”Gene Finding in Eukaryotic Genomes” DTU course #27614 Nikolaj Blom Center for Biological Sequence Analysis BioCentrum-DTU Technical University of Denmark nikob@cbs.dtu.dk

Outline • Gene finding in eukaryotic genomes • Why look for genes? • Genes as products • Orphan genes • What is the problem? • Needles in haystacks • Signal and background • Gene finding by hand • Gene features • Strategies • Ab initio gene prediction • Gene prediction methods • Isolated • Integrated

Gene Finding - Gene Hunting – Gene Discovery • Why Look for Genes? • Genes may: • Explain Basic Biological Functions • Protein kinases, Cyclins, etc. • Explain Medical Conditions • Cystic fibrosis gene • Be Used for Treatment of Disease • Contain commercial value • As enzymes (Lipases, Amylases, ’washing detergent’) • As drug targets (Ion channels, Receptors) • As therapeutic factors

Genes/Proteins(Biologics) as Pharmaceutical Products • ’Blockbusters’ >1 billion US$ yearly • Avonex • Interferon-beta from Biogen inc. • Multiple schlerosis • EPOgen • EPO (Erythropoetin) from Amgen inc. • Anemia

At Least 40% Orphan Proteins in the Human Genome Uncharted territory • Novel genes • Novel opportunities • Novel biological functions • Novel biomarkers and therapeutic factors Venter et al., Science, 2001

Human Genome Published HUGO: Nature, 15.feb.2001 Celera: Science, 16.feb.2001

We Have the Human Genome Sequence...now what? • Are there still novel genes to be discovered? • Yes! • What is the challenge? • We don’t know how many genes there are! • We don’t know where they (all) are! • We don’t know what they (all) do!

The cellular machinery recognize genes without access to GenBank, SwissProt or computers – can we?

Why is Gene Finding Difficult? • Because genes • are embedded in the genome sequence • are needles hiding in genome haystacks... • constitute only 2% of human genome (the coding regions) • are often split, ie. have exon-intron structure • Can we distinguish the gene features from the background?

Can U spot Spot?

TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTATGCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTTGTGTGTGTTATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTCCTTGTCAGGTTTTCACCCCATGCTCCTCCATTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGGGCTAGTCTGCTCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGCTTCCCGTCTTACTGGAAGACCAGCAGCATTTGACAGAGTTGGTCACTCTCTCCTCCTTGGACACCTTTTCTTCACTTGGTTTCCAGAACAGCATTATCTCCTGCTTATTGTCTTCCTCAGTCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTATGCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTTGTGTGTGTTATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTCCTTGTCAGGTTTTCACCCCATGCTCCTCCATTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGGGCTAGTCTGCTCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTGCTTCCCGTCTTACTGGAAGACCAGCAGCATTTGACAGAGTTGGTCACTCTCTCCTCCTTGGACACCTTTTCTTCACTTGGTTTCCAGAACAGCATTATCTCCTGCTTATTGTCTTCCTCAGTCTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT

AAGAGGTAATTAAAGCTAAATGAAGTTGTAAGAGTGGCCCTATCGCATAGGACTAGTGTCCCTATAAGAACACGAAGAAATCACCTTAGAAAGGCTGAGAAAGGGCTGCAGGGCAGTGGGAGTGCAGACTGAAAGATGCAGACCACTGGGCTTCTACTTCTGTTTCCATTTCTGATCCGGCCTGCATCTGCCTCCTTCCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTGCCACTGCACTCCAGCCTGGGTGACAGAGCAAGACCCTGCCTCAAAAATAAATAAATAAATAAATAAATAAAAATAAGAGTGCTTGGCAGCTTGATCAAGCTATGCCAGGAACCCATCTCTCAAGCAGCAGCTCTTCTCCTGTGCCATTGTCAGCTTTGTCCTGTCTGAGTCCATGGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTATATATATATATATATATATATATATATATATATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCACTGCAATACAGCCTGGGTGACAGAGCAAGACCTTATCTCAAAATAAACAAACAAACAAAAAAGATGACAAAATAAATGTCTGTCGTTTAAGTCACCCATTCTGTGATATCTTGTTACGGCAGCCTGAACTGACCAATACACTTCCTCACCCAGTTTAAATTCCATGCTCAATCATAATCAGCCATTGCAATTACCCTCAACTGTATTATCAACCCTCAATTTGTATTAGTTGCTTGGCAAAACCCAAACCCTTGTGAAATCCAGTTCTTCTATATCTACATCGATGCTGCCGAATATGGCTGAAGAAAAGCAACTGTGTTGACTGGACTGCTTTAAATTCATGACCACTTACCTCAAGTGGGCACTTAACTTCCTGGCAATTATTCTACATTTTTCTAGTCCATTAACTCTCCTCCTCTCTGAGTTAATTATTTCACAGCTTTTCCTCCCTCTTTATACATGTTCCATCCTAACTCTCTGCTGATGACCTTGTTTCTTATTTCACTAATGGAGGCCACCAGGAGAGAACTCCCACAGCCATCAAATTCACCAAGCCAACAGCATCCTTACACAAATCCTCTGCCTTCTCTCTGGGCTGGCTGTGCCCTCTCTTTGCTCCTGCAATTTCCCTAACTCTCCTATACTGTTGTTATTCACTCTCCAGTGGATAATCACCATCAGGATGCAAAGATGCTGTACTAGCTTCTGAACTCTCCAAAAACCCAGGAAACAAAAAGGCAAAGGCTAAGCTTTTTCTTATTCCCCCTTATATACATATATATATATAGTAGGCACTCAATAAACATTCACTGAATGAATGAACAGTAATGCTCACTTGCCCATAAATACAAGTACCTCATCTTTTACCACAAAGGGTATTTGTAAATATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAAACTCCTGAGCTCAAGCAATCCTCCCACCTTGGCTTCCCAAAGTGCTGGGATTATAGGCGTGAGCAACTGTACCTGGCAAAAACTTTTTAAGAGCTTCGCTTCCAGATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAGATTAGGCAACTTTAACCTTCAACAGTGATCATAACCCTTAGTTTTCAGATCCGATTAAGGGAAATGTGTAATGTCTTACTGACACACTAATCCCATCACTGCTCACACCACCCACAATTAGCTGAGAAGAGGTAATTAAAGCTAAATGAAGTTGTAAGAGTGGCCCTATCGCATAGGACTAGTGTCCCTATAAGAACACGAAGAAATCACCTTAGAAAGGCTGAGAAAGGGCTGCAGGGCAGTGGGAGTGCAGACTGAAAGATGCAGACCACTGGGCTTCTACTTCTGTTTCCATTTCTGATCCGGCCTGCATCTGCCTCCTTCCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTGCCACTGCACTCCAGCCTGGGTGACAGAGCAAGACCCTGCCTCAAAAATAAATAAATAAATAAATAAATAAAAATAAGAGTGCTTGGCAGCTTGATCAAGCTATGCCAGGAACCCATCTCTCAAGCAGCAGCTCTTCTCCTGTGCCATTGTCAGCTTTGTCCTGTCTGAGTCCATGGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTATATATATATATATATATATATATATATATATATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCACTGCAATACAGCCTGGGTGACAGAGCAAGACCTTATCTCAAAATAAACAAACAAACAAAAAAGATGACAAAATAAATGTCTGTCGTTTAAGTCACCCATTCTGTGATATCTTGTTACGGCAGCCTGAACTGACCAATACACTTCCTCACCCAGTTTAAATTCCATGCTCAATCATAATCAGCCATTGCAATTACCCTCAACTGTATTATCAACCCTCAATTTGTATTAGTTGCTTGGCAAAACCCAAACCCTTGTGAAATCCAGTTCTTCTATATCTACATCGATGCTGCCGAATATGGCTGAAGAAAAGCAACTGTGTTGACTGGACTGCTTTAAATTCATGACCACTTACCTCAAGTGGGCACTTAACTTCCTGGCAATTATTCTACATTTTTCTAGTCCATTAACTCTCCTCCTCTCTGAGTTAATTATTTCACAGCTTTTCCTCCCTCTTTATACATGTTCCATCCTAACTCTCTGCTGATGACCTTGTTTCTTATTTCACTAATGGAGGCCACCAGGAGAGAACTCCCACAGCCATCAAATTCACCAAGCCAACAGCATCCTTACACAAATCCTCTGCCTTCTCTCTGGGCTGGCTGTGCCCTCTCTTTGCTCCTGCAATTTCCCTAACTCTCCTATACTGTTGTTATTCACTCTCCAGTGGATAATCACCATCAGGATGCAAAGATGCTGTACTAGCTTCTGAACTCTCCAAAAACCCAGGAAACAAAAAGGCAAAGGCTAAGCTTTTTCTTATTCCCCCTTATATACATATATATATATAGTAGGCACTCAATAAACATTCACTGAATGAATGAACAGTAATGCTCACTTGCCCATAAATACAAGTACCTCATCTTTTACCACAAAGGGTATTTGTAAATATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAAACTCCTGAGCTCAAGCAATCCTCCCACCTTGGCTTCCCAAAGTGCTGGGATTATAGGCGTGAGCAACTGTACCTGGCAAAAACTTTTTAAGAGCTTCGCTTCCAGATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAGATTAGGCAACTTTAACCTTCAACAGTGATCATAACCCTTAGTTTTCAGATCCGATTAAGGGAAATGTGTAATGTCTTACTGACACACTAATCCCATCACTGCTCACACCACCCACAATTAGCTGAG Can U spot the Gin? Can U spot the Gene? Ooops

AAGAGGTAATTAAAGCTAAATGAAGTTGTAAGAGTGGCCCTATCGCATAGGACTAGTGTCCCTATAAGAACACGAAGAAATCACCTTAGAAAGGCTGAGAAAGGGCTGCAGGGCAGTGGGAGTGCAGACTGAAAGATGCAGACCACTGGGCTTCTACTTCTGTTTCCATTTCTGATCCGGCCTGCATCTGCCTCCTTCCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTGCCACTGCACTCCAGCCTGGGTGACAGAGCAAGACCCTGCCTCAAAAATAAATAAATAAATAAATAAATAAAAATAAGAGTGCTTGGCAGCTTGATCAAGCTATGCCAGGAACCCATCTCTCAAGCAGCAGCTCTTCTCCTGTGCCATTGTCAGCTTTGTCCTGTCTGAGTCCATGGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTATATATATATATATATATATATATATATATATATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCACTGCAATACAGCCTGGGTGACAGAGCAAGACCTTATCTCAAAATAAACAAACAAACAAAAAAGATGACAAAATAAATGTCTGTCGTTTAAGTCACCCATTCTGTGATATCTTGTTACGGCAGCCTGAACTGACCAATACACTTCCTCACCCAGTTTAAATTCCATGCTCAATCATAATCAGCCATTGCAATTACCCTCAACTGTATTATCAACCCTCAATTTGTATTAGTTGCTTGGCAAAACCCAAACCCTTGTGAAATCCAGTTCTTCTATATCTACATCGATGCTGCCGAATATGGCTGAAGAAAAGCAACTGTGTTGACTGGACTGCTTTAAATTCATGACCACTTACCTCAAGTGGGCACTTAACTTCCTGGCAATTATTCTACATTTTTCTAGTCCATTAACTCTCCTCCTCTCTGAGTTAATTATTTCACAGCTTTTCCTCCCTCTTTATACATGTTCCATCCTAACTCTCTGCTGATGACCTTGTTTCTTATTTCACTAATGGAGGCCACCAGGAGAGAACTCCCACAGCCATCAAATTCACCAAGCCAACAGCATCCTTACACAAATCCTCTGCCTTCTCTCTGGGCTGGCTGTGCCCTCTCTTTGCTCCTGCAATTTCCCTAACTCTCCTATACTGTTGTTATTCACTCTCCAGTGGATAATCACCATCAGGATGCAAAGATGCTGTACTAGCTTCTGAACTCTCCAAAAACCCAGGAAACAAAAAGGCAAAGGCTAAGCTTTTTCTTATTCCCCCTTATATACATATATATATATAGTAGGCACTCAATAAACATTCACTGAATGAATGAACAGTAATGCTCACTTGCCCATAAATACAAGTACCTCATCTTTTACCACAAAGGGTATTTGTAAATATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAAACTCCTGAGCTCAAGCAATCCTCCCACCTTGGCTTCCCAAAGTGCTGGGATTATAGGCGTGAGCAACTGTACCTGGCAAAAACTTTTTAAGAGCTTCGCTTCCAGATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAGATTAGGCAACTTTAACCTTCAACAGTGATCATAACCCTTAGTTTTCAGATCCGATTAAGGGAAATGTGTAATGTCTTACTGACACACTAATCCCATCACTGCTCACACCACCCACAATTAGCTGAGAAGAGGTAATTAAAGCTAAATGAAGTTGTAAGAGTGGCCCTATCGCATAGGACTAGTGTCCCTATAAGAACACGAAGAAATCACCTTAGAAAGGCTGAGAAAGGGCTGCAGGGCAGTGGGAGTGCAGACTGAAAGATGCAGACCACTGGGCTTCTACTTCTGTTTCCATTTCTGATCCGGCCTGCATCTGCCTCCTTCCTGAACAGGCCAGAGAATTCATCTAAATAGCCTAAGCAGGCTGGGTGCTGTGGCTCACCTGTAATCCCAACACTTGGGAGGCCGAGGTGGGCAGATCACCTGAGGTCAGGAGTTCAAGGCTAGCCTAGCCAACATGACAAAACCCCATCTCTACTAAAAAAATACAAAAATTAGCCAGGCATAGTGGCGCCTATAGTTCCAGCTACTTGGGGGCTGAGGTAGGAAGATCGCTAGAGCCTGGGAGGTTAAGGCTGCGGTGAGCTGTGATTGTGCCACTGCACTCCAGCCTGGGTGACAGAGCAAGACCCTGCCTCAAAAATAAATAAATAAATAAATAAATAAAAATAAGAGTGCTTGGCAGCTTGATCAAGCTATGCCAGGAACCCATCTCTCAAGCAGCAGCTCTTCTCCTGTGCCATTGTCAGCTTTGTCCTGTCTGAGTCCATGGGACTCTTCTGTTTGATGGTGGTCTTCCTCATCCTCTTCATCATGTGAAGCTCCATGGAGATCACCTACCCATACCTGCTTCTGTGACCTCATGCCATTCCTGGTGTTGGAATGTGCCAAGGTTTGCCATTAAACACACATTTCTCATTTCATAATTTCATATATATTATATATATGTGTGTGTGTGTGTGTTTATATATGCGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTGTATATATATATATATATATATATATATATATATATATATATAAAATATATAGGAAGAGGCACCAGAGAGCTCTCTGCATAGTCACAGAGGAAAGGTCATGTGAGGACAGCCAGAAGGCAGATGTCACAAGCCTCACCAGCAACCTACCATACCCTGCTTGTACCTCCATCCTGGAAGTCCAGCTTCTAAAATTAGAAGAAAATAGTCGGGTGTGGTGGCTCGCACCTATAATCCCAGCACTTTGGGAGGCTGATGTGGGAGGATCATTTGAGGTCAAGAGTTTGAAACCAGCCTAGGCAACATAGGGAGACCCTGTCTTTAAAAAAAATTTTTTTTTGTTTTAATTAGCTGGGTGTGATGGTGCACACCTGAGTCCTAGCTACTTGGGAGGCTGAGGTAGGAGGATCCCCTGAGCCCAGGGAAGTGGAGGCTGCAGTGAGCCATGATCACACCACTGCAATACAGCCTGGGTGACAGAGCAAGACCTTATCTCAAAATAAACAAACAAACAAAAAAGATGACAAAATAAATGTCTGTCGTTTAAGTCACCCATTCTGTGATATCTTGTTACGGCAGCCTGAACTGACCAATACACTTCCTCACCCAGTTTAAATTCCATGCTCAATCATAATCAGCCATTGCAATTACCCTCAACTGTATTATCAACCCTCAATTTGTATTAGTTGCTTGGCAAAACCCAAACCCTTGTGAAATCCAGTTCTTCTATATCTACATCGATGCTGCCGAATATGGCTGAAGAAAAGCAACTGTGTTGACTGGACTGCTTTAAATTCATGACCACTTACCTCAAGTGGGCACTTAACTTCCTGGCAATTATTCTACATTTTTCTAGTCCATTAACTCTCCTCCTCTCTGAGTTAATTATTTCACAGCTTTTCCTCCCTCTTTATACATGTTCCATCCTAACTCTCTGCTGATGACCTTGTTTCTTATTTCACTAATGGAGGCCACCAGGAGAGAACTCCCACAGCCATCAAATTCACCAAGCCAACAGCATCCTTACACAAATCCTCTGCCTTCTCTCTGGGCTGGCTGTGCCCTCTCTTTGCTCCTGCAATTTCCCTAACTCTCCTATACTGTTGTTATTCACTCTCCAGTGGATAATCACCATCAGGATGCAAAGATGCTGTACTAGCTTCTGAACTCTCCAAAAACCCAGGAAACAAAAAGGCAAAGGCTAAGCTTTTTCTTATTCCCCCTTATATACATATATATATATAGTAGGCACTCAATAAACATTCACTGAATGAATGAACAGTAATGCTCACTTGCCCATAAATACAAGTACCTCATCTTTTACCACAAAGGGTATTTGTAAATATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAAACTCCTGAGCTCAAGCAATCCTCCCACCTTGGCTTCCCAAAGTGCTGGGATTATAGGCGTGAGCAACTGTACCTGGCAAAAACTTTTTAAGAGCTTCGCTTCCAGATTTAGGTTGTTTCTACCCAGATTATGGCTTGGTAATTCTTTTTTTTTTTTTCTAATTTTTATTTTTTTTCTAGGGACAGGGTCTCACTATGTTGCCCAGGATGGTCTTGAACTCCTGGGCTCAAGCATTCTGCCTGCCTTGGCCTCCTAAAGTGCTGAGATTACAGGCATGAGCCACCGTGCCTGCCTTCATGTATGTTTTTAGAACACAGAGAAAATGTGTTCTAAATGTGCTCATTGCTCAGCAATGAGCAAAGGCTTATGCAGTCACCACCAATCAAAAACTTTTTTTTTTTTTTTTGAGACAAGATCTTGCTCTGTTGCCCAGGCTGGAGTGCAGTGGCAGGATCATAGCAAGCTGCAGTCTTGACCTCATAGGCCTAAATCATCCTCCCACCTCAGCCTCACAAGTAGCTAAGACCACAGGTACAAGCCACCGTATCTAGCTAACTTTCAAAATTTTTTGAATTTTTAAATTTAAAAATTTTGAGGCCAGGCTGGCCTCAGATTAGGCAACTTTAACCTTCAACAGTGATCATAACCCTTAGTTTTCAGATCCGATTAAGGGAAATGTGTAATGTCTTACTGACACACTAATCCCATCACTGCTCACACCACCCACAATTAGCTGAG

Manual Genefinding Find, mark and count all ATG Start codon: ATG Stop codons: TAA, TAG, TGA Donor splice site: ^GT[AG]AG Acceptor splice site: [CT]AG^ >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCC AGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101 GTCTTGTGTG TCCCCCAGCA GCCTTGTCAT CTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAG ATCCAGCCCT ATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAAC TGCCAATGAC AAGCCCAGTC How many ATGs do you expect?

Manual Genefinding Start codon: ATG p(ATG)=p(A) x p(T) x p(G) ~ ¼ x ¼ x ¼ = 1/64 (in 950 bp = 14.8 ATG expected)

Manual Genefinding Start codon: ATG p(ATG)=p(A) x p(T) x p(G) ~ ¼ x ¼ x ¼ = 1/64 (in 950 bp = 14.8 ATG expected; observed = 16) >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCC AGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101 GTCTTGTGTG TCCCCCAGCA GCCTTGTCAT CTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGATGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCATGTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAATGGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAG ATCCAGCCCT ATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAAC TGCCAATGAC AAGCCCAGTC

Manual Genefinding Start codon: ATG p(ATG)=p(A) x p(T) x p(G) ~ ¼ x ¼ x ¼ = 1/64 (in 950 bp = 14.8 ATG expected; observed = 16 17) >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCC AGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101 GTCTTGTGTG TCCCCCAGCA GCCTTGTCAT CTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGATGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCATGTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAATGGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAG ATCCAGCCCT ATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAAC TGCCAATGAC AAGCCCAGTC

Manual Genefinding Mark codons until first in-frame Stop codon Start codon: ATG Stop codons: TAA, TAG, TGA >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCC AGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCAT CTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAG ATCCAGCCCT ATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAAC TGCCAATGAC AAGCCCAGTC

Manual Genefinding Mark codons until first in-frame Stop codon Start codon: ATG Stop codons: TAA, TAG, TGA >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCCAGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCATCTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAG ATCCAGCCCT ATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAAC TGCCAATGAC AAGCCCAGTC

Genes and Signals

Manual Genefinding Find and mark potential donor splice sites in first exon Start codon: ATG Stop codons: TAA, TAG, TGA Donor splice site: ^GT[AG]AG Acceptor splice site: [CT]AG^ >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCCAGAAGGTAAG TCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCATCTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAGATCCAGCCCTATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAACTGCCAATGAC AAGCCCAGTC First exon (Coding exons!) Second exon

Manual Genefinding Find and mark potential donor splice sites in first exon Start codon: ATG Stop codons: TAA, TAG, TGA Donor splice site: ^GT[AG]AG Acceptor splice site: [CT]AG^ >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCCAGAAGGTAAGTCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCATCTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAGATCCAGCCCTATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAACTGCCAATGAC AAGCCCAGTC First exon (Coding exons!) Second exon

Manual Genefinding Alternative splice forms(?) Start codon: ATG Stop codons: TAA, TAG, TGA Donor splice site: ^GT[AG]AG Acceptor splice site: [CT]AG^ >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCCAGAAGGTAAGTCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCATCTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAGATCCAGCCCTATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAACTGCCAATGAC AAGCCCAGTC First exon (Coding exons!) Not in frame Second exon

Manual Genefinding Alternative splice forms(?) Start codon: ATG Stop codons: TAA, TAG, TGA Donor splice site: ^GT[AG]AG Acceptor splice site: [CT]AG^ >U70368 (950 bp) 1 CTCCCTTAGA AGACTCCAGC AAGTTATTTG AAGAGGTCTT TGGAGACATG 51 GTGAGTTCTC TTTCCTTCCCAGAAGGTAAGTCTCACTGTA AGGTCTTTAT 101GTCTTGTGTG TCCCCCAGCA GCCTTGTCATCTCCGGCTGC CCTAGACCTG 151 CATAAGGACA GATTGAGTGT GCTGGGATAG ACTTTTGTTG ACAAAGGGGC 201 TGCTCTGCCC TTCTAAGAGG TTGAGTCTCA TCATAAGGCC TTTTGCAGCT 251 TGCATGTGTA GTGCCAGGAA AGAGTAGTCA TCCCCCAAAA CCAGACAGGA 301 ACTGACGAGA TGCAATCACT GTGTGGACTT TTTACCAGCT AGCTAGGGCA 351 CTACCATGAG CCACTGTCTA GCAGGGAGGC TTTGGGGATG GTGTGCCCCG 401 AATATCTCTC AGGGTAAGAG TTTACAGTAA GCAGCAAGCA GAGGGGTGTG 451 GGTGAGTGTG CAAGTATCTA ATTGGCTAGT TTTTGTGGCC TGTAACATAT 501 TGGTGGGTGT TGGGAGTCAT AAGCTAAATG TTTGCTTTCC TCTGCATTGG 551 TGGTCATTAG GGAGGGGGCA GATTATGAAC CTAGGTTGCA GATCTGTTGG 601 AGTAATAACA AGACACTGGT CTTGTTGGGG GTATAACCTA GAGACTCGAT 651 TTATGTTCAT GTTTGGTTTG GGATGGGTTT TATGTGAGTG TTTTCTTTTT 701 TGGGGAGGGG GTCGGTTAAC TTGGAAAGTA ATGCTAGGTA CTGTCCTGTT 751 CATTTCCCTG AGGTGAAAGT TAGGTCAGGT TTTCTAGAAT GGAGTCTGAA 801 GGTAAAACAT TTGGCCACTG GCATGCCCTA AAGTCTTTTT GTGTTCTTGT 851 CCCCTAGCAGATCCAGCCCTATCATCTCCT GGTGCCCAAC AGCTGCATCA 901 GGATGAAGCT CAGGTAGTGG TGGAGCTAACTGCCAATGAC AAGCCCAGTC First exon (Coding exons!) Second exon

How to Approach a Novel Genome • First hunt for similar genes • Align all known genes and ESTs from all other organisms against genome sequence • Some exons more conserved than others • Will not result in complete gene structures • Will indicate regions potentially encoding genes • Some genes will have no homology to any known genes • Second hunt includes • ab initio gene prediction • Predict full gene structure from genomic DNA

Gene Prediction • Eukaryotic Gene Prediction • Prediction relies on integration of several gene features • Each gene feature carries a low signal • E.g. ATG, splice sites, etc. • Combinatorial explosion • Some are mutually exclusive (e.g. reading frame) • Sensor based HMMs well suited for gene prediction

Sensor-based methods • Ab initio Gene Finders • HMM-based • GenScan • HMMgene • Neural network-based • GRAIL • NetGene2 (splice sites)

Gene Features • Codon frequency/bias • Organism dependent • Hexamer statistics • Transcriptional • Promoters/enhancers • Exon/introns • Length distributions • ORFs • Splicing • Donor/acceptor sites • Branchpoints • Translational • Start codon context

Codon Bias • tRNA availability • Expression level • Gene Finders are often organism specific • Coding regions often modelled by 5th order Markov chain (hexamers/di-codons)

Needles Hiding in Genome Haystacks... • Intron-exon structure of genes • Large introns (average 3365 bp ) • Small exons (average 145 bp) • Long genes (average 27 kb)

Human genes: • Short exons • Long introns

Intron lengths • Human genes: • Introns lengths have broad distribution • Min. Length ca. 60 bp

Intron Prevalence

Gene Prediction • ”Isolated” methods • Predict individual features • E.g. splice sites, coding regions • NetGene (Neural network) • http://www.cbs.dtu.dk/services/NetGene2/ • ”Integrated” methods • Predict genes in context • ”Grammar” of genes • Certain elements in specific order are required • HMMgene http://www.cbs.dtu.dk/services/HMMgene/ • GenScan (HMM-based) http://genes.mit.edu/GENSCAN.html

Gene Grammar Isolated features HAPPYEUGENEAWASGUYFINDER

Gene Grammar Isolated features HAPPYEUGENEAWASGUYFINDER Intron 3’UTR Exon Promoter Exon RBS

Gene Grammar Integrated features EUGENEFINDERWASAHAPPYGUY HAPPYEUGENEAWASGUYFINDER

Gene Grammar Integrated features EUGENEFINDERWASAHAPPYGUY PromRBSExonIntronExon3’UTR

Gene Grammar ”Isolated” methods (e.g.NN): HAPPYEUGENEAWASGUYFINDER ”Integrated” methods (e.g.HMM): EUGENEFINDERWASAHAPPYGUY

HMMs for genefinding • GenScan principle • E=exon • I=intron • F=5’ UTR • T=3’ UTR • P=promoter • N=intergenic

Gene Prediction Programs • ”Integrated” methods • HMMgene • http://www.cbs.dtu.dk/services/HMMgene/ • GenScan (HMM-based) • http://genes.mit.edu/GENSCAN.html • ”Isolated” methods • NetGene (Neural network) • http://www.cbs.dtu.dk/services/NetGene2/

Genscan http://genes.mit.edu/GENSCAN.html

Genscan

Genscan http://genes.mit.edu/GENSCAN.html

Genscan
