  1. Forces Hooke’s Law

  2. Hooke: • In 1678, Robert Hooke published the results of his work on elasticity and the deformation of an elastic object. • An object is said to be elastic if it returns to its original dimensions after the applied force is removed.

  3. Hooke’s Law: low k = easy to stretch • The amount of deformation of an elastic object is directly proportional to the force applied to deform it. F = kx F = force applied on spring (N) k = force constant of the spring (N/m) x = amount of deformation of the spring (m)

  4. Ex. A spring has a force constant of 0.02N/m. What force is exerted to stretch the spring 12cm? F = kx F = ? F = (0.02)(0.12) k = 0.02 N/m F = 0.0024N x = 0.12m

  5. Ex. A 31 N force stretches a bungee cord 43 cm. What is the force constant of the cord? F = kx F = 31N 31 = (?)(0.43) k = ? k = 72.09 N/m x = 0.43m

  6. Ex. A spring that has an original length of 0.125m is stretched to a total length of 0.173m when a force of 3.6N is applied to it. What is the force constant of this spring. F = kx 3.6 = (?)(0.048) F = 3.6N k = 75 N/m k = ? x= 0.048m 0.173 – 0.125 = 0.048m

  7. Ex. A 325 g mass is applied to a spring with a force constant of 5.0 N/m. How much does it stretch? F = kx F = mg F = ? F = 3.185 N m = 0.325kg k = 5.0 N/m g = 9.8 N/kg x = ? F = (0.325)(9.8) 3.185 = (5)(x) F = 3.185 N x = 0.637m

  8. Ex. in N A mass of 500g stretches a spring 8cm when it is attached to it. What additional weight would you have to add so that the spring would stretch 10cm? F = kx F = kx F = mg F = (0.5)(9.8) 4.9 = (k)(0.08) F = (61.25)(0.1) F = 4.9 N k = 61.25 N/m F = 6.125 N 6.125 N – 4.9 N = Fadditional F = 1.225 N

  9. Ex. A B The following graph describes the spring constant of three different springs. Force (N) C length (m) Which of the springs would be the easiest to stretch? • small slope = low k F = kx • low k = easy to stretch spring C is easiest to stretch k = slope

  10. Try: pg 183 #1 - 3
