Presentation Transcript
slide2

How to Control

Your Own Apparatus

using

PC Printer Port

Viraj Vishwakantha Jayaweera

slide3

Printer

Touch pad

Scanner

Microphone

CPU

Monitor

Speaker

Mouse

Key Board

slide4

All these devices can be divided in to two categories

Output

Output

Process

Output

Input

Input

Input

Input

slide5

Motor

How to connect my own device ?

?

?

Light Bulbs or LEDs

?

Micro Switch

Temperature Censer

(Thermister)

Light Censer

(LDR)

Water Censer

slide6

Various types of connecters (communication ports) available in rear side of CPU

USB

(Universal Serial Bus)

Parallel Port (Printer Port)

RS232

(Serial Port)

Speaker

Microphone

Line In

GPIB

(Genaral Purpose Interface Bus)

slide7

1000 * 0 = 0

100 * 1 = 100

10 * 6 = 60

1 * 4 = 4

= 164

8 * 1 = 8

4 * 1 = 4

2 * 0 = 0

1 * 1 = 1

= 13

Decimal & Binary Number Systems

Decimal

Binary

10

2

1000

100

1

8

4

1

103

102

101

100

23

22

21

20

1 1 0 1 2

1 6 4

We use Ten Symbols

0 1 2 3 4 5 6 7 8 9

We use Two Symbols

0 1 or Off On or Low Hi or 0V 5V

slide8

Auto Feed

Data 0

Data 1

Initialize Printer

Data 2

Error

Data 3

Select Input

Data 4

Data 5

Data 6

Data 7

Strobe

ACK

Busy

Paper Empty

Select

Printer Port Pin Assignment

1 14

Input

Output

Output

Pins 18 – 25 Ground

Input

13 25

8 Data Outputs (378 H)

4 Other Outputs (379 H)

5 Data Inputs (37a H)

slide9

1 14

13 25

Directly Connect LED to Printer Port

VCC

LED

5V

-

+

470 ohm

Example in Qbasic

Out &H378,1(for LED off)

Out &H378,0(for LED on)

Printer Port

slide10

1 14

13 25

Directly Connecting LED to Printer Port

LED

470 ohm

Printer Port

D0

D1

D2

D7

5 V

slide12

230 V AC

L N

X

D1

R1

1N4007

10kohm

K2

From

Printer Port

Y

R3

RELAY

D400

10kohm

230V AC Motor

R2

R5

100kohm

3.3kohm

Output Signal Amplifier

VCC

12V

R4

3.3kohm

5

IN+

2

IN-

4

Comparator

¼ LM339

slide14

1 14

13 25

Simple method to use Signal Input line

we can use Qbasic function inp()

X = Inp( &H379)

Print X

Printer Port

10

25

Switch

slide15

12V

LDR

100kohm

10kohm

¼ LM339

5

To Printer

Port Input

IN+

2

IN-

4

Comparator

1 M

Preset

100kohm

5.6kohm

Input Detectors

100 k

Preset
