Presentation Transcript
Wireless security by prof russell jones l.jpg

WIRELESS SECURITYbyProf. Russell Jones


Wireless communication issues l.jpg
WIRELESS COMMUNICATION ISSUES

  • Wireless connections are becoming popular.

  • Network data is transmitted using radio waves.

  • Physical security is no longer sufficient.

  • Transmissions can be intercepted outside the building where the data originates.


How wireless networking works l.jpg
HOW WIRELESS NETWORKING WORKS

  • Institute of Electrical and Electronics Engineers (IEEE) 802.11 is the standard

    • 802.11b & 802.11g

  • Security Standard

    • 802.1x & 802.11i (June 2004)

  • Can use various upper-layer protocols



Wireless threats l.jpg
WIRELESS THREATS

  • Theft of service

    • Free use of Internet access

    • Free use of applications

  • Eavesdropping

    • Confidential Information

    • Financial & Health Security Laws

  • Unauthorized access

    • Change of Data, insert viruses, disable system


Wired equivalency privacy wep l.jpg
WIRED EQUIVALENCY PRIVACY (WEP)

  • Provides encryption and access control

    • Media Access Control

  • Uses the RC4 encryption algorithm

    • Originally - 24-bit and 40-bit encryption

    • New versions support 128-bit encryption


Wep keys l.jpg
WEP KEYS

  • An attacker can discover the WEP key by using a brute-force attack.

  • All computers use a single shared WEP key.

  • WEP does not define a secure means to distribute the key.

  • WEP designed to use manual distribution of keys


Advantages of wep l.jpg
ADVANTAGES OF WEP

  • All messages are encrypted.

  • Privacy is maintained.

  • WEP is easy to implement.

  • WEP provides a basic level of security.

  • Keys are user definable and unlimited.


Disadvantages of wep l.jpg
DISADVANTAGES OF WEP

  • A hacker can easily discover the shared key.

  • You must tell users about key changes.

  • WEP alone does not provide sufficient wireless local area network (WLAN) security.

  • WEP must be implemented on every client and AP.


Wifi protected access wpa l.jpg
WiFi Protected Access (WPA)

  • Improved encryption using Temporal Key (TKIP)

    • Provides integrity testing

    • Scrambles the key fields

  • Use of smart card devices with EAP

  • Allows for MAC filtering


802 11i protocol june 2004 l.jpg
802.11i PROTOCOL (June 2004)

  • Improved authentication (PEAP, EAP)

    • Certificate-based (client and RADIUS)

    • Do not use EAP-MD5 (No protection to client password)

  • Requires authentication before access

  • Dynamic key assignment (Every 10 minutes)

  • Increased encryption (128-bit)

  • Adding preferred networks to clients


Authentication process l.jpg
Authentication Process

  • Wireless client contacts uncontrolled AP port

  • The AP requests identity of client

  • AP create a RADIUS request and transmits

  • RADIUS checks to see if AP is approved

  • Checks credentials and policies on client

  • If ok, AP generates WEP key and passed to client

  • Client access controlled port with WEP key


Wireless threats13 l.jpg
Wireless Threats

  • Attack by intruder with wireless connection

    • Use Switches instead of Hubs

  • ARP Spoofing

    • Warn client not to accept credential changes

  • Evil Twin Attack

    • Authentication of Access Points

  • WEP Attacks

    • www.airsnort.com & www.netstumbler.com


Basic defenses against wireless attacks l.jpg
BASIC DEFENSES AGAINST WIRELESS ATTACKS

  • Limit the range of radio transmissions.

  • Change the default SSID.

  • Disable SSID broadcast.

  • Use newer Access Points

  • Search for unauthorized access points (APs).

  • Restrict access by limiting access to specific media access control (MAC) addresses.

  • Separate the wireless segment from the rest of the network.


Basic defenses against wireless attacks15 l.jpg
BASIC DEFENSES AGAINST WIRELESS ATTACKS

  • Increase WEP encryption levels.

  • Change the default WEP keys.

  • Measure the signal strength.

  • Protect SNMP.

  • Do not use Shared Key Authentication

  • Secure clients

  • Use honeypots


Conclusion l.jpg
CONCLUSION

  • Access your particular security needs

    • Determine efficiency versus security trade-off

  • Any key is hackable

    • Use longest key feasible (not necessarily available)

    • Change as often as feasible

  • Remember the Wireless Rule

    • The more flexible access to a network is made, the less secure the environment
