  1. Chapter 4 Data Structures ADT Examples • Stack • Queue • Trees

  2. Data structures in Java • Java provides a set of data structures… well, we can implement a set of data structures using Java. • There is a major difference between C/C++ and Java • dynamic data structures (C/C++ uses pointers) • static data structures (no pointers, however this does not prevent us from implementing data structures in Java)

  3. Stack Class • Stack (LIFO data structure) can be implemented as the following Class: class Stack { …. Stack() { … } boolean empty() { … } void push(Object o) { … } Object pop() { … } Object peek() { … } } • An application - check if balanced parentheses, e.g. (a+sin(x)-A[i-j])/(cos(x)+{p-q}/{m-n})

  4. An Application - Balanced Parenthesis Checking class ParenMatcher { …. private boolean match(char c,char d) { switch(c) { case ‘(‘ : return (d==‘)’); case ‘[‘ : return (d==‘]’); case ‘{‘ : return (d==‘}’); default : return false; } }

  5. ...Parenthesis Checking public void parenMatch() { Stack s = new Stack(); int n = inputString.length(); int i= 0; char c,d; while (i<n) { d=inputString.charAT(i); if (d==‘(‘ || d==‘[‘ || d==‘{‘) s.push(new Character(d)); else if (d==‘)‘ || d==‘]‘ || d==‘}‘) if (s.empty()){ output(“More right parenthesis than left”); return;} else {c = ((Character)s.pop()).charValue(); if (!match(c,d)){ output(“Mismatched parenthesis”); return;}} ++i;} }

  6. Array Implementation (for Stack) capacityIncr itemArray class Stack { private int count, capacity, capacityIncr; private Object[] itemArray; public Stack() { count=0; capacity=10; capacityIncr=5; itemArray = new Object[capacity]; } count capacity

  7. Stack Methdos public boolean empty() {return (count==0); } public Object pop(){ if (count==0) return null; else {return itemArray[--count];} } public Object peek(){ if (count==0) { return null; } else {return itemArray[count-1];} }

  8. More Methods public void push(Object ob) { if (count==capacity){ capacity += capacityIncr; Object[] tempArray = new Object[capacity]; for (int i=0; i<count; i++) {tempArray[i] = itemArray[i];} itemArray=tempArray; } itemArray[count++]=ob; }

  9. Linked-List Implementation (for Stack) item link class StackNode { Object item; StackNode link; } An Object

  10. Stack Class class Stack { private StackNode topNode; public Stack() { topNode=null; } public boolean empty() {return(topNode==null);} public Object pop() { if (topNode==null) { return null; } else { StackNode temp=topNode; topNode=topNode.link; return temp.item; } }

  11. More Methods public Object peek() { if (topNode==null) return null; else return topNode.item; } public void push(Object ob) { StackNode newNode = new StackNode(); newNode.item = ob; newNode.link = topNode; topNode = newNode; }

  12. front A count B rear 7 C D G E F Queue Class • Stack (LIFO data structure) can be implemented as the following Class: class Stack { …. Queue() { … } ; boolean empty() { … }; void insert(Object o) { … };// at back Object remove() { … };// from fornt } • Useful for simulation, etc. • Queue on a Circular Track • Advance front & rear one, as follows: front=(front+1) % size; rear=(rear+1) % size;

  13. Circular Array Implementation (for Queue) class Stack { private int front,rear,count,capacity, capacityIncr; private Object[] itemArray; public Queue() { front=0; rear=0; count=0; capacity=10; capacityIncr=5; itemArray = new Object[capacity]; } public boolean empty() {return (count==0); } public Object remove() { if (count==0) { return null; } else {Object tempitem = itemArray[front]; front=(front+1) % capacity; count--; return tempitem;} }

  14. More Methods public void insert(Object ob) { if (count==capacity){ capacity+=capacityIncr; Object[] tempArray = new Object[capacity]; ..copy to new array & assign to itemArray.. } itemArray[rear]=ob; rear=read+1 % capacity; count++; }

  15. Trees root • Trees are useful for organising complex data & for representing expressions. Level 0 * internal nodes Level 1 if fact 4 7 Level 2 5 > leaves Level 3 n 5

  16. Binary Trees • A binary tree is either an empty tree, or a node whose left and right subtrees are binary trees. class TreeNode{ Object info; TreeNode left, right; TreeNode(Object ob, TreeNode l,r) {info=ob;left=l;right=r;} TreeNode(Object ob) {info=ob;left=null;right=null;} } data constructor

  17. t2 * empty trees + 8 t1 7 / 6 3 Creating a tree: TreeNode t1=new TreeNode(“/”,new TreeNode(“6”),new TreeNode(“3”)); TreeNode t2=new TreeNode(“*”,new TreeNode(“8”),new TreeNode(“+”,t1,new TreeNode(“7”)));

  18. Tree Traversals • There are three common ways of tree traversals • pre-order traversal • in-order traversal • post-order traversal

  19. void preOrder(TreeNode t) { if (t!=null) { process(t.info); preOrder(t.left); preOrder(t.right); } } preOrder(t2) * 8 + / 6 3 7 void inOrder(TreeNode t) { if (t!=null) { inOrder(t.left); process(t.info); inOrder(t.right); } } inOrder(t2) 8 * 6 / 3 + 7 void postOrder(TreeNode t) { if (t!=null) { postOrder(t.left); postOrder(t.right); process(t.info); } } post-Order(t2) 8 6 3 / 7 + *

  20. Data for Binary Search Tree • Node and BST declarations. class TreeNode{ CompareKey key; TreeNode left; TreeNode right; } class BinarySearchTree { private TreeNode rootNode; public BinarySearchTree() {TreeNode = null} … // methods static TreeNode find(TreeNode t, CompareKey k) {…} void insert(CompareKey k) {…} }

  21. CompareKey Interface • For polymorphism, BST stores Objects. However their keys need to be comparable. • Hence, we should define an interface of the following . interface CompareKey { // if k1 & k2 are CompareKeys, then k1.compareTo(k2) // returns either // 0, +1, -1 according to k1==k2, k1>k2, or k1<k2 in the // ordering defined int compareTo(CompareKey value); }

  22. IntegerKey class IntegerKey implements CompareKey{ private Integer key; … //additional data possible IntegerKey(Integer value) {key=value); IntegerKey(int value) {key=new Integer(value)); public int compareTo(CompareKey val){ int a = this.key; int b = ((IntegerKey)val).key; if (a.intvalue == b.intvalue) return 0; else return (a.intvalue < b.intvalue) ? -1 : +1 ; } }

  23. BST Method : Find a Node static TreeNode find(TreeNode t, CompareKey k) { if (t==null) return null; else if ((result=k.compareTo(t.key))==0) return t; else if (result >0) return find(t.right,k); else return find(t.left,k); } • To find a node in a BST, we have:

  24. BST Method : Insert a Node void insert(CompareKey k) { rootNode = insertKey(rootNode,k); } private static TreeNode insertKey(TreeNode t,CompareKey k) { if (t==null) { TreeNode n = new TreeNode(); n.key = k; return n; } else if (k.compareTo(t.key)>0 { t.right = insertKey(t.right,k); return t; } else { t.left = insertKey(t.left,k); return t; } } • a recursive insertion function:
