Presentation Transcript
symptoms
Symptoms
  • pain located URQ to upper middle of the abdomen.
  • Pain occurs within minutes of a meal
  • clay colored stools
  • Jaundice (obstructive/conjugated)
  • Nausea
  • Vomiting
  • Mild fever
work up
Work up
  • Blood tests:
    • Amylase and Lipase- digestive enzymes made by the pancreas
    • Bilirubin- jaundice (typically measures both BC/BU)
    • CBC
    • Liver function
  • Abdominal Ultrasound
  • Abdominal CT scan
  • Abdominal X-ray
  • Oral cholecystogram -Eat high fat meal at noon, low fat meal at night, take tablets and then NPO until the x-ray the next day
  • Gallbladder radionuclide scan- 1-2 hr scan that takes pictures to detect inflammation or gallstones

Useful for detecting gallstones and location

abdominal ultrasound example
Abdominal Ultrasound Example

From St. Luke’s Health System Resource Library

diagnosis 1
Diagnosis1
  • Acute/Chronic cholecystitis:
    • Cholelithiasis -90% of cases & often obstruction of the cystic duct, in chronic it is not understood if gall stones are what first initiate symptoms
    • Rarely tumors: cholangiocarcinoma freq: 0.6/100,000 malignancy of the biliary tree
  • Biliary dyskinesia: (chronic acalculous gallbladder disease)
diagnosis 11
Diagnosis1
  • Cholelithiasis (gallstones)- 10-20% of the population
    • Pigment stones and Cholesterol stones
    • Women 2x more likely to have, aging also plays a role
    • Choledocholithiasis- if gallstone(s) located in the common bile duct

From Telepathology.com

laparoscopic cholecystectomy
Laparoscopic Cholecystectomy

Advantages

Contraindications2

  • Low mortality
  • Shorter hospital stay
  • Quicker recovery
  • Decreased cost
  • Gall Bladder or Bile duct tumors
  • Portal Hypertension
  • Acute pancreatitis
  • Biliary fistula
  • Mirizzi’s Syndrome
  • Pregnancy in the final trimester
  • Cardiopulmonary or Coagulation disorders
instrumentation
Instrumentation
  • 2 or 3 5mm trocars
  • 1 or 2 10mm trocars
  • 10mm 30° scope
  • liver retractor/
  • grasper(s)
  • straight dissectors
  • clip applier
  • Scalpel and Suture
  • Metzenbaum Scissors
  • L-hook electrocautery
  • 5 mm/10mm, irrigation & suction
  • Cholangiogram depending on location of stones
  • extraction bag
structures to avoid
Structures to avoid
  • Duodenum and colon on trocar placement
  • Common bile duct (2-7% chance of injury)
  • Common Hepatic Duct (can be mistaken for cystic artery in anatomical variations)
  • Liver and other instruments with L-Hook
  • Also note any variations such as an accessory hepatic ducts
anatomy in the operating room
Anatomy in the Operating Room
  • Falciform Ligament
  • Fundus of Gallbladder
  • Infindibulum of Gall bladder
  • Calot’s Triangle
    • Cystic Duct (connecting from Common Bile Duct)
    • Common Hepatic Duct
    • Liver
    • Cystic Artery (often arises from the right hepatic artery, but note that there are variations
    • Calot’s (Lund’s) Node
operating room setup
Operating Room Setup

Placed in a reverse Trendelenburg and tilted slightly to the left after insertion of optic trocar

retrograde laparoscopic cholecystectomy steps
Retrograde Laparoscopic Cholecystectomy Steps
  • Prep the patient
  • Placement of first trocar (midline navel)
  • Creation of Pneumoperitinium
  • Final Diagnosis (2 min 47 sec)
  • Place patient in Reverse Trendelenburg position slightly rotated to the left
  • Apply local anesthetics and 2-3 other trocars under visualization of scope (4 min 50 sec)
trocar placement
Trocar placement

Surgical Trocar (both are often 5mm)

Optical Trocar

Retraction of gall bladder/liver

retrograde laparoscopic cholecystectomy steps1
Retrograde Laparoscopic Cholecystectomy Steps
  • Assistant grasps fundus of gallbladder and retract superiorly
  • Grasp infundibulum of the gallbladder (may need some dissecting)
  • Create tension by pulling slightly superior and laterally on the infundibulum of the gall bladder
  • Dissect Calot’s Triangle starting towards the infundibulum of the gall bladder and working your way to the common bile duct (12 min 51 sec)
slide15

Infundibulum of Gall Bladder

Cystic Artery

Cystic Duct

retrograde laparoscopic cholecystectomy steps2
Retrograde Laparoscopic Cholecystectomy Steps
  • Using the gallbladder as point of reference, place 2 distal clips and 1 proximal clip along the cystic duct. (30 min 3 sec)
  • Divide making sure both jaws are visible to prevent vascular injury
retrograde laparoscopic cholecystectomy steps3
Retrograde Laparoscopic Cholecystectomy Steps
  • Using the gallbladder as point of reference, place 2 distal clips and 1 proximal clip along the cystic artery. (39 min 21 sec)
  • Divide and cauterize/clip any necessary collateral arteries
retrograde laparoscopic cholecystectomy steps4
Retrograde Laparoscopic Cholecystectomy Steps
  • Dissect away the posterior wall of the gall bladder using an L-Hook. Make sure L-hook does not come in contact with other instrumentation to prevent tissue damage

(45 min 9 sec)

retrograde laparoscopic cholecystectomy steps5
Retrograde Laparoscopic Cholecystectomy Steps
  • Remove gallbladder via bag or trocar
  • Irrigate and Suction
  • Final visualization check
    • Deroofing of ovarian cyst (55 min 28 sec)
  • Irrigate and suction
  • Release of CO2 and steri-strip or suture trocar incisions
post operative care
Post-operative care
  • Transfer to PACU
  • Discharge typically within 24 hours
  • Post-operative pain can typically be relieved with OTC pain medications
  • Patient can resume normal daily activities in roughly 24 hours
  • Heavy lifting should be avoided for a few weeks
  • Watch for drainage, bleeding, swelling around incision sites, and for mild fever, as this could indicate complication
references
References
  • 1. Kumar , V., Abbas, A., & Fausto, N. (7th Ed.). (2005). Robbins and Cotran: Pathologic basis of disease. Philidelphia, PA: Elsevier Saunders.
  • 2. Kremer, K., Platzer, W., Schreiber, H., Steichen, F.M. (2001). Minimally Invasive Abdominal Surgery. New York, NY:Theime.
  • 3. Berci, G., Nobuto, T., Phillips, E.H. (2008). A pocket atlas of laparoscopic surgery. Tuttlingen, Germany: Endo:Press.
  • 4. Longstreth, G.F. (2009, July 6). Acute cholecystitis. Retrieved from http://www.nlm.nih.gov/medlineplus/ency/article/000264.htm
  • 5. Swierzerski, III, S.J. (2001, November 1). Cholecystectomy: preoperative procedures, postoperative procedures, complications. Retrieved from http://www.surgerychannel.com/cholecystectomy/preop.shtml
