SPECIFICATIONS. ELEMENTS. Principal Base: Unit where elements are put together Camera: . It work as thermographic or as a common camera. Its of small size and it resist impacts. Caterpillar wheels: For moving the robot in every terrain.
E N D
ELEMENTS • Principal Base: Unit where elements are put together • Camera:. It work as thermographic or as a common camera. Its of small size and it resist impacts. • Caterpillar wheels: For moving the robot in every terrain. • Shovel: To take the bomb out the ground without making the bomb explode. • Bomb detector: Issues a electromagnetic wave which detect object who are 5m underground • Robotic hands: For disarming the bomb after its on the plate. • Plate: The place where the bomb is placed. • Microchip: Electric component • Controller: Unit for controlling the robot
Material • Principal Base: Its made of steel alloys and some aluminium parts for making the robot. • Camera: made of aluminium and plastic. It includes solar panels for working, HD view. • Caterpillar wheels: Are made of aluminium and gum. • Shovel: Is made of iron. • Bomb detector: A copper disc of 4 cm diameter with a metal arm which holds it. They are equipped with the latest technology with digital media for the identification of possible mines. • Robotic hands: Made of aluminium, with independent finger movement for disarming the mines. • Plate: Circular aluminium surface. • Microchip: Component which is find on the market, that allows voice controlling • Controller: Plastic, circuits and a microphone
Characteristics • Principal Base:Dimensions: Length: 100cm, Width: 100cm, High: 30cm. • Camera: For detecting people, animals or any element near the bomb, also for checking that the bomb is completely disarmed. Also works on detection and vision through smoke, fog, the backlight in the dark and the vegetation. • Caterpillar wheels: Is a system that enables movement of the equipment for all types of terrain. • Shovel: Is used to excavate and remove the mine from the bottom. • Bomb detector: Intended for search and location of mines and explosive devices such as bombs. Are highly sensitive equipment designed to detect the metal components that are part of the mines. They can detect a copper disk of 4 cm. in diameter and up to 70 cms depth. • Robotic hands: Used for manipulating and disarming the bomb. • Plate: Dimensions: 40 cm Diameter, 10cm High. Is the area where the mine is placed close to the camera and robotic hands, facilitating the deactivation. • Microchip: This device is connected with the controller . • Controller: Model of glasses.
