Presentation Transcript
slide1
Michigan’s Waste toEnergy OpportunityPresented to: Michigan Department of Energy, Labor, and Economic GrowthApril 29, 2009
  • Brad Schneider & Bill Chynoweth, Recovered Energy Resources, Inc.
  • Dave Prouty, President & CEO, Heat Transfer International, Inc.

Recovered Energy Resources

slide2

Waste will become energy. A liability will become an asset.An opportunity and a vision will become a reality.The benefits will accrue to Michigan COMMUNITIES.

Project Team Vision

Recovered Energy Resources

slide3

Why Waste-to-Energy?

  • Michigan’s urban regions are poor in Wind and Solar resources, but have an abundance of MSW
    • Fuel source is close to every population center, offering significant transportation savings and associated emissions (esp. CO2) reductions
  • Michigan’s significant Agricultural waste within rural regions is not being fully exploited for energy production
    • Gasification provides a clean and efficient means to generate thermal and electric energy
  • MSW Waste-to-Energy (and other forms of Biomass) provides competitive and dependable base load power
    • Other forms of baseload renewable power (e.g. geothermal) do no exist in Michigan
  • Michigan has the opportunity to lead the nation in exploiting this relatively nascent opportunity
    • Provide a spring-board for uniquely Michigan based developers, manufactures, engineering and construction firms
  • Michigan has a unique stewardship responsibility for protection of the Great Lakes
    • MSW-to-Energy protects Michigan watersheds

Recovered Energy Resources

slide4

Strong Government / Institutional Support

  • US Department of Agriculture
    • Co-funded RER feasibility study with USDA for Montmorency-Oscoda-Alpena Solid Waste Authority
    • $500,000 grant and loan guarantee to Sietsema Farm Feeds (under construction in Howard City)
  • Michigan Public Service Commission
    • $2,300,000 Energy Efficiency Grant awarded to HTI for Gasification Technology Demonstration Center in Kentwood
  • Michigan Economic Development Corporation
    • Science and Technology Vetted and endorsed by Technology Advisory Board
    • Business Strategy vetted and supported by MEDC Bio=Energy Team
    • Co-funded RER feasibility study with USDA for Montmorency-Oscoda-Alpena Solid Waste Authority (DTE Energy is co-development partner)
  • City of Kentwood
    • Granted Renewable Energy Renaissance Zone
  • Next Energy
    • Vetted and endorsed by Technology Advisory Panel

Recovered Energy Resources

michigan economic opportunities from waste to energy gasification
Michigan Economic Opportunities from Waste-to-Energy Gasification
  • Waste-to-Energy will ensure that the Governor’s goal of reducing fossil fuel imports for electricity production by 45% by the year 2020 can be achieved
  • Waste-to-Energy will ensure that the Governor’s goal of 25% renewable energy by 2025 can be achieved
  • Gasification technology does not require the massive amounts of MSW and economies of scale required with traditional urban-centered incinerator or plasma facilities
  • Provides economic opportunities for all regions (e.g. under-served urban areas and small communities)
    • 18 – 25 permanent jobs are created per small scale (e.g. 5 MW) waste to energy plant

Recovered Energy Resources

michigan needs renewable energy and a sustainable solid waste strategy
Michigan Needs Renewable Energy ANDa Sustainable Solid Waste Strategy!
  • Testifying before the Michigan Senate Natural Resources Committee in 2005, DEQ Director, Steve Chester outlined the need for a more comprehensive solid waste strategy designed to improve Michigan’s recycling program and to ensure that landfill capacities remain adequate
  • According to Director Chester, the cornerstone of a responsible solid waste management program must include:
  • Funding efforts to increase recycling provide for economic development and build technical capacity at the local level
  • Expand the bottle bill to control litter and reduce the amount of recyclablematerial going to the landfills
  • Ensuring disposal capacity for waste generated in Michigan while reducing excess capacity attractive to out of state waste generators
  • Doubling the amount of waste recycled in Michigan by providing recycling opportunities for all Michigan citizens through plans designed and implemented at the local level
  • Update the original 1988 Michigan Solid Waste Policy to support these goals

Recovered Energy Resources

slide7

MSW-to-Energy vs. Landfill Gas (LFG)

  • Energy from MSW is 6-9 times greater than energy produced from LFG (without the need to wait 15+ years)
    • System can exploit LFG from existing landfills without the intensive capital and O & M expenses required for LFG-to-Energy systems
  • Every ton of MSW converted to energy saves one ton of CO2
  • Energy from waste can extend the life of landfills by 9 times
  • US DOE, EPA, FERC, and PURPA all recognize MSW as sustainable and indigenous
    • More that 18 states, including Michigan, include MSW as renewable

Recovered Energy Resources

slide8

Solid Waste Models

Typical Municipal Solid Waste Model

Typical Recycled Waste Model

HTI / RER Waste to

Energy Solution

Recovered Energy Resources

hti rer solid waste solution continued
HTI/RER Solid Waste Solution (Continued)

2007 MDEQ records show that greater than 3,000 MW

could be produced from existing MI landfills

800 KW of power produced from each Ton of MSW

Nearly 100% recyclingof glass and metals create a revenue stream & increases landfill capacity

slide11

History of Gasification

Recovered Energy Resources

slide12

HTI Solid Waste Gasification System

Recovered Energy Resources

slide13

Why HTI’s Starved Air Low Temperature (SALT) Gasifier?

  • “SALT”…
          • Produces a cleaner combustible syngas
          • Leaves undesirables in the ash
          • Minimizes slag and soot
          • Reduces airborne emissions (more easily permitted)
          • Provides more options for producing heat and power
          • Higher system efficiency (energy out/waste in)
          • Simpler system
            • Lower initial equipment cost
            • Lower operating temperatures
            • Costs less to operate and maintain
            • Shorter concept-to-operation timeline
          • Low maintenance equipment yields long life span

Recovered Energy Resources

materials previously destroyed by hti s gasification systems
Materials Previously Destroyed by HTI’s Gasification Systems

BIOMASS

Sawdust

Pallets

Sugar beets

Sugar cane

Turkey Litter

GASES

CO

H2

Syngas

SLUDGES

Sewage

Industrial

Hazardous

MUNITIONS

Spent

Nerve gas filters

OTHER

Pathological wastes

Industrial trash

Returned pharmaceuticals

Organic process residues

Waste solvents

Laboratory chemicals

Radioactively contaminated waste

Municipal solid waste

Industrial sludge

Wood products

Agricultural products

Ethanol plant by products

  • MEDICAL
  • Drugs
  • Lab animals
  • Sharps
  • Solvents
  • Sludges
  • MSW
  • Unsorted
  • Tires
  • PCBS
  • Liquid
  • Sludges
  • PLASTICS
  • Carpet
  • Wraps
  • Seran
  • Mill scrap

Recovered Energy Resources

slide15

Biomass Energy Project in Development:

Sietsema Farms (Turkey Litter to Electricity)

slide16

RER Waste-to-Energy Plant Description

  • Step 1: Incoming waste is received by the plant where foreign and oversize material is removed. It is then shredded, removing the metals and glass, and the sorted waste is stored for further processing.
  • Step 2: The sorted waste is conveyed from the storage system to the gasifier array, where it is heated until it releases syngas. The syngas flows to the Lo-Nox oxidizer where it is combusted to produce a high temperature exhaust gas.
  • Step 3: The exhaust gas is passed into heat recovery to power conversion system, of which there are several technologies to implement depending on application and site specifics.
  • Step 4: Ash produced by the gasifiers is conveyed to a disposal container for land disposal or reuse.

Recovered Energy Resources Lipten Company

slide17

Waste will become energy. A liability will become an asset.An opportunity and a vision will become a reality.The benefits will accrue to Michigan communities.

Michigan can lead the nation.

THANK YOU!

Recovered Energy Resources
