Presentation Transcript
references
References
  • Sachs, K., Perez, O., Pe'er, D., Lauffenburger, D. A. & Nolan, G. P. Causal protein-signaling networks derived from multiparameter single-cell data. Science308, 523-529 (2005)
  • Fisher, J. & Henzinger, T. A. Executable cell biology. Nat Biotech25, 1239-1249 (2007)
overview
Overview
  • Introduction to Systems Biology
  • Review of Modeling Techniques
  • An Example of Systems Biology in action
systems biology
Systems Biology
  • Goal of systems biology: How do the individual parts interact to yield system behavior?
    • Biology has focused on figuring out the pieces
    • But what happens when you fit them together?

Slide courtesy of Prof. David Dill, Stanford University

large data sets in biology
Large Data sets in Biology
  • Protein Interaction Maps
  • Synthetic Lethality Tests
  • Genome Sequencing
  • DNA Microarray
    • Capture the relative quantities of a large number mRNA’s in the cell
need for systems biology
Need for Systems Biology
  • Large data sets
  • Need to store, integrate and analyze this information into a coherent system
  • Simple diagrammatic representation schemes can no longer provide usable information
a simple kohn map
A Simple Kohn Map

Source: http://discover.nci.nih.gov/kohnk/fig6b.html

types of models
Types of Models
  • Mathematical models are used to represent actual quantitative relations between the molecules in the system
  • Used widely in physics
  • Generally use a system of differential equations to represent the process
  • Can be simulated and, in some cases, analyzed
  • Require very detailed knowledge of the system
a mathematical model
A Mathematical Model

Souce: http://www.homepages.ucl.ac.uk/~ucbpdsb/Report/node21.html

computational models
Computational Models
  • Allow for abstract representations of biological processes
  • Have an inherent execution scheme attached to the model
  • Certain techniques create finite state machines which can be model checked
model checking
Model Checking
  • A technique to analyze finite state machines
  • Essentially can check for certain temporal properties along all possible executions of the machine
  • Properties are of two types
    • LTL : Only temporal properties
        • In the next state, eventually, always
    • CTL : Temporal and path properties
        • Does there exist a path, Along all paths
criteria for evaluating models
Criteria for Evaluating Models
  • Scalability of the modeling scheme
  • Completeness of representation
      • Ability to incorporate a variety of effects at different levels of abstraction
  • Ease and Intuitiveness of the modeling scheme
      • The scheme should be related to actual biology
  • Tools available for the analysis of the information encoded in the model
types of biological processes
Types of Biological Processes
  • Gene Regulatory Networks

Source: http://www.bioinfo.de/isb/2006/06/0010/fig4_small.jpg

metabolic pathways
Metabolic Pathways

Source: http://pinguin.biologie.uni-jena.de/bioinformatik/Forschung/figs/Cglut_net3_color.png

protein interaction pathways
Protein Interaction Pathways

Source: http://jorde-lab.genetics.utah.edu/people/reha/4.gif

computational models16
Computational Models
  • Boolean Network:
    • Each molecule is considered a node with states as active or inactive
    • Connections between molecules define activation or inhibition of one molecule by another
    • A molecule is considered to become active if the sum of its activation is smaller than the sum of its inhibitions
robustness of the yeast cell cycle
Robustness of the Yeast Cell Cycle
  • Built a boolean network for the yeast cell cycle
  • Identified one fixed point attracting 86% of the states
  • Found that the cell cycle steps are extremely stable

Proc Natl Acad Sci U S A. 2004 Apr 6;101(14):4781-6. Epub 2004 Mar 22

petri net modeling
Petri Net Modeling
  • Two types of nodes: places and transitions
  • Edges are either from places to transitions or transitions to places
  • State of the system is defined by the places holding tokens

p2

p1

t3

t1

t2

p3

petri net modeling19
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t1 fires

p2

p1

t3

t1

t2

p3

petri net modeling20
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t1 fires

p2

p1

t3

t1

t2

p3

petri net modeling21
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t1 fires

p2

p1

t3

t1

t2

p3

petri net modeling22
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t2 fires

p2

p1

t3

t1

t2

p3

petri net modeling23
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t2 fires

p2

p1

t3

t1

t2

p3

petri net modeling24
Petri Net Modeling
  • Any transition for which all incoming places have tokens is active
  • State of the system changes when an active transition fires shifting tokens from in-places to out-places

t2 fires

p2

p1

t3

t1

t2

p3

pathalyzer
Pathalyzer
  • A place represents a molecule, a location and an activation state
  • Transitions represent reactions possible in the process

Source: http://chicory.stanford.edu/PAPERS/pathalyzer.pdf

interacting state machines
Interacting State Machines
  • Model biological systems as state machines
  • Allow multiple levels of hierarchy to capture different levels of detail in biological systems
  • Model concurrency through definition of parallel communicating state machines

Source: “Statecharts: A Visual Formalism for Complex Systems”, Jeff Pang

process calculus
Process-Calculus
  • Model molecules as communicating processes
  • Model reactions as communication between these processes
  • Try to capture the underlying constraints behind interactions

Source: Phillips et. al, Bioconcur, 2004

hybrid models
Hybrid Models
  • Combine mathematical models with computational models
  • Have discrete variables controlled by discrete state changes
  • Have continuous variables with rate of change governed by discrete variable
problem definition
Problem Definition
  • Cell Processes require numerous cellular signaling pathways
  • Information flow occurs through a cascade of molecules being modified chemically and physically
  • These transitions activate molecules allowing further propagation of the signal

Source: http://jorde-lab.genetics.utah.edu/people/reha/4.gif

traditional means of studying pathways
Traditional Means of Studying Pathways
  • Identify the phenotypic response generated by the pathway
  • Construct mutants to identify genes involved in the pathway
  • Perform double mutant experiments to discover relation between genes to understand causality in the pathway
drawbacks
Drawbacks
  • Cannot capture interactions between the different pathways
  • Cannot consider changes in behavior of the pathway under varied conditions
flow cytometry
Flow Cytometry
  • Cells are treated with antibodies which stain specific phosphorylated proteins in the cells
  • These cells are injected into a sheath flow to cross a laser one cell at a time
  • Light scatter and light excitation are used to identify quantity of stained molecules

Source: http://biology.berkeley.edu/crl/flow_cytometry_basic.html

modeling scheme bayesian networks
Modeling Scheme-Bayesian Networks
  • A Bayesian network over a set X is a representation of the joint probability distribution over X
  • The representation consists of a directed acyclic graph with variables as nodes and conditional distribution of each variable given its parent
  • Each variable is independent of its non-descendants, given its paren

X1

X4

X2

X5

X3

Source: Peer et. al

example a simple garden
Example- A Simple Garden
  • There are two events which could cause grass to be wet:

either the sprinkler is on or it's raining

  • Also, suppose that the rain has a direct effect on the use of the sprinkler (namely that when it rains, the sprinkler is usually not turned on)

Source: http://en.wikipedia.org/wiki/Bayesian_network

modeling signaling pathways using bayesian networks
Modeling Signaling Pathways using Bayesian Networks
  • Model molecules in specific activation states as variables
  • Arcs represent dependencies between molecules
  • Direction of arc is decided using intervention data
bayesian inference algorithm
Bayesian Inference Algorithm
  • Use standard scoring metrics that reward relatively simple models
  • Adapt model to incorporate interventions
bayesian inference algorithm43
Bayesian Inference Algorithm
  • Start with a random network
  • Explore the possible networks with steps of addition, deletion or reversal of single arc
  • Accept transition if score is increased
choosing high confidence edges
Choosing High-Confidence Edges
  • Process initialized 500 times with different random graphs
  • Choose only the high confidence networks
  • Select final edges present in >85% of the high confidence graphs
experimental validation of hypothesis
Experimental Validation of Hypothesis
  • Tested reported edges experimentally
  • To test Erk1 on Akt causality used small interfering RNA to inhibit Erk1
advantages of flow cytometry
Advantages of Flow Cytometry
  • Ability to observe molecular quantities in each cell separately preventing population averaging of results
  • Large amounts of data generated to enable accurate prediction of pathway structure
  • Possible to apply a variety of intervention reagents to further classify inter-pathway connections
verification of importance of flow cytometry
Verification of importance of Flow Cytometry
  • Applied Bayesian Network Analysis on 3 different data sets
    • An observation only data set
    • A population averages data set
    • A truncated individual cell data set
future possibilities
Future Possibilities
  • Flow Cytometry will grow in power as more antibodies are discovered to allow measurement of different molecules
  • Handling shortcomings due to need for acyclic graphs enforced by Bayesian Networks
    • All three edges missed in this paper were due to the acyclic condition
