove or add the object or pair from/to set or

relation

slide18

Repair in Example

for b in used, size(next.b)  1 is false for b = 1

Must repair size(next.1)  1

Can remove either 0,1 or 2,1 from next

blocks

used

0

next

free

1

3

next

2

slide19

Repair in Example

for b in used, size(next.b)  1 is false for b = 1

Must repair size(next.1)  1

Can remove either 0,1 or 2,1 from next

blocks

used

0

next

free

1

3

2

acyclic repair dependences
Acyclic Repair Dependences
  • Questions
    • Isn’t it possible for the repair of one constraint to invalidate another constraint?
    • What about infinite repair loops?
    • What about unsatisfiable specifications?
  • Answer
    • We require specifications to have no cyclic repair dependences between constraints
    • So all repair sequences terminate
    • Repair can fail only because of resource limitations
external consistency constraints
External Consistency Constraints

Quantifiers, Condition  Body

  • Body of form V = E, V.F = E, V.F[I] = E
  • Example

for b in free, true  D.block[b].nextBlock = -2

for i,j in next, true  D.block[i].nextBlock = j

for b in used, size(b.next) = 0  D.block[b].nextBlock = -1

  • Repair simply performs assignments
  • Translates model repairs to bit repairs
slide22

abst

0

intro

2

1

-5

1

-1

Directory Entries

Disk Blocks

abst

0

intro

2

1

-1

-1

-2

Directory Entries

Disk Blocks

Repair in Example

Inconsistent File System

Repaired File System

when to test for consistency and repair
When to Test for Consistency and Repair
  • Persistent data structures
    • Repair can be independent activity, or
    • Repair when data written out or read in
  • Volatile data structures in running program
    • Under programmer control
    • Transaction-based approach
      • Identify transaction start and end
      • Repair at start, end, or both
    • Failure-based approach
      • Wait until program fails
      • Repair and restart from latest safe point
experience
Experience
  • We acquired four benchmarks (written in C/C++)
    • CTAS (air-traffic control tool)
    • Simplified Linux file system
    • Freeciv interactive game
    • Microsoft Word files
  • We developed specifications for all four
    • Very little development time (days, not weeks)
    • Most of time spent figuring out Freeciv and CTAS
  • Each benchmark has
    • Workload
    • Fault insertion methodology
  • Ran benchmarks with and without repair
slide25
CTAS
  • Set of air-traffic control tools
    • Traffic management
    • Arrival planning
    • Flow visualization
    • Shortcut planning
  • Deployed in centers around country (Dallas/Ft. Worth, Los Angeles, Denver, Miami, Minneapolis/St. Paul, Atlanta, Oakland)
  • Approximately 1 million lines of C/C++ code
results
Results
  • Workload – recorded radar feed from DFW
  • Fault insertion
    • Simulate error in flight plan processing
    • Bad airport index in flight plan data structure
  • Without repair
    • System crashes – segmentation fault
  • With repair
    • Aircraft has different origin or destination
    • System continues to execute
    • Anomaly eventually flushed from system
aspects of ctas
Aspects of CTAS
  • Lots of independent subcomputations
    • System processes hundreds of aircraft – problem with one should not affect others
    • Multipurpose system (visualization, arrival planning, shortcuts, …) – problem in one purpose should not affect others
  • Sliding time window: anomalies eventually flushed
  • Rebooting ineffective – system will crash again as soon as it sees the problematic flight plan
slide29

Simplified Linux File System

intro

0

110

1011

directory

block

super

block

group

block

inode

bitmap

block

block

bitmap

block

inode

inode

disk blocks

inode block

Some Consistency Properties

  • inode bitmap consistent with inode usage
  • block bitmap consistent with block usage
  • directory entries refer to valid inodes
  • files contain valid blocks only
  • files do not share blocks
results1
Results
  • Workload – write and verify several files
  • Fault insertion – crash file system
    • Inode and block bitmap errors
    • Partially initialized directory and inode entries
  • Without repair
    • Incorrect file contents because of inode and disk block sharing
  • With repair
    • Bitmaps repaired preventing illegal sharing, correct file contents
slide31

Freeciv

Terrain Grid

O = Ocean

Consistency Properties

  • Tiles have valid terrain values
  • Cities are not in the ocean
  • Each city has exactly one reference from city location grid
  • City locations are consistent in
    • City structures and
    • tile grid

O

P

M

M

P = Plain

O

O

P

M

M = Mountain

O

P

M

M

City

Structures

P

P

P

M

loc: 3,0

loc: 2,3

results2
Results
  • Workload – Freeciv software plays against itself
  • Fault insertion – randomly corrupt terrain values
  • Without repair – program fails (seg fault)
  • With repair
    • Game runs just fine
    • But game plays out differently because of the different terrain values
microsoft word files
Microsoft Word Files
  • Files consist of a sequence of streams
  • Streams stored using FAT-based data structure
  • Consistency Properties
    • FAT blocks exist and contain valid entries
    • FAT streams are properly terminated
    • Free blocks properly marked
    • Streams contain valid blocks
    • No sharing of blocks between streams

abst

1

7

0

intro

1

9

2

1

-1

-1

-2

Directory Entries

FAT

Disk Blocks

results3
Results
  • Workload – several Microsoft Word files
  • Fault insertion – scramble FAT
  • Without repair
    • If blocks containing the FAT were incorrectly marked as free, Word successfully loads file
    • Otherwise, “The document name or path is not valid”
  • With repair
    • Word loads all files
extensions
Extensions
  • Elimination of external consistency constraints
    • Eliminates problems with translating repairs on the abstract model to the actual data structure
    • Repair algorithm analyzes model definition rules to generate repair actions for the actual data structure
extensions1
Extensions
  • Support for doubly linked data structures
    • Enables the repair algorithm to regenerate back links
extensions2
Extensions
  • Compilation and optimization of consistency checking
    • Achieved significant speedups (n x) by compiling the specification
    • Achieved further speedups () by partially optimizing away the construction of the abstract model
related work
Related Work
  • Hand-coded repair
    • Lucent 5ESS switch
    • IBM MVS operating system
  • Self-stabilizing algorithms
  • Log-based recovery for database systems
  • Recovery-oriented computing
    • Recursive restartability
    • Undo framework
conclusion
Conclusion
  • Data structure repair interesting way to (potentially) improve reliability
  • Specification-based approach promises to make technique more widely applicable
  • Moving towards more robust, probabilistic, continuous concept of system behavior
