  1. Š-ARM 2006 ARMed Tahometer http://www.papnkukn.net Papn Kukn

  2. Funkcije • čas, datum • število obratov na minuto • hitrost, pospešek, razdalja, čas vožnje • temperatura, ± 0,5 °C • zračni tlak, ± 1 mBar • altimeter, ± 8 m • štoparica, odštevalnik časa, budilka • zaklepanje (PIN koda) • zvočna opozorila • zaslon, tipke • RS232

  3. Hardver optični senzor LCD (2x16 znakov) senzor temperature (DS1820) induktivni senzor tipke (4) senzor zrač. tlaka (HYBMAP) zvočnik RS232 (UART1) operacijski ojačevalnik (LM324) LPC2138

  4. Tahometer

  5. Nadmorska višina z, p ∆z, ∆p z0, p0

  6. Softver kalibracijski način normalni način inicializacije inicializacije vrednost števca vnesi PIN (3) 200 ms interval izpiši na LCD tipka 1000 ms interval pošlji na UART1 medpom. UART1 2000 ms interval
