runtime feedback in a meta tracing jit for efficient dynamic languages

Runtime Feedback in a Meta-TracingJIT for Efficient Dynamic Languages

Writer: Carl Friedrich Bolz

Introduced by Ryotaro IKEDA

at 2011/09/06


This paper describes about…

How to make it more efficient to apply JIT compiler with PyPy

PyPy :

Well-known as fast Python implementation.

However, in actual, it is one of framework to implement interpreter with JIT and GC!

( Python implementation is just a demo! )

What is PyPy?

Framework which enables to write

interpreter implementation with Restricted Python

The project mainly intends to give environments to

implement dynamic interpreter much efficient

pypy s jit automatic implementation
PyPy’s JIT Automatic Implementation


It is implemented

by PyPy user!

Target code that is

written in any language

Any interpreter

that is written in RPython

Give some “hints”

to enable to run JIT

compiler efficiently


PyPy’sRPython interpreter

The most bottom one performs JIT compilation

and optimization to the middle one

In result, JIT compiler that is suitable for

any language is automatically implemented

how to treat non language specific jit compilation
How to treat non-language-specific JIT compilation

Typical JIT Compiler

Uses language-specific feature because

each JIT compiler is dedicated to compile only one language

PyPy’s JIT Compiler

Though it is for RPython, PyPy can’t use any language-specific featurewhich PyPy user want to implement.

It is what we called “ Meta-Tracing “

How can we make it much faster with applying

efficient method for Meta-Tracing??

= Objective

what merit using pypy rather than jit of other implementation
What Merit Using PyPyRather than JIT of other implementation

Widen compilation / optimization area

It is too challenging for JIT compiler

to target data structure operation

Typical JIT Implementation

It traces ,and only looks to whole RPython code,

so it can target data structure operation

which written in RPython by developer.

PyPy’s JIT


hinting mechanism
Hinting Mechanism

Main concept



Giving hints to enable JIT compiler to compile

efficiently is the most important




A hint to turn arbitrary variables into constants in the trace by

feeding back runtime information into compilation

A way to annotate operations which the constant folding opti-

mization then recognizes and exploits.

General techniques for refactoring code to expose constant

folding opportunities of likely runtime constants.

pypy s meta tracing jit compilers
PyPy’s Meta-Tracing JIT Compilers


To check and determine which control path to compile

x = 100

y = 200

Cycle: Trace


Optimizations are also

performed during

this trace form



x = x + y

Also constant-folded

Trace (cycles, to be compiled):

Cond -> x = x + 200 -> Cond ….

pypy s tracer
PyPy’s Tracer

Trace Area

PyPy (can / by default) traces only “hot” paths.

-> Trace will be invoked frequently executed path


It indicates how many times

the loop is executed

When it crosses

threshold, it is

regarded as “hot”


for x in sequence :

t = x + ….

☆ As mentioned before, PyPy’s tracer doesn’t trace user program

directly, but interpreter implementation written in RPython instead.

optimization passes
Optimization Passes
  • Remove/simplify operations in the trace
    • Constant folding
    • Common subexpression elimination
    • Allocation removal
    • Store/load propagation
    • Loop invariant code motion

These can be applied because traces are absolutely linear form

Operate duringRPython form

running example
Running Example

Arrangements of shown examples

Simple and bare-bones object model.

  • Just supports classes and instances
  • No inheritance
  • Class contains method and variable
  • Instance have a class, if no requested method / variable found in the instance, it searches among the class.
example implementation
Example Implementation

Use dictionary

to manage class method

Use dictionary

to manage instance


To search requested method

To register given method

Dictionary’s “get” method costs too much.

To solve the problem, it is required to make it target to JIT compilation

( The way to do this is described later discussion )

hints for controlling optimization
Hints for Controlling Optimization

Applied only to interpreter written in RPython, not user program.

  • Two hints that enables to increase the optimization opportunities for constant folding

Enable propagation to find “Constant-

foldable” variables via trace guard



Annotation to notify which variables

are assumed as constant variable

☆ Though each of them never break code’s behavior,

Using them incorrectly will definitely deteriorate its speed.

what guard is
What “Guard” is

Dynamic Language

That both x and y are number, or string is OK

test = x + y;

Static Language

That both x and y are either number or string, types cannot be canged

test = x + y;


It is necessary to assure each variables’ type are same

to compile Dynamic Language to Static Language

Native code is one of static language, it’s needed

how guard works
How “Guard” works

Guard assures that interpreter is running compiled trace in

same condition as when it is compiled at first time.

Source code

Trace result

Now it



y = 10

z = 100

for x in sequence:

x = y + z

y += 1

…. = func(x)

guard(x == int() )

guard(y = int())

guard(z = 100)

x = y + z

y += 1

…. = func(x)

Assure conditions

to compile them

to machine code


If conditions described in guard is true,

it continues to run.

During execution

of compiled

machine code…

If conditions described in guard is false,

it stops to run and switch to interpreter exec.

  • Technique to operate constant-fold using guard

Result after Promotion

Source Code

Trace Result








x = somefunc()

y = func(x)

x = somefunc()

guard( x == 200)

y = func(200)

x = somefunc()

guard( x == 200)

y = func(x)

Trace tree

x = somefunc()


guard(x == 200)


y = func(200)

y = func(x)

Normal execution root (interpreter)

Traced root (will be / already compiled)

promote how to
“Promote” how to

Use “promote()” embedded method

which is given by PyPyRPython interpreter

to give it a “hint” that indicates

“promote” can be applied during this scope.

Assume the trace here usually be with a

condition that self and val are expected

to not so frequently varied.

Guard-fall is expected not so

occurs frequently

Later discussion!


It may not consume overhead

so much and can be expected

that constant-folding will bring

great improvement.

trace elidable helps to apply promote
“Trace-Elidable” helps to apply “Promote”
  • To tell the truth, promote cannot be invoked without @elidable annotation in the example.


Assure specific method never

change any variables.

Though tracer want to “promote” method “f” ,

tracer doesn’t know whether self.c() returns

always same value or not…

Tracer considers not to use

value-specific guard but

type-specific guard… never “promoted”.

@elidable annotations shows that given method is immutable

This “hint” enablestracer to promote f()!

result trace after these 2 hints applied
Result trace after these 2 hints applied




Constant-folding is applied

via @elidable and promote.

This trace is created

without any hints given.

technique to increate trace elidable
Technique to increate “trace-elidable”

Putting It All Together

Increasing the amount of Trace-elidable method increases

chance to apply constant-folding and to help Promote.

for index map (described in next slide)

Prepare original “Map” class

to manage Instance’s attributes

instead of using dictionary

To append @elidable


index map
Index map
  • Efficient / Suitable data structure for PyPy

Map: To manage data location (index)

“string” : 1

“v1” : 0

“x” : 3

List: Stores actual data

Prepare getindex with this impelemntation,

though it is immutable, trace-elidable can be used!

how does instance use the map
How does Instance use the “Map”?

This class which is used for manage instances no longer uses dictionary!

No longer use dictionary

Whole methods belong to “map”

are “trace-elidable”.

So the promote will work correctly!

versioning of classes
Versioning of Classes

Using only trace-elidabledon’t satisfy requirements

In Python, though @elidable annotation is given,

the method may yield not same value because

any attributes can be changed.

How do you feel if

“inst.x = -1” is executed?

class A:

def __init__(self):

x = 100


def X(self):

return x

inst = A()

It is necessary to handle

this possible changes

They propose “Versioning”

use guard feature to versioning
Use Guard Feature to Versioning

Dummy class to use guard feature

This promote helps to create value-specified

guard with current “version”.

So, it is still trace-elidable but can handle

methods changing.

When some of methods is changed,

Yield new VersionTag and save it to self.version



Intel Core2 Duo P8400 processor with 2.26

GHz and 3072 KB of cache on a machine

with 3GB RAM running Linux 2.6.35

It uses many OOP’s features

No hints given


for board game

BZ2 decoder

OS Kernel


Decimal floating

Point calculations

  • Two hints that can be used in the source code of an interpreter written with PyPy.
  • They give control over runtime feedback and optimization to the language implementor.
  • They are expressive enough for building well-known virtual machine optimization techniques, such as maps and inlining.
effects to my study
Effects to my Study
  • Use PyPy as infrastructure
    • It can emit C source code from RPython implementation
      • Applying P.T seems easy
    • Parallelized Template for Rpython
      • This paper performs optimizations in RPython form.How do you think that I consider to implementtemplate code in RPython?
