Calibration Meeting on NuSTAR and XMM Analysis of Coma Cluster - March 2014

The EPIC Calibration Meeting on March 26, 2014, focused on the analysis of the Coma cluster, a nearby cluster characterized by a uniform high-temperature distribution (7-9 keV). The meeting discussed NuSTAR calibration utilizing data from XMM-Newton. Detailed comparisons of temperature maps and broadband fits were performed, highlighting the relationship and discrepancies between NuSTAR and XMM data. The meeting concluded with future work recommendations, including additional XMM observations and fits across various energy bands for improved analysis of hot thermal plasmas.

cece
Download Presentation

Calibration Meeting on NuSTAR and XMM Analysis of Coma Cluster - March 2014

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Garhing, 26 March 2014 EPIC Calibration Meeting XCAL NuSTAR-XMM WITH COMA CLUSTER FABIO GASTALDELLO INAF, IASF-Milano NuSTAR calibration & cluster WG

  2. Nearby cluster with a rather uniform high temperature distribution (7-9 keV). Its center observed mainly (but not only) for calibration purposes • NuSTAR analysis with nustardas1.3.1 and CALDB 20132213 • XMM pn (doubles) analysis obsid 0153750101 December 2001 with SAS 12.0 ANALYSIS

  3. COMA NUSTAR TEMPERATURE MAP • Boxes of 2 arcmin x 2 arcmin

  4. COMA NUSTAR TEMPERATURE MAP WIK+14

  5. DET A

  6. DET B

  7. COMPARISON T A-B

  8. CHECK WITH CHANDRA SANDERS+13

  9. COMPARISON WITH XMM pn

  10. Mean of the ratio pn/A 0.892 with stdev 0.084 COMPARISON T A 3-20 keV-pn 0.5-10 keV

  11. Mean of the ratio pn/B 0.893 with stdev 0.077 COMPARISON T B 3-20 keV-pn 0.5-10 keV

  12. Mean of the ratio pn/A 1.185 with stdev 0.204 COMPARISON T A-pn 3-10 keV

  13. Mean of the ratio pn/B 1.156 with stdev 0.189 COMPARISON T B-pn 3-10 keV

  14. Mean of the ratio A/pn 0.986 with stdev 0.137 COMPARISON norm A 3-20 pn 0.5-10 keV

  15. Mean of the ratio B/pn 0.967 with stdev 0.135 COMPARISON norm B 3-20 pn 0.5-10 keV

  16. With nustardas 1.2.0 and caldb 20130509 • Mean of the ratio B/pn 1.147 with stdev 0.158 COMPARISON norm B 3-20 pn 0.5-10 keV

  17. XMM pn BROADBAND FIT • 105/120 10.0 ± 1.1 norm 3.1± 0.1 E-03 3-10 keV

  18. XMM pn BROADBAND FIT

  19. XMM pn BROADBAND FIT • 105/120 7.5 ± 0.3 norm 3.5± 0.1 E-03 0.5-10 keV

  20. pn and its bkg nustar and its bkg COMPARISON WITH XMM pn

  21. COMPARISON WITH XMM pn

  22. Nustar has the capabilities to constrain well hot thermal plasmas like the 8-9 keV emission in Coma • Comparison with XMM pn still stresses the problems with cluster broad band fitting (Nevalainen+10) • Future work: more XMM obervations, fit in varius energy band (2-7 keV), Fe line ratios SUMMARY
