slide1

ASHLOK

Presents

Safe Earthing Electrode (ASEEL)

“ YOUR SAFETY IS OUR RESPONSIBIlITY”

slide2

Need For Superior Earthing

  • Industrial Revolution and Infrastructure Development
  • Electronic Boom in the 1980’s
  • Requirement of Precise Ohmic Values for various applications
  • Protection from chaotic electrical Hazards
  • NOT TO BE FORGOTTEN:
    • Human Safety
    • Infrastructure Safety
slide3

EARTHING SYSTEM

Earth Pit

Conductive Electrodes

Soil Enhancing Compound

slide4

Significance of Good Earthing

Low impedance

Resist Corrosion

Sufficient Mechanical strength to hold fault current

Earth Resistance

Varies with different soils

To be Checked before earthing the site

Decide the earthing system for the requirement

slide5

TECHNOLOGY & STRUCTURE

  • Pipe In Pipe Technology
    • Coaxial Pipes ( One inside the other)
    • Adequate Mechanical strength
    • Galvanized or
    • Coated for effective corrosive resistance
slide6

Ashlok Earthing – Features

  • Crystalline Conductive Mixture (CCM):
    • Contains metal alloys and natural compounds
    • CCM is an unique mixture having.
      • Excellent conductivity.
      • High specific gravity.
      • Anti-corrosive Properties.
      • Excellent bonding properties.
slide7

Ashlok Earthing – Features

  • Back Fill Compound (BFC) : After erecting the pipe in the earth pit the BFC is mixed with water and filled around the pipe.
    • Not soluble & part of the earth pit.
    • Hydroscopic in nature.
    • Enhances performance of electrode – Electrolytic Gel solution.
    • Maintains moisture and enhances conductivity around the electrode.
    • Does not leach in to the normal soil.
    • Reduces soil resistivity around the electrode.
slide8

Ashlok Earthing - Benefits

  • Scientifically developed, Readymade and Standardized
  • Maintenance Free
  • Consistency
  • Larger surface area
  • Low earth resistance
  • Corrosion resistant & Eco friendly
  • Long life – 15 -20 yrs
  • As per IS 3043:1987 standards
slide9

TECHNICALITIES

  • ASEEL 19 ( 3 Mtrs ) Dia 50mm
    • 20 KA /sec of rms
    • 51 KA peak value
  • ASEEL 39 ( 3 Mtrs ) Dia 80mm
    • 40 KA /sec of rms
    • 100 KA peak value
slide12

Ashlok Earthing – Specially Coated Electrodes

  • Advanced SPM ( Special Purpose Machine ) technology
    • 80 – 100 microns of coating on the outer pipe.
    • Customized as per application & requirement
  • SPM Benefits
    • Thick Coating
    • Uniformity
    • Mat Finish
  • Products in 2009
    • Zinc coated
    • Copper coated
    • Alloy coated
slide14

Installation – Normal Soil

3 M Electrode – Normal Soil

Augur a hole of 10” Diameter and 10’ in depth.

Put BFC at the bottom of the pit (App 5 Kgs)

Place the electrode in the middle of the pit.

Filter the mother soil (taken out during auguring) - mix the BFC with the soil.

Start putting the mixture around the electrode with adequate supply of water in the pit.

slide15

Installation – Normal Soil

  • With a long stick, start poking the sides of the pits to help in mixing the compound well and to remove the air bubbles.
  • Fill the pit completely with the compound mixture and pour abundant water in and around the pit.
  • Leave the pit to rest for a day.
  • Construct a chamber and provide connection to the equipment.
slide16

Achievements & Credentials

Best product award – Elecrama 2008

Accomplished the toughest installation in remote regions of India, under the harshest conditions

Our electrode has the distinction of being the only Earthing product to withstand the highest short circuit current tested by CPRI

Successfully converted our 1st Annual turnover into daily turnover

slide20

L

Some Prominent Customers

slide24

L

Some Prominent Customers

Railways and Aviation

slide25

ASHLOK SEE

  • CONVENTIONAL
  • Long term – (15 – 20 yrs)
  • One Time investment
  • Maintenance Free
  • Better Ohmic Value
  • Short Term ( 1 – 2 yrs )
  • Repetitive Investment
  • Continuous maintenance
  • Unpredicted Ohmic Value

Performance, Value, Safety & Good price (Vs) Only less COST

Please Act Smart & Fast - Be Safe

THANK YOU

“”
