Presentation Transcript
about me
About Me
  • Windows SharePoint Services MVP
  • President, BinaryWave
  • President, International SharePoint Professionals Association
  • Member, Patterns & Practices Advisory Board (spg.codeplex.com)
  • Web: www.binarywave.com
  • Blog: www.sharepointcowboy.com
  • Twitter: @eshupps
  • Facebook: www.facebook.com/sharepointcowboy
agenda
Agenda
  • SharePoint Basics
  • Packaging and Deployment
  • Common Artifacts
  • Remote Applications
  • Demo
    • Visual Web Parts
    • List Definitions
    • Event Receivers
    • Client Object Model
why sharepoint
Why SharePoint?
  • .NET
  • SharePoint

Custom

Development

  • Data Storage
  • Data Storage

Out of

the Box

  • Presentation
  • Presentation
  • Security
  • Security
  • Clustering
  • Clustering
  • API’s
  • API’s
  • Office Integration
  • Office Integration
  • Features
  • Features

Custom

sharepoint terminology
SharePoint Terminology

Timer Job

Web Part

Layout Page

Elevated Privileges

CAML

Farm

Safe Control

Content Type

Site Column

Declarative Workflow

Feature

STSADM

Site Collection

Application Page

Persisted Object

Site Definition

Solution Package

Scope

Event Receiver

Content Database

List Definition

Central Administration

Publishing Page

Theme

Web Application

ONET

List Instance

List View

Feature Receiver

Team Site

Field Control

Client Object Model

sharepoint architecture
SharePoint Architecture

Server Farm

Databases

Solutions

Service Applications

Alternate Access

Monitoring

Security

Policies

Web Application

Providers

File Types

Service Connections

Throttling

Managed

Paths

Quotas

Permissions

Site Collection

Templates

Web Parts

Features

User

Solutions

Content Types

Site Columns

Content

Database

Web

Features

Lists

Views

Workflows

Themes

Layouts

Alerts

server farms
Server Farms
  • A collection of SharePoint role servers and a SQL database server
  • Servers can perform one or more functions (web front end, search, application, etc.)
  • Farm-level features are managed via Central Administration
  • Custom code can be deployed at the Farm level and managed centrally
  • Solution Packages allow custom code to be automatically deployed across the farm

Server Farm

Web Front Ends

Application

Database

web applications and site collections
Web Applications and Site Collections
  • Web application = IIS Virtual Server
  • Each web application may be assigned its own app pool
  • Web applications may utilize multiple service applications
  • Site collections reside within web applications
  • Site collection functionality derived from underlying site definition
  • Special site collection types include My Sites, Shared Services Provider, Publishing Web

Portal

HR

Finance

Marketing

MySites

Central Administration

solution packages
Solution Packages
  • Solution Packages are “bundles” of functionality deployed to the farm or site collection (sandbox)
  • May contain one or more Features, assemblies, pages, controls, and other artifacts
  • SharePoint framework handles installation and configuration of solution items automatically across entire farm
  • Automated packaging and deployment in Visual Studio 2010
sandbox solutions
Sandbox Solutions
  • Trusted solutions which run in isolated process
  • Load balanced execution
  • Uploaded to solution directory in site collection
  • Administratively controlled via quotas
    • Can be automatically disabled
  • Subset of OM functionality
  • Ability to use trusted proxy for restricted operations

MyWebPart.dll

Runtime

Full Object Model

Subset Object Model

Proxy

features
Features
  • A ‘Feature’ is a defined set of functionality encapsulated within a specific format
  • Features are the basic building block of WSS v3 and MOSS development
  • Features may be comprised of any combination of code, including web parts, workflows, and site definitions
  • Features may be deployed manually or automatically on a local or global basis
  • Features are heavily dependent on CAML
web parts
Web Parts
  • Web Parts are a specific type of server control that inherit from System.Web.UI.WebPart
  • Web Parts contain discreet functionality that is exposed to the user in the context of a Web Part Page
  • Classic Web Parts do not have an IDE; Visual Web Parts host ASP.NET User Controls
  • Web Parts execute in the context of the current user
  • Web Parts may be deployed individually or in conjunction with other artifacts
list elements types and views
List Elements, Types and Views
  • Lists are virtual data repositories for unstructured content
  • Fields defined by associated content types and user-defined columns
  • Common lists types included OOTB
    • Custom list types may be created in UI or code
  • List data is stored in the content database associated with the site collection
  • Maximum limit for list items is 30M+
    • Be aware of performance implications and throttling when storing/retrieving large amounts of list data
  • Lists have associated views defined in UI or CAML
  • Custom field types may be created programmatically
event receivers
Event Receivers
  • Event Receivers are handler assemblies that respond to events on specific objects (Webs, Lists, Features, etc.)
  • Event receivers override built-in methods:
    • Adding/Added
    • Updating/Updated
    • Activated/Deactivated
    • Installing/Uninstalling
  • Event Receivers have no UI or user feedback mechanism
  • Event Receivers must run with Full Trust in the GAC

Code

Item Adding

Content

Database

Code

Item Added

relational data
Relational Data
  • LINQ to SharePoint
  • CAML joins

varq = fromannouncement indc.announcements

whereannouncement.Expires >= DateTime.Today

select new { announcement.Title, announcement.Body };

<Joins>     <Join Type='LEFT ListAlias='List1'>         <Eq>             <FieldRef Name='Field1' RefType='Id' />             <FieldRef Name='ID' List='List1' />         </Eq>      </Join>     <Join Type='LEFT' ListAlias='List2'>         <Eq>             <FieldRef List='List1' Name='SomeFieldName' RefType='Id' />             <FieldRef List='List2' Name=’ID’ />          </Eq>     </Join> </Joins>

workflow
Workflow
  • SharePoint Workflow inherits and builds upon Windows Workflow Foundation (WF)
  • Simple workflows can be created in SharePoint Designer, advanced workflows require Visual Studio
  • Two types of workflow – Sequential and State Machine
  • User interaction provided via InfoPath forms or custom ASPX pages
  • Workflows are tied directly to lists and list items
  • Built-in history, tasks, and tracking mechanisms
web services
Web Services
  • SharePoint Web Services provide remote access to a number of Object Model functions
  • Web services are limited in scope to several primary functional areas, such as Farm, Site, Web, List, List Items, List Views, etc.
  • Web services require a great deal of XML manipulation
  • Many web service functions require a solid understanding of CAML
  • Custom web services should be deployed as WCF solutions
  • Can increase load on Web Front End Servers
    • Deploy isolated WFE if used heavily
slide24
REST
  • HTTP-based XML data transfer
    • Stateless, cacheable, uniform
  • Conforms to Atom Publishing Protocol
  • Direct integration with SharePoint Services (Excel) and Lists
  • Sample queries:
    • http://myserver/_vti_bin/listdata.svc
    • http://myserver/_vti_bin/ExcelRest.aspx/Docs/Documents/sampleWorkbook.xlsx/model/Ranges('Sheet1!A1|G5')
client object model
Client Object Model
  • Subset of server OM functionality
  • .NET, Silverlight, JavaScript
  • Sync and Async processing
  • Request throttling
  • Batch object handling

Browser

JavaScript Controls

Client

Service

Server

Object

Model

JavaScript OM

Proxy

Proxy

Managed OM

Content

Database

Managed Controls

Client

Server
