scs computing facilities software installation on facilitized linux machines

SCS Computing Facilities:Software Installation on Facilitized Linux Machines

Mark Held, Ken Tew

and Jeff Baird

Carnegie Mellon University

April 15, 2008

how software is installed
How Software Is Installed
  • These slides (and past SCS Admins Presentations) are available under http://www.cs.cmu.edu/~markh

CMU / SCS Computing Facilities

how software is installed3
How Software Is Installed
  • SUP (Software Update Program)
    • System files
  • Depot
    • Application Files (/usr/local)
  • Misc
    • Uses Depot for distribution
    • Details on how application software is prepared for distribution via Depot in the SCS Environment

CMU / SCS Computing Facilities

sup software update program
SUP (Software Update Program)
  • SUP runs nightly
    • Starting at 2:00 AM
      • With random delays of between 0 and 5.5 hours
      • Delays spread out load on servers
  • SUP updates “system” files
    • Not /usr/local
    • Kernel, /usr/bin, /bin, /lib, /usr/lib, /etc

CMU / SCS Computing Facilities

sup software update program5
SUP (Software Update Program)
  • Uses timestamps to determine what needs to be updated on the target machine
  • Basically a single collection is updated
    • fac.<AFS_SYSTYPE>
      • fac.amd64_f7 For Example
  • What has been updated is recorded in /usr/adm/fac/sup/fac.<AFS_SYSTYPE>/last
  • /usr/adm/fac/sup/fac.<AFS_SYSTYPE>/when is a binary timestamp

CMU / SCS Computing Facilities

sup software update program6
SUP (Software Update Program)
  • Trigger mechanism can invoke a script when a particular file has been updated.
    • See /usr/adm/fac/log/sup.log for examples
    • Merge of local and global printcap files into /etc/printcap (and then restart cups) is an example
    • .global and .local conventions

CMU / SCS Computing Facilities

sup software update program7
SUP (Software Update Program)
  • .global Convention
    • Used by printcap, inetd.conf, services
    • See the “last” file for all examples
    • Modern applications may not require a merged file
      • Read all files in a directory, so merge unnecessary
      • Examples: Cron.d, Pam.d, Init.d, Xinetd.d

CMU / SCS Computing Facilities

sup software update program8
SUP (Software Update Program)
  • Only One SUP Server in use
  • Security Updates are SUP’ed out
    • RPMs downloaded, then run
  • SUP will NOT delete local additions
    • Even overwritten files are not touched if the timestamp is newer than the file in the repository.

CMU / SCS Computing Facilities

sup software update program9
SUP (Software Update Program)
  • To halt SUP (and Depot) updates
    • Touch /etc/disableupdates (as local root)
    • Dangerous, as you will not get security updates
    • Machine could get into a “bad” state from which it cannot recover without intervention

CMU / SCS Computing Facilities

sup software update program10
SUP (Software Update Program)
  • FC5 Versus F7
  • The Fedora folks are including more packages with their OS distribution
    • The “C” means (meant) “Core”
  • Consequently some applications have migrated from /usr/local to /usr/bin and /bin

CMU / SCS Computing Facilities

depot
Depot
  • Depot maintains the /usr/local directory hierarchy
    • AFS-based repository of applications copied to local disks of all facilitized machines
    • 2nd part of the nightly ‘dosupdepot’ process

CMU / SCS Computing Facilities

depot12
Depot
  • Depot can be used to integrate local software into the /usr/local hierarchy
  • Process is relatively easy

CMU / SCS Computing Facilities

depot integration into usr local
Depot – Integration into /usr/local
  • First, install your software into:
    • /usr0/local
  • Do not leave “cruft” in the /usr0/local directory structure
  • Make sure that all paths are relative or if absolute refer to /usr/local (and not /usr0/local)

CMU / SCS Computing Facilities

depot integration into usr local14
Depot – Integration into /usr/local
  • Second, In your /usr/local/depot/depot.pref.local file add the following line:   path  mylocal  /usr0/local
  • This will tell depot to look in /usr0/local for a collection called 'mylocal' and link all of files found there into the /usr/local hierarchy.

CMU / SCS Computing Facilities

depot integration into usr local15
Depot – Integration into /usr/local
  • Note that you can install multiple packages into /usr0/local and depot will link all of them into your /usr/local environment.
  • The install directory does not have to be /usr0/local, and directory will do.
    • However, /usr0 is backed up.

CMU / SCS Computing Facilities

depot integration into usr local16
Depot – Integration into /usr/local
  • Third, as root, run the “dosupdepot” command.
  • Save the output somewhere, such as: dosupdepot >> /tmp/depot.log 2>&1
    • Then “tail –f /tmp/depot.log” to see the output as it is written.
  • Nightly runs will store log output in the /var/adm/fac.log directory

CMU / SCS Computing Facilities

depot integration into usr local17
Depot – Integration into /usr/local
  • Fourth, if there are ‘conflict’ errors in the log file and depot did not successfully complete, add the following to your depot.pref.local file:
  • In this example I am assuming that the 'java' collection is the one that is in conflict with your software install override  mylocal  java

CMU / SCS Computing Facilities

depot integration into usr local18
Depot – Integration into /usr/local
  • Depot finds conflict errors one at a time.
    • Once a conflict is encountered, depot exits
  • So, you have to keep running depot, and adding “overrides” until depot runs without finding conflicts
    • So a depot.pref.local file with multiple overrides would look like:
      • override mylocal java,foo,bar

CMU / SCS Computing Facilities

depot integration into usr local19
Depot – Integration into /usr/local
  • Installing directly in /usr/local
    • This can also be done, but you need to tell depot to ignore the new application
    • By default, depot will remove ANYTHING in /usr/local of which it is unaware

CMU / SCS Computing Facilities

depot integration into usr local20
Depot – Integration into /usr/local
  • To protect files under /usr/local
    • You simply have to add a “specialfile” directive into the depot.pref.local file
  • The “specialfile” directive can protect hierarchies or individual files
    • specialfile lib/foo
    • specialfile lib/firefox-2.0.0.5/plugins/libflashplayer.s

CMU / SCS Computing Facilities

misc applications
Misc Applications
  • Misc Applications are ‘depot-ed’ out to all machines with each depot run.
  • Depot integrates Misc Applications into /usr/local on facilitized Linux Machines
    • Not “all” Misc Applications, some must be requested
    • Ex: httpd, or wwwserv
  • Most Misc collections are maintained by volunteer maintainers
    • When you complain about missing software you are given the opportunity to provide it to the User community

CMU / SCS Computing Facilities

misc applications22
Misc Applications
  • Misc Maintainers receive
    • AFS Disk Space for Source and Binaries
    • Control over releases of their software
      • Alpha, Beta and Omega Environments
    • Ability to build and test new releases
    • Integration of their offering into the /usr/local hierarchy

CMU / SCS Computing Facilities

misc applications23
Misc Applications
  • Misc Applications’ releases are defined by the coll.conf file
    • All Misc Applications have a “common” directory
      • Usually this is an AFS mountpoint to a “common” volume
      • /afs/cs/misc/<APPLICATION-NAME>/common/conf/coll.conf

CMU / SCS Computing Facilities

misc applications coll conf
Misc Applications – coll.conf
  • Coll.conf file tells depot where to find packages.
  • stored in: /afs/cs/misc/<collection/common/conf/coll.conf
  • template in: /afs/cs/misc/tools/src/samples/coll.conf

CMU / SCS Computing Facilities

misc applications coll conf25
Misc Applications – coll.conf
  • Minimum information required:
    • sys_types  all the systems the collection is released for (any versions)
    • alpha, beta, omega and default definitions
      • these should be aliases

CMU / SCS Computing Facilities

misc applications coll conf26
Misc Applications – coll.conf
  • Other information
    • named releases for each version
    • specific sys_type releases.

CMU / SCS Computing Facilities

misc applications coll conf27
Misc Applications – coll.conf
  • Named releases:
    • contents <release-name> <relative path(s) to code>
    • Examples:
      • contents 4.2.4 @sys/4.2.4 common/4.2.4
        • Note: release-name 4.2.4 does NOT have to be same as pathname 4.2.4
      • contents 4.3.2 @sys/4.3.2 common/4.3.2
      • contents empty common/empty

CMU / SCS Computing Facilities

misc applications coll conf28
Misc Applications – coll.conf
  • Using aliases for named releases
    • alias alpha 4.3.2
    • alias beta  4.2.4
    • alias omega empty

CMU / SCS Computing Facilities

misc applications coll conf29
Misc Applications – coll.conf
  • Platform specific overrides
    • Syntax:
      • on <sys_type> alias <alias-name> <release-name or other alias>
    • Example:
      • on amd64_fc3 alias omega 4.2.4

CMU / SCS Computing Facilities

misc applications psmake
Misc Applications – psmake
  • Building misc collections use “psmake”
    • Psmake is a tool developed to efficiently work in the SCS environment
    • psmake allows you to build on multiple platforms from a single afs source tree
  • Facilities provides machines of each sys_type for building misc collections:
    • <sys_type>.sp.cs.cmu.edu

CMU / SCS Computing Facilities

misc applications psmake31
Misc Applications – psmake
  • Building for each platform will simply require:
    • Logging into build machine of the desired sys_type
    • Moving to misc src area
    • Running:
      • psmake init all (initialize and build package)
      • psmake check (test build - if package provides)
      • psmake install (install to afs misc sys_type area) Building misc collections

CMU / SCS Computing Facilities

misc applications psmake32
Misc Applications – psmake
  • Details on using psmake
    • Requires PSMakefile
    • Sample file available from:

/afs/cs.cmu.edu/misc/tools/src/samples/PSMakefile-autoconf

CMU / SCS Computing Facilities

misc applications psmake33
Misc Applications – psmake
  • For new misc collections:
    • Untar the source in the misc source area
    • Copy the sample PSMakefile to the root of the source area as PSMakefile

CMU / SCS Computing Facilities

misc applications psmake34
Misc Applications – psmake
  • Edit the following in the PSMakefile: 1) Comment out second line: ## This is a sample; you need to edit it for it to be useful. die "Read and edit the PSMakefile first!\n"; 2) Set the package (misc collection) name ## Set to the package name as it appears in directory names: $_package = 'sample';

CMU / SCS Computing Facilities

misc applications psmake35
Misc Applications – psmake
  • Edit the following in the PSMakefile (Cont’d): 3). Set the version pattern: ## Uncomment one of the following two lines.  Convention says you should ## use the first variant unless there is more than one package in the same ## collection. # $ReleasePat =~ s/omega/$_version/; # $ReleasePat =~ s/omega/$_package-$_version/; You should always pick 1st pattern unless multiple software packages are under one misc collection – (ex. httpd)

CMU / SCS Computing Facilities

misc applications psmake36
Misc Applications – psmake
  • Edit the following in the PSMakefile (Cont’d): 4) If you need to add ./configure options for ALL sys_types add them here: ## Fill in any additional platform-independent configure options here. @configure_args = ( '--prefix=/usr/local' ); Or just below this section for system dependent arguments.

CMU / SCS Computing Facilities

misc applications psmake37
Misc Applications – psmake
  • Once the PSMake file is configured it can usually be re-used for newer releases.
  • Create a README.cmu file in the misc/<name>/src which includes:   - Where the code came from   - Any problems you encountered in building   - Any special configuration options needed   - Commands you ran to build and install the code

CMU / SCS Computing Facilities

misc applications psmake38
Misc Applications – psmake
  • What to do if code already installs under /usr/local
    • Depot will take the contents of the /afs/cs/misc/<name>/<sys_type>/<version> and put it under    /usr/local
    • The simplest solution is to create a /afs/cs/misc/<name>/<sys_type>/<version>/depot.conf with the   contents: usr/local/bin     bin usr/local/lib     lib usr/local/lib64   lib64 usr/local/man     man usr/local/share   share
    • And so on….

CMU / SCS Computing Facilities
