in the name of god aptamer in vitro selection selex non selex

In the name of GodAptamer in-vitro selection SELEX & Non-SELEX

Maryam Tabarzad

ShahidBeheshti University of Medical Science


  • Aptamers are synthetic, highly structured, single stranded DNA/RNA ligands
  • Term “Aptamer”(Ellington&Szostak 1990) : aptus(to fit) + mer(oligo)
  • The first SELEX experiment on single- stranded oligonucleotides was published by Tuerk and Gold in 1990
  • 'Systematic evolution of ligands by exponential enrichment' (SELEX)
  • A protocol in which vast libraries of single-stranded oligonucleotides are screened for desired activities
selex components
SELEX components
  • Oligonucleotide random pool
    • DNA/RNA
    • Modified nucleic acids
dna or rna
  • RNA : in vitro transcription
  • ssDNA:
    • Asymmetric PCR
    • Biotin-streptavidin separation
    • Lambda exonuclease digestion
    • Size separation on denaturing-urea PAGE
selex components cont
SELEX components (cont.)
  • Target
    • Small molecules
    • Bimolecules
    • Whole cells
    • Whole organisms
selex components cont1
SELEX components (cont.)
  • Separation techniques
    • Filtration (nitrocellulose, Dialysis)
    • Chromatography (size exclusion, Affinity)
    • Electrophoresis (PAGE, Agarose, CE)
    • Magnetic beads
    • Precipitation (Immunoprecipitation, centrifuge)
    • SPR
    • AFM
negative selex
Negative SELEX

To exclude adsorbed ssDNA or RNA by the matrixes used for immobilizing targets with the purpose of gaining aptamers that can only adsorb the targets

counter selex
Counter SELEX

Alike to the negative SELEX

In order to get aptamers with stronger specificity

Excluding ssDNA or RNA molecules with coaffinity to the similar molecules of the targets.

Established by Jenison and his fellows(theophylline , caffeine )

subtractive selex
Subtractive SELEX

The same purpose as counter SELEX

To improve the selectivity of aptamers

The main difference between them lies in the targets of the process.

The targets of complex targets

Eliminates the ssDNA or RNA sequences that can bind the no purpose part of the complex target.

by Chinese researcher Wang (capability to distinguish differentiated PC12 cells from normal PC12 cells)

toggle selex
Toggle SELEX

A method to deal with several kinds of targets at the same time

The different rounds of the screening cycles focus on different targets according to the strategy during this toggle SELEX.

tecs selex

Target Expressed on Cell Surface-SELEX

blended selex
Blended SELEX

Other molecules, which can lead the oligonucleoride chain to the specific region of the target, are mixed to the screening pool.

This method was established by Smith first, For drug discovery

They connected valylphosphonate moiety (valP, an inhibitor of human neutrophil elastase) with the 5’ linker of a DNA splint oligonucleotide, which can combine with the end of the RNA pool according to the principle of complementary base pairing.

This inhibitor could be joined to the random sequence to form a “blended pool”

conditional selex
Conditional SELEX

Method for producing nucleic acid ligands that generate a signal, or cause a decrease in the level of a signal, in the presence of a target molecule or an environmental stimulus.

To measure the concentration of a target molecule or detect and quantitate an environmental stimulus.

mirror image selex
Mirror-image SELEX

The improvement of their stability and half-lives of DNA and RNA in vivo becomes the key point

Stable aptamers can be obtained by Spiegelmer Technology.

Screens aptamers of chiral target from dextrorotatory oligonucleotide pool

Then, the corresponding levorotatory oligonucleotide, called Spiegelmers, is synthesized


Spiegelmers have a good stability in vivo for not being able to be degraded by ribonuclease.

This method only suits for peptides and small molecules with optical activity. When targets do not have optical activity, this method could not be used anymore.

Spiegelmer cannot be amplified by PCR, it loses the advantage to be quickly obtained plentiful of aptamer in vitro.

photo selex
  • A screening method that uses the photosensitive nuclear acids’ ability of covalent cross-link with other molecules under a certain wavelength’s light
    • The selectivity of the aptamers would be higher
    • The false positive of this method is also higher
  • 5-IU or 5-BrdU is mixed into the screening pool, then the pool incubates with the target, the mixture is irradiated by ultraviolet radiation to make the cross-link reaction happen
  • The wavelength of the UV radiation and the irradiation time should be optimized to ensure that only specific sequences could react with the targets.
  • This method was first used in 1995 by Jensen, who obtained aptamers for Rev of HIV-1 by using 5-IU
genomic selex
Genomic SELEX

Uses the whole genome of a certain organism as the screening pool

Bioactive molecules as the targets

Great potential in the research of the interaction of bioactive molecules and nuclear acids

Study the regulation networks between protein and nuclear acid in proteomics

Include all the gene sequences and the intron sequences of the genome

cdna selex

At 1995, another library modification strategy was proposed by Dobbelsteinet al.

use of total cell RNA from Human B-cell lymphoma

Revealed three sites on 28S ribosomal RNA that have the potential to interact with L22

in vivo selex

In 1997 the first report of a selection made inside mammalian cells was done by Coulter et al.

uses transient transfection and an iterative procedure to enrich RNA-processing signals in culture

To find splicing enhancers sites

expression cassettes selex
Expression Cassettes SELEX

Peviously isolated aptamer to the E2F1 transcription factor was coupled to a Pol III promoter as an expression unit (or cassette) in a plasmidic DNA.

The construct contained a promoter, a tRNA sequence and the aptamer flanked by randomized regions.

expression cassettes selex1
Expression Cassettes SELEX

When the transcript was generated, tRNA structure stabilized the aptamer and the randomized stretches formed a stem flexible enough to allow the formation of the proper configuration for target recognition.

This expression cassette yielded RNAs that bind E2F with high affinity without sacrificing its structure and which can be stably expressed at high levels in mammalian cells

multiple pools selex
Multiple pools SELEX

A method that combines aptamers from different pools via a certain way

Screens the combinational production again in order to obtain multiple functional aptamers

Presently, two modes have been established

chimeric selex
Chimeric SELEX

Burke fused pairs of aptamers previously selected and the results show that the binding ability of the new aptamers to both the targets were reduced.

Applying dual selection pressure to recombined populations yielded the combinations that were best suitable for binding both targets.

The method can generate dual-function aptamers for a wide variety of applications, including catalysis, novel therapeutics, and studies of long-range RNA structure

multi stage selex
Multi Stage SELEX
  • To study of binding mechanism of aptamers and their targets
  • Two nucleic acid pools of N40 and N60 were founded to screen aptamers for cibacron blue and cholicacid
    • Stage one starts on the selection of parental aptamers from randomized libraries.
    • Stage two, a counter-selection step is used to avoid cross-reaction between each selection target (cibacron blue and cholic acid).
    • Stage three, obtained aptamers are fused to each other and reselected to isolate the most affinity allosteric pairs.
    • Stage four was to separate binding regions and returned to the counter-selection like stage two.
    • In stage five, new allosteric-DNA combinations are re-joined and re-selected to later be cloned and characterized
tailored selex
Tailored SELEX

Classical screening of aptamers must truncate the primers after sequencing and this must affect the selectivity of the aptamers, especially the aptamers with short random areas.

This technique decreases the number of the oligonucleotides of the primers according to the principle of complementary base pairing.

At the time of amplification, primers can be added to both the ends by a bridge sequences; after the amplification, these primers can be eliminated by alkali and the new pool for the next cycle is still with short stable sequences.

primer free selex
Primer-Free SELEX

Wen used a genomic library derived from the bacteriophage, and the gene 5 protein (g5p) from the phage as the target protein to obtain aptamers by means of primer free SELEX.

Primer sequences are removed from the genomic pool before incubation of the target protein and are then regenerated to allow amplification.

A key step in the regeneration of primer-annealing sequences is to use thermal cycles of hybridization-extension, with the sequences from unselected pools as templates.

Pan et al reported their work about minimal primer and primer-free SELEX protocols for screening of aptamers from random DNA libraries as well.

signaling aptamers
Signaling Aptamers

Basic design of a SELEX for aptamer beacons starts with a library that had been amplified using a 5′-labeled primer (fluorescein)

Then hybridized with a capture oligonucleotide that is biotynilated on the 3′-end and coupled to a particular quencher in the 5′-end.

Hybrids are recovered using streptavidin beads and mixed with the target

In such way that only those sequences forming specific interactions are released and dequenched.

Each aptamer has the property of emitting a signal proportional to target concentration.

flumag selex

Stoltenburget al. 2005

Used fluorescent labeling and an target immobilized over magnetic beads

The possibility of applying them as biosensors useful in clinical approaches

deconvolution selex
Deconvolution SELEX

Gold et al. 1998

Red Blood Cells

Specific aptamers to cell surface markers


affinity chromatography followed by physical fragmentation of the resin column

Nitsche et al.

Complete Vaccinia virus particles

ce selex
  • Capillary electrophoresis has been high efficiency and widely used in the analysis of nuclear acids and proteins.
  • Capillary electrophoresis was used in the screening of aptamers by Mendonsa and Bowser firstly at 2004
  • The reasons for the high efficiency of CE SELEX are as follows:
    • first, random sequences with stronger capacity will be obtained in each cycle because of the high efficiency of capillary electrophoresis
    • second, the target in this method is in solution, without the interruption of the matrix, the requirement of negative SELEX will be eliminated
nanoselection nm afm selex
NanoSelection® (nM-AFM SELEX)

Atomic force and fluorescence microscopy were combined with small copy number PCR by Penget al. in 2007

The possibility to isolate individual aptamers in a single selection cycle

microfluidic chips
Microfluidic chips

A little sample of target-DNA mixture (up to 5 nL) was injected into a capillary and separated with a high voltage setting the bases of microfluidics SELEX

Micro-magnetic device (MMS)

spr surface plasmon resonance
SPR Surface Plasmon Resonance

Flow cytometeryCell SELEX

non selex

High efficient and fast method for aptamers’ screening.

The key point of this method is that it omits the magnification step by PCR.

The random sequences with binding ability separated from the previous circle are used directly in the next one.

The screening process claims higher efficiency of the separation step, while capillary electrophoresis is a good choice.

Nonequilibrium capillary electrophoresis of equilibrium mixtures is a new separation-based affinity method.


automated selex
Automated SELEX

Cox set up a robotic work station configuration based on an augmented BeckmanuBiomek 2000 Pipetting robot for screening aptamers in 1998 and obtained aptamers for lysozyme

The described robotic work station can carry out eight screenings in parallel and will complete approximately 12 rounds of selection in 2 days.

Furthermore, the automatic work station was improved by containing a part of the generation of protein targets directly transcribed and translated from the respective gene in vitro on the robotic work station.

This should further accelerate aptamer screening for proteins and increase the utility of aptamers as reagents in proteome analysis

half automated selex
Half automated SELEX

As the screening conditions are not the same for all the aptamers, the automated system should be designed with some flexibilities such as the adjustment of the buffer components, the change of the time of incubation, and the optimization of the conditions for PCR.

The half-automated screening platform developed by Eulberg in 2005 can meet the claims above to some degree.

This system based on Amp 4200E (MWG Biotech Ebersberg, Germany) co-worked with ultrafiltration, fluorescence detection, and semiquantitative PCR. With this system, they obtained RNA aptamer for substance P

bioinformatics approaches for selex
Bioinformatics Approaches for SELEX

In silico analysis has also been used to study the behavior of nucleic acid populations during SELEX
