natfw nslp intra realm communications and migration considerations

NATFW NSLP Intra-realm communications and Migration considerations

Cedric Aoun, Marcus Brunner, Miquel Martin

Martin Stiemerling, Hannes Tschofenig

IETF 58 Minneapolis

agenda
Agenda
  • NSIS NATFW NSLP role with NSIS unaware NATs
  • NSIS protocol traversal of NSIS un-aware NATs and Firewalls
  • Unilateral signaling - No NR on the far end host
  • Open issues

NSIS NATFW NSLP design team

nsis natfw nslp role with nsis un aware nats
NSIS NATFW NSLP role with NSIS un-aware NATs
  • An NSIS NATFW NSLP MUST be able to discover that an NSIS un-aware NAT is deployed on the data path
  • Once an NSIS un-aware NAT is discovered on the data path then either 2 options would be available:
    • STUN
    • Create a STUN like capability within the NATFW NSLP

NSIS NATFW NSLP design team

nsis natfw nslp role with nsis unaware nats

2-Address/port

Mapping response

1-Request address/port

mapping

NSIS NATFW NSLP role with NSIS unaware NATs

Net x

Alice

a.b.c.1/24

k.l.m.n/30

Phil

The net

a.b.c.e

Bob

e.f.g.h

a.b.c.d

“STUN-like capability”

NSIS NATFW

NSLP un-aware

NAT

NSIS NATFW NSLP signaling

Data Flow

NSIS NATFW NSLP design team

nsis natfw nslp role with nsis unaware nats1
NSIS NATFW NSLP role with NSIS unaware NATs

Net x

Alternate path issues

Alice

a.b.c.129/25

k.l.m.n/30

Phil

The net

a.b.c.e

a.b.c.1/25

Bob

e.f.g.h

a.b.c.d

“STUN-like capability”

NSIS NATFW

NSLP un-aware

NAT

NSIS NATFW NSLP signaling

Data Flow

NSIS NATFW NSLP design team

nsis protocol traversal of nsis unaware nats and firewalls
NSIS protocol traversal of NSIS unaware NATs and Firewalls
  • NSIS un-aware NAT traversal:
    • QoS NSLP flow specification need to be taken from STUN or STUN like approach
    • Qos NSLP responder could only receive messages if the responder is listening on the same address and port as the data flows (not practical)
    • NSIS messages traversing NSIS un-aware NATs would require that NSIS is transported on top of widely deployed transport protocols (de-multiplexing requirement)
      • Example of troublesome transport approaches:
        • Raw IP
        • SCTP (very rare NAT implementations support it)

NSIS NATFW NSLP design team

nsis protocol traversal of nsis unaware nats and firewalls1
NSIS protocol traversal of NSIS unaware NATs and Firewalls
  • NSIS un-aware Firewall traversal:
    • NSIS signaling MUST be allowed to bypass (proper identification of NSIS messages is required)
    • Data flows would need to use existing ACL capabilities

NSIS NATFW NSLP design team

unilateral signaling

No NSIS Responder on Bob’s end-host system

??

-Last NSIS aware NATFW will respond back with no NR on end-host notification

-NI will let the user application decide if it wants to continue

Unilateral Signaling

Net x

Alice

a.b.c.1/24

NSIS aware

NAT/FW + Qos NSLP

k.l.m.n/30

The net

a.b.c.e

NSIS aware

NAT/FW + Qos NSLP

e.f.g.h/30

a.b.c.1/24

Bob

a.b.c.d

NSIS NATFW NSLP design team

migration ntlp requirements
Migration NTLP requirements
  • NSIS un-aware NAT:
    • NTLP to run in datagram mode with NTLP sent from the source address and port on which the data will be sent and received

NSIS NATFW NSLP design team

open issues
Open issues
  • Are there known issues with RAO and existing Firewall implementations?
    • Packets could be dropped because of the IP option?
  • Unilateral signaling introduces a DoS attack, there is no means to determine if the targeted NR can’t be reached because of lack of protocol support or because the destination is not valid

NSIS NATFW NSLP design team

open issues1
Open issues
  • How to deal with NATFW NEs that don’t have a trust relation with the NI in the case of uni-lateral signaling?
  • Unilateral operations require that last NATFW NSLP in the path respond back on behalf on the un-available NATFW NR
    • Does the NTLP play a role in this?

NSIS NATFW NSLP design team

backup
Backup

NSIS NATFW NSLP design team

intra realm communications
Intra-realm communications

Net x

Alice wants to talk to Bob

Alice

k.l.m.n/30

a.b.c.1/24

a.b.c.e

The net

Bob

NSIS aware

NAT/FW

a.b.c.d

How to avoid useless resource spending on NAT and Firewalls (potentially event Qos gates)?

Let Bob provide to Alice both his locally scoped and global scoped addresses

NSIS NATFW NSLP design team

intra realm communications1
Intra-realm communications

Net x

Alice

Alice wants to talk Phil

a.b.c.1/24

NSIS aware

NAT/FW + Qos NSLP

k.l.m.n/30

The net

a.b.c.e

Bob

NSIS aware

NAT/FW + Qos NSLP

e.f.g.h/30

a.b.c.1/24

a.b.c.d

Local scoped address could obviously overlap, a solution needs to be provided to handle that case

Phil

a.b.c.d

NSIS NATFW NSLP design team

intra realm communications2
Intra-realm communications
  • Proposed solution:
    • Communicate several NR addresses to the NI
      • The first response received from an NR will hint the NR address to use for the rest of the messages
      • NSIS messages need to be sent simultaneously and not sequentially (I.e. don’t wait for responses).
    • User application impacts:
      • Several NR addresses need to be provided
    • NTLP impacts:
      • Although a messaging association was already linked to a destination address, it needs to be re-checked if applicable or not to avoid the confusion of overlapped local scoped addresses

NSIS NATFW NSLP design team
